Edelbrock 1107 1949-1953 Ford Flathead Single 4-Barrel Intake

Edelbrock 1107 1949-1953 Ford Flathead Single 4-Barrel Intake
Carbureted Fuel System Type, Dual Plane Intake Manifold Type, One Carburetor Quantity, Natural
On Backorder
Ships FREE
STORE PICKUP
Availability
Store Pickup Availability
X
Lincoln, NE -
Phoenix, AZ -
Select Vehicle



Edelbrock 1107 1949-1953 Ford Flathead Single 4-Barrel Intake
X


Details
Reviews
Q&A
Videos & Articles
- It comes drilled for the early Carter WCFB carb
- Specifically designed for the 1949-1953 Ford Flathead V8
- Intake includes an adapter to accept modern 4 barrel carbs
- Features an all aluminum construction with a natural finish
- Engineered to allow the use of square-bore carbs such as the Edelbrock Performer Series or Thunder Series AVS 500 cfm on the Ford Flathead engine
Details
Fuel System Type:
Carbureted
Intake Manifold Type:
Dual Plane
Carburetor Quantity:
One
Carburetor Flange Type:
4-Barrel Square Bore
Material Type:
Aluminum
Finish:
Natural
Gaskets Included:
No
Overall Height:
6.06"
Port Height:
1.70"
Port Width:
1.30"
Bolt Hole Pattern:
5.160" x 5.625"
MFG. Part #:
1107
Sold in Quantity:
Each
GTIN Code:
085347011070
Info
This manifold allows the use of square-bore carbs such as the Edelbrock Performer Series or Thunder Series AVS 500 cfm on the Ford Flathead engine. This is a reproduction of the vintage Edelbrock #452 two-piece manifold with a new carb adapter flange.
- Includes an adapter to accept modern 4 barrel carbs.
- Comes drilled for the early Carter WCFB carb
- 1949-1953 Ford Flathead
- Dual Plane
Note: The Edelbrock single 4-barrel intake is drilled for the early ’50s small Carter WCFB carb-mounting pattern, so an adapter is mandatory with a Holley carb, even if you don’t have other linkage- or choke-clearance issues.
Notes
Carburetor Recommendations: Edelbrock Performer Series carb, 500 cfm; 3251404 manual choke or 3251403 electric chokeInstallation Notes:
- Recommended intake gasket: Fel-Pro #MS2853
- Manifold height: A-4.06", B-6.06"
- Port exit dimensions: 1.3" x 1.7"
