Zoomed In Image
Part # 9109531
$8,690.99
kit
Call to Order
Add to Buildlist
Compare
Details
What's In The Kit
Reviews
Q&A
Videos & Articles
  • Includes Mustang II front spindles/disc brakes/rack and pinion steering with Ford 9" Posi rear end
  • Complete chassis assembly for 1/2 ton GM trucks only
  • Replicates shape and dimensions of original Chevy frame
  • Welded on a rail fixture to ensure proper shape
  • Completely bolt in cross member for 1947-54 Chevy/GMC trucks - no welding required

Build Your Kit

You're almost there! This kit has an option or two for you to select. Let us know which options you want for your new kit.
Item 1 of 2
Replacement Springs for Mustang II Coilovers
Replacement Springs for Mustang II Coilovers
Quantity: 2
Item 2 of 2
Mustang II Power Steering and Manual Rack & Pinions
Mustang II Power Steering and Manual Rack & Pinions
Quantity: 1
Next
Add to Cart

Details

Spindle Type:
Stock Height
Sold in Quantity:
Kit

Info

As featured on our 1952 Chevy Pickup for Classic Truck’s Week to Wicked. Watch the transformation here!

Kit Includes:

  • (1) 1947-1954 Chevy 1/2 Ton Pickup Truck Frame Rails Kit with Crossmembers and Support Rails
  • (1) 1947-54 Chevy Pickup Motor Mounts for Bolt-In IFS
  • (1) 1947-1954 1/2 Ton Chevy/GMC Pickup Power Brake Pedal Assembly
  • (1) Speedway 1947-54 Chevy Truck 4-Link Rear Suspension Kit
  • (1) 1947-54 4-Link 9 Inch Housing with Brackets
  • (1) Speedway Ford 9 Inch Posi Traction 3rd Member Assembly, 31 Spl, 3.50
  • (2) Currie 9 Inch Ford 31 Spline Axle Shafts
  • (1) Heidts SB-054 Mustang II Stabilizer Sway Bar Kit
  • (1) Bolt-In 1947-54 Chevy Pickup Mustang II Crossmember
  • (1) Set of Standard Tubular Control Arms
  • (2) Sets of Coilover Shocks with Springs
  • (1) Pair of Stock Spindles
  • (1) Mustang II Coil Spring Ride Height Adjuster Kit
  • (1) Mustang II Power or Manual Rack & Pinion
  • (1) GM Metric 11 Inch Disc Brake Kit



Frame Kit

  • Laser cut from 7-gauge steel plate
  • Replicates shape and dimensions of original Chevy frame
  • Welded on a rail fixture to ensure proper shape
  • Ground and sanded to prep for finishing
  • For '47-'54 1/2 pickups
  • Bolt in lower radiator support to replace your rusted or missing original
  • Ideal replacement to avoid trimming your original for steering rack clearance
  • Tubular steel bolt-together assembly – no welding required
  • Laser cut from 11-gauge steel plate
  • Bolt-in boxing plates add strength to frame
  • Provides extra mounting options for fuel tank and exhaust

Parts List (PDF)

NOTE: Finish will be plain steel, not powder coated as shown.



Motor Mounts

  • Small Block Chevy bolt-in motor mounts for use with Speedway 47-54 Chevy Pickup Mustang II Bolt-In Crossmember
  • Kit includes steel frame mounts, steel engine mounts, rubber cushion set, and all hardware



Brake Pedal Assembly

  • Allow you to easily install power brakes on your 1947-1954 half ton Chevy and GMC truck
  • Will NOT work in conjunction with the factory clutch pedal
  • Intended for use with an auto transmission



Spindles

  • Heat treated forged steel spindle that retains stock factory geometry
  • Direct replacement for 1974-1980 Pinto/Bobcat and 1974-1978 Mustang II
  • Uses all stock rotors, bearings, calipers, etc
  • Stock height



Coilover Shocks with Springs

  • For unmatched ride quality for the street and strip, turn to QA1’s Mustang II Coil-Over Shocks
  • Stock appearance
  • Steel Body
  • Simple bolt-in installation
  • Coil-Over Capable
  • Adjustable ride height
  • Mount is Stock 7/16" I.D. Bolt Hole, Bushing
  • Chrome silicon spring material
  • 8 1/8" free length
  • Polished & chrome plated finish
  • Choose your desired spring rate



Calipers

  • Stock replacement single piston Metric calipers
  • Standard equipment on 1978-88 GM mid-size cars (Cutlass, Grand Prix, Regals, Monte Carlo, etc.)
  • Feature a 2.375" single piston, shielded bottom inlet
  • Will save 3-1/2 lbs. per side compared to mid-size 1969-1977 caliper
  • No core charge required
  • 7/16"-20 inlet
  • 5-1/2" Mount Spacing
  • Utilizes GM metric style D154 brake pads



Brake Pads

  • Speedway soft brake pad for GM Metric 1978-Up

Tech Tip:  Only use full metallic pads on coated rotors.

Learn how to properly Bed-In your brake pads by reading our tech article.  Bedding-In Brake Pad Procedure.



Rotors

  • Vented stock 11" diameter brake rotors for 1974-1980 Mustang II, Pinto, or Bobcat spindles (or popular GM Metric calipers and brackets)
  • Brake rotors are new, not plugged or re-drilled
  • Has a 5 on 4-3/4" bolt pattern with corresponding 7/16" diameter fine thread wheel studs
  • 5 on 4.75" Bolt circle
  • Granada type rotor



Control Arms

  • Stock Width
  • For Coil-Over Shock
  • Upgrade to a cleaner looking control arm
  • Full .120" wall, 1" diameter fixture welding tubing
  • Features screw-in ball joints and no-squeak bushings
  • Works with nearly any stock or aftermarket crossmember
  • Welding may be required on some applications
  • Designed to correspond with coil-over style springs and shocks
  • Works with Mustang II crossmembers that come without lower A-Arm tabs
  • Non-strut rod applications



Crossmember

Our bolt-in Mustang II suspension kit for 1947-1954 Chevy half-ton and 3/4 ton pickups includes all hardware and instructions.

  • Completely bolt in - no welding required
  • Based on proven Mustang II geometry
  • Complete with bolt in boxing plates to reinforce the frame
  • Interlocking design for ultimate strength
  • Threaded adjusters to fine tune ride height
  • Full lower A-arms required with this crossmember (strutless type)
  • Requires the use of a power rack and pinion and tubular control arms
  • NOT for use with air ride

Parts List (PDF)

Note:  Use bolt-in motor mount kit 910-54754 to mount your S/B Chevy.



Sway Bar

  • For 1947-54 Chevy pickups
  • Includes urethane mount and end-link bushings
  • For use with tubular arms that include end link mounting tabs
  • Hardware included
  • Used in conjunction with standard width lower control arms



Steering Rack

  • Fits aftermarket Mustang II crossmembers
  • Available in manual or power steering
  • Mount bushings are included with the Power version, but mount bushings are NOT included in the Manual version

MANUAL:

  • New manual rack and pinion steering assembly for Pinto/Bobcat/Mustang II based front suspensions in street rods and kit cars
  • 9/16"-26 spline input shaft
  • 16" mount centers
  • We suggest the Sweet brand u-joint 910-3247 or 910-3227
  • The Unisteer U-joint tends to run big on this joint
  • Features 14mmx1.5 thread for inner rack extensions, # 910-34345-MAN suggested

POWER:

  • New power rack modeled from the 1982-88 T-bird design which will work with aftermarket Mustang II crossmembers
  • Bushings included
  • (Can be used with a Saginaw GM power steering pump without any additional valves or inline pressure regulators)
  • Overall width is 45-1/8" with 15-1/2" mount centers
  • Must use offset bushings (910-34342) to mount to original Mustang II crossmembers
  • 3/4"-36 spline input shaft
  • Uses 910-4047 -6AN adapter fittings
  • Rack has 9/16"-18 female o-ring high pressure inlet and 5/8"-18 female o-ring low pressure outlet return line threaded ports
  • Replacement sku for rack and pinion hard lines is 910-35344



Speedway 1947-54 Chevy Truck 4-Link Rear Suspension Kit

  • Allows the do-it-yourself rodder to use the rear end of their choice
  • Modern geometry and handling
  • Chromoly four bars with urethane bushings
  • Bolt-on frame brackets and shock crossmember
  • The length of the upper bars is 16" eye to eye
  • The length of the lower bars is 21.5" eye to eye
  • 1/2 ton chassis application only
  • Kit will locate rear axle centerline in the original factory housing center line, and as such, it retains the original wheel base and the tire/wheel will not be centered in the fender opening as they will be located in the original factory location.

NOTE: Finish will be plain steel, not powder coated as shown.



Speedway Ford 9 Inch Posi Traction 3rd Member Assembly, 31 Spl, 3.50

  • Hand-assembled by our trained technicians for an unbeatable combination of quality and value
  • Track-tested durability in our own cars – we race what we sell
  • Precision assembly for the correct backlash, preload, and proper amount of pinion shims to ensure the correct pattern on the ring gear teeth
  • Ring and pinion gears of 8620 cold-rolled steel for long wear
  • Nodular iron housing is stronger than OEM “gray” iron and has 4 lbs of additional reinforcement
  • Large bearing “Daytona” style pinion bearing supports for strength and reliability
  • Spacer and shim setup maintains critical pinion depth settings and easier to service than traditional crush sleeves
  • Richmond Powertrax Grip Pro spiral gear differential gives positive traction without the noise of a full locker
  • Ring gears assembled with Grade 9 hardware, 15% stronger in tensile strength than Grade 8
  • Viton® pinion seal, resistant to chemicals and high temperatures
  • Grade 8 Carrier cap bolts
  • Lock-style pinion nut with pre-applied Loctite®
  • Grade 5 pinion support bolts
  • Includes form fitted, reusable red poly storage case



Currie 9 Inch Ford 31 Spline Axle Shafts

  • This custom cut and splined Currie Enterprises axle shaft is for Speedway housing 91046260 or 91047258 and other 9" Ford rearends
  • Works with New Big Ford (Torino) bearing ends
  • Flanges are dual-drilled for both 5 on 4-1/2" Ford/Mopar and 5 on 4-3/4" GM wheel bolt patterns
  • Induction heat treated 1541 forged alloy
  • 31-spline
  • 2.5" brake space offset



Notes

Spindles

  1. The Mustang II spindle has been used in street rod applications for years. As such, many brake kits have been developed for them. One can get kits with rotors of 9-1/2", 10", 10-1/2" or 11".
  2. Caliper choices are full size GM, orginal Ford, GM Metric or Wilwood. Bolt patterns are available in 5 x 4-1/2", 5 x 4-3/4", and 5 x 5".
  3. The biggest brake kit we offer for this spindle is #91031943, with 1969-1972 Chevelle 11" rotors, full size calipers and standard Chevy 5 x 4-3/4" bolt pattern.



Control Arms

Why go with tubular control arms? The most obvious reason is the looks. Tubular control arms and strut rods give your hot rod a much cleaner and hi-tech appearance than the stock type do. Another bonus is that the tubular control arms are available in 5/8" narrower than stock, which helps tuck the wheels up under the fenders without having to buy expensive special offset wheel. When using 5/8" narrower control arms, 1" must be removed from each inner tie rod end.



Crossmember

This bolt in unit is ONLY made to fit a 47-54 Chevy 1/2 ton and 3/4 Pickup chassis. Inside dimension at axle centerline is 23-1/2", outside is 28". This frame is slightly tapered to the front. Standard MII spindles will set pin at 1/2" below frame rail and 2" drop will set it at 1-1/2" above. Track width is standard 56-1/2" depending on which brake kit is used.



Steering Rack

  1. The Power Steering unit has 5/8" and 9/16" O-ring style ports. If you have an inverted flare fitting on your existing lines, that will not work.
  2. The Power Steering unit can be used with our standard GM pumps 91032922-GM, 91032908-BLK & -CHR, and with hose kits 910-32535 and 617-4835.
  3.  Applicable Bump Steer Kit # 721-BAX102 now available when application may require.



Proper Break-In Procedure for Steel or Cast Iron Rotors

New steel/iron rotors should be bedded in before being used in racing conditions. Proper bedding will prepare the rotor surface, prolong the rotor's life, and make it more resistant to thermal checking or cracking under severe braking conditions. The following procedures should be performed when bedding in both steel and cast iron rotors. It is best to bed in a new rotor using a used set of pads, preferably ones which will not create heat rapidly. Generating heat too rapidly will thermal shock the rotors. Likewise, when bedding in a new set of brake pads it is best to perform the process on a used rotor. This new/used bedding process permits controlled bedding of each individual component.

Make sure rotor surfaces are free from oils, grease, and brake fluid. Run vehicle up to a moderate speed and make several medium deceleration stops to heat up the rotor slowly. This will help reduce the chance of thermal shock caused by uneven heating of the rotor. Pull into the pits and allow the rotor to cool to ambient air temperature. Care should be taken not to ride the brakes into the pits as this may hot spot the rotor causing premature wear to the surface or structural damage.



3rd Member

Because there are no friction plates, no friction modifier additive is necessary.  Always use a 80W-90 weight petroleum based gear oil with a GL-5 (or higher) rating, friction additive/modifiers should NOT BE USED.  Synthetic oils and oils containing friction modifiers are not recommended.

Gear lube recommendations :

910-44090 - For street and every day driving under normal conditions



Axles

When utilizing an aftermarket axle with disc brake conversion kits, it may be necessary to reduce the diameter of the axle flange to a diameter necessary to adequately fit inside the required Clearance I.D. that the brake hat/brake rotor will require.  (see above diagram for illustration)



Charts

AFCOILS® Spring Rate Guide (Link)

Coil-Over Mounting Guide (Link)

Coil Over Mount Illustration (Link)

3rd Member Instructions (PDF)

How to Measure Your Housing (JPG)

4-Link Suspension Instructions (PDF)

910-34307 Instructions (PDF)

Brake Pad Brand Guide (Link)

910-35335 Tubular Lower Control Arm Instructions (PDF)

910-35320 Tubular Upper Control Arm Instructions (PDF)

Tubular Control Arms Application Chart (GIF)

Tubular Control Arm Chart (GIF)

Mustang II Manual Rack Bolt Kit Installation Instructions

910-44754 Instructions (PDF)

Spring Rate Chart (Link)

916-04754 Instructions (PDF)

910-14754 Instructions (PDF)

910-54754 Instructions (PDF)

910-64754 Instructions (PDF)

910-84754 Instructions (PDF)



Warranties

Coil Springs

AFCOILS® springs are manufactured using the finest spring material available. They are designed for extended life and consistent performance. They are guaranteed to do the job for which they are designed for as long as they are owned by the original purchaser.

AFCO will replace any AFCOILS® spring that ever exceeds the maximum allowable 2% loss of free height from original nominal specification. One way freight is included.

  1. Guarantee applies to original retail purchaser only.
  2. Damaged springs not covered by warranty.
  3. Spring must be returned to AFCO freight prepaid along with a copy of the original invoice.
  4. No other warranty, either expressed or implied, applies to AFCOILS® springs.

(Warranty not valid without invoice.)



3rd Member

No warranty is offered or made for durability or specific performance. No warranty is offered for commercial, off road, street performance, or racing use.



Important Messages

  • This item 9109531 is made to order. It will be shipped from our warehouse when it is produced.
Some parts are not legal for use in California or other states with similar laws/regulations

What's In The Kit

Each kit from Speedway Motors is carefully packaged and delivered right to your door. Below is a list of all the items you should expect to receive when you order this kit. Some of these items may also be available for sale individually if you're here looking for replacement parts.
  • 1947-1954 Chevy 1/2 Ton Pickup Truck Frame Rails
    Qty x 1
  • Radiator Support Brace for 1947-54 Chevy Pickup
    Qty x 1
  • Bolt-In 1947-54 Chevy Pickup Mustang II Crossmember
    Qty x 1
  • 1947-54 Chevy Pickup Motor Mounts for Bolt-In IFS
    Qty x 1
  • Bolt-In 1947-54 Chevy Pickup Center Chassis Crossmember
    Qty x 1
  • Rear Fuel Tank Brace for 1947-54 Chevy Pickup Truck
    Qty x 1
  • AFCO 23250CR 10 Inch Extreme Chrome Coil-Over Spring, 250 Rate
    Qty x 2
  • 1947-54 4-Link 9 Inch Housing with Brackets
    Qty x 1
  • 1947-54 4-Link Chassis Bracket, Left
    Qty x 1
  • 1947-54 4-Link Chassis Bracket, Right
    Qty x 1
  • Upper Link 4-Bar, '47-'54
    Qty x 2
  • Lower Link 4-Bar, '47-'54
    Qty x 2
  • Shock Mount Crossmember
    Qty x 1
  • Front Lower Left Bracket 4-Link
    Qty x 1
  • Front Lower Right Bracket 4-Link
    Qty x 1
  • 1947-1954 1/2 Ton Chevy/GMC Pickup Power Brake Pedal Assembly
    Qty x 1
  • Hardware Kit 4-Bar, '47-'54
    Qty x 1
  • 1947-54 Chevy Pickup Truck Bolt-in Transmission Crossmember
    Qty x 1
  • Speedway Mustang II Stock-Height Steel Spindles
    Qty x 1
  • QA1 MS303 Front Pro Coil single adj. Mustang II Mount Shock
    Qty x 2
  • Replacement Springs for Mustang II Coilovers
    Qty x 2
  • QA1 Pin Cross 0.750" O.D.
    Qty x 2
  • Mustang II Power Steering and Manual Rack & Pinions
    Qty x 1
  • Speedway Mustang II Steering Rack & Pinion Mounting Bushing
    Qty x 2
  • Mustang II Outer Tie Rod End, Manual Version
    Qty x 2
  • Pinto-Mustang II Spindle Nut & Washer Kit
    Qty x 1
  • GM Metric Caliper Bracket Set for Mustang II Spindle
    Qty x 1
  • IMCA Approved 1978-88 GM Metric RH Brake Caliper, 7/16-20 Inlet
    Qty x 1
  • IMCA Approved 1978-88 GM Metric LH Brake Caliper, 7/16-20 Inlet
    Qty x 1
  • Speedway Soft Street Brake Pads, GM Metric 1978-Up D154
    Qty x 1
  • 11 Inch Mustang II Rotor with GM 4.75 Inch Bolt Circle, Metric Caliper
    Qty x 2
  • Bearing-Seal Kit for Two Mustang II Brake Rotors
    Qty x 1
  • Speedway Mustang II Tubular Lower A-Arms for Coilovers, No Strut Rod
    Qty x 1
  • Speedway Mustang II Upper Control Arm T-Bolts
    Qty x 1
  • Mustang II Rack & Pinion Bolt Kit
    Qty x 1
  • 9/16 Inch Fine Thread Tie Rod Nuts
    Qty x 1
  • Speedway Mustang II Coil Spring Rubber Isolator Cushion
    Qty x 1
  • Mustang II Rack & Pinion Bolt Kit - For Use With Rack Spacers
    Qty x 1
  • Mustang II Rack Spacer, 3/4 Inch
    Qty x 2
  • Speedway Mustang II Tubular Upper Control Arms, Stock Width, Pair
    Qty x 1
  • Front Disc Brake Hardware Kit
    Qty x 1
  • Heidts SB-054 Mustang II Stabilizer Sway Bar Kit, 47-54 Chevy Pickup
    Qty x 1
  • QA1 US304 Adjustable Shock and Coilover Kit w/o Spring, 11 Inch
    Qty x 2
  • Speedway Ford 9 Inch Posi Traction 3rd Member Assembly, 31 Spl, 3.50
    Qty x 1
  • Currie CE-98132-30625 9 Inch Ford 31 Spline Axle Shaft, 30-5/8 Inch
    Qty x 1
  • Currie CE-98129-28250 9 Inch Ford 31 Spline Axle Shaft, 28-1/4 In
    Qty x 1
  • 9 Inch Ford Rearend Axle Housing 3rd Member Pumpkin Gasket
    Qty x 1

Reviews

Q & A

Articles
  • Visit the Toolbox

    The Toolbox is Speedway Motors' hub for professionally written articles.

  • When it comes to a traditional style build on an early hot rod it just has to be rolling on a solid front axle of some sort. In this buyer's guide we take you through I-beam and round tube solid axles, spindle choices, radius rod needs, and more.

You May Also Like

Error
X
Note
X
Ok
