BluePrint Engines BP350CTCK 350CI Cruiser Crate Engine, Dressed

Ships FREE!

#227BP350CTCK

BluePrint Engines BP350CTCK 350CI Cruiser Crate Engine, Dressed

Name: BluePrint Engines BP350CTCK 350CI Cruiser Crate Engine, Dressed
Brand: BluePrint Engines
SKU: 227BP350CTCK
Price: 8299 USD
Availability: LimitedAvailability
Rating: 5 (1 reviews)

1 Review

1 Question

HP & Torque: 341 HP / 371 FT LBS
Compression Ratio: 9.0:1
Aluminum Heads

Level Of Dress:

#3 Deluxe Dressed - Carbureted - Black Pulley Kit

#1 Long Block #2 Base Dressed - Carbureted #3 Deluxe Dressed - Carbureted#4 Deluxe Dressed - EFI #4 Deluxe Dressed - EFI - Black Pulley Kit

$8,299.00

/kit

In Stock

Order soon, only 2 left in stock!

Quantity

Need Help? Call to Order

Add to a list

Select an engine to verify Fitment

Select Engine

Product Summary

Deluxe Crate Engine Crate Engine Type, Oil Pan Included

HP & Torque: 341 HP / 371 FT LBS
Compression Ratio: 9.0:1
Aluminum Heads
Hydraulic Roller Cam
Cast Iron Crankshaft

Rebates Available

See rebate details

See more details

Key Specs

Crate Engine Type	Deluxe Crate Engine
Compression Ratio	9.0:1
Engine Displacement	350 cu. in.
Camshaft Type	Hydraulic Roller Tappet
Cylinder Head Material	Aluminum

See more specs

Need To Know

Truck Shipment

Truck shipments must be pre-paid with a credit card, certified check or money order

Need help?

855.313.9176

View the Help Center

Quick and Easy Returns

Return Policy

BluePrint Engines BP350CTCK Details

HP & Torque: 341 HP / 371 FT LBS
Compression Ratio: 9.0:1
Aluminum Heads
Hydraulic Roller Cam
Cast Iron Crankshaft
Hypereutectic Pistons

BLOCK:

NEW BluePrint Cast Iron Block
Manufactured and Machined in the USA!
4-Bolt Main
4.000" Bore
1-Piece Rear Main Seal
Mech fuel pump provision: Yes
Passenger Side Dipstick
Drilled and tapped for clutch linkage

ROTATING ASSEMBLY:

Cast Iron Crankshaft
3.480" Stroke
Forged 5.700" connecting rods
Hypereutectic pistons
Internal Front/ External Rear engine balance

CYLINDER HEADS:

BluePrint Aluminum Cylinder Heads - H8002K
64cc chamber
2.02" intake/1.60" exhaust valves
195cc intake/75cc exhaust runners

CAM SPECS:

Cam Type: Roller
.477 Intake .471 Exhaust
202 Intake / 212 Exhaust duration
@ .050 - 115 degree lobe separation

IGNITION TIMING:

32 Degrees Total at 3500 RPM

ALSO INCLUDES:

Valve covers
Oil pan
Timing cover
Aluminum intake
HEI distributor
Spark plugs and wires
600 cfm carburetor HOLLEY 80457
Mechanical fuel pump
Waterneck and Thermostat
Dyno test results shipped with engine
Front Accessory Drive with Water Pump, A/C Compressor, Alternator, and Power Steering Pump (Does not fit Corvette)

WARRANTY:

30 month / 50,000 mile

NOTES:

This engine is an excellent cruiser and daily driver engine. This engine makes up to 18 inches of vacuum, and is designed to work excellent with power brakes, stock torque converter, stock gearing, and run on 87 octane fuel

Features

The front serpentine assemblies installed on the deluxe dressed crate engines feature the 7B10 Peanut style A/C compressor, this unit is fitted for the R-134A Freon Refrigerant type-fittings, and is compatible with most aftermarket A/C systems such as Vintage Air.

Rebates

BluePrint Old School $350 Off Qualifying Engines

Purchase a qualifying BluePrint Engines 350ci (341 HP) Small Block Chevy-compatible engine during the promotional period and receive a $350 mail-in rebate. To take advantage of this offer, complete the rebate form and mail it along with a copy of your purchase receipt within 30 days of the purchase date. The rebate is valid on eligible engine part numbers only and provides $350 back for each qualifying engine purchased, making it a great opportunity to save on a classic, reliable BluePrint Engines small block powerplant.

Guides & Documents

Crate Engines Installation Instructions (227BP350CTCK)

Crate Engines Technical Information (227BP350CTCK)

CARB Warning

Follow EPA, CARB, and state regulations for engine changes

Emissions warning: this part is for vehicle engine changes, not direct oem engine replacements. In California, engine changes are legal when done in compliance with California bureau of automotive repairs (bar) engine change policy. For assistance, call bar referee at: (800) 622-7733. And see https://bar.Ca.Gov/consumer/smog_check_program/engine_changes. All customers must comply with federal epa mobile source enforcement memorandum no. 1a (and addendum) and all applicable state regulations when conducting engine changes. Improper installation and/or use of this part in California may subject the installer and/or owner to a $37,500 penalty per violation per vehicle, revocation of registration, loss of use on California public right of ways, and proof of correction for tampering. There are similar restrictions and penalties under federal law and laws of all states for use of this engine change part on makes or models of vehicles that render them noncompliant with applicable state and/or federal emission laws with penalties under federal law of up to approximately $45,268 per tampered vehicle and/or engine

CA WARNING:

Can expose you to lead, a carcinogen and reproductive toxicant. See www.P65Warnings.ca.gov

CARB warning

BluePrint Engines BP350CTCK Specifications

KEY SPECS
MFG. Part #	BP350CTCK
Brand	BluePrint Engines
Crate Engine Type	Deluxe Crate Engine
Compression Ratio	9.0:1
Engine Displacement	350 cu. in.
Camshaft Type	Hydraulic Roller Tappet
Cylinder Head Material	Aluminum
Piston Material	Hypereutectic Aluminum
Crankshaft Material	Cast Iron
Carburetor Included	Yes
Intake Manifold Included	Yes
Distributor Included	Yes
Connecting Rod Material	Forged Steel
Valve Covers Included	Yes
Engine Balance	Internal/External
Cylinder Heads Included	Yes
Rear Main Seal Style	1-piece
Throttle Body Included	No
Timing Cover Included	Yes
Oil Pan Included	Yes
Water Pump Included	Yes
Harmonic Balancer Included	Yes
Flexplate Included	No
Flywheel Included	No
Air Cleaner Included	Yes
Spark Plugs Included	Yes
Spark Plug Wires Included	Yes
Computer Included	No
Wiring Harness Included	No
Spark Plug Style	Straight

GENERAL
Torque	371 ft./lbs.
Horsepower	341 horsepower
Combustion Chamber Volume	64cc
Camshaft Duration (.050 in)	202° intake / 212° exhaust
Camshaft Lift (in)	.477 intake / .471 exhaust
Bore x Stroke (in)	4.000" x 3.480"
Warranty	30 month / 50,000 miles
Assembled	Yes
Cylinder Head Style	Assembled
Intake Runner Volume	195cc
Intake Valve Diameter	2.02"
Exhaust Valve Diameter	1.6"
Carburetor Quantity	One
Block	4 bolt main
GTIN Code	887753800749
Sold in Quantity	Each
