COMP Cams CL12-223-4 Magnum Solid Camshaft Kit, Chevy S/B

#282CL122234

COMP Cams CL12-223-4 Magnum Solid Camshaft Kit, Chevy S/B

Name: COMP Cams CL12-223-4 Magnum Solid Camshaft Kit, Chevy S/B
Brand: COMP Cams
SKU: 282CL122234
Price: 456.95 USD
Availability: InStock

Write a Review

Ask a Question

Duration:

282/282 (Base Kit)

294/294 (Base Kit)282/282 (Deluxe Kit)

$456.95

/each

Factory Shipped

Quantity

Need Help? Call to Order

Add to a list

Select an engine to verify Fitment

Select Engine

Product Summary

Solid Flat Tappet Camshaft Type, 2000 to 6000 RPM Range

See more details

Key Specs

Camshaft Type	Solid Flat Tappet
Intake Duration (.050" Lift)	236
Exhaust Duration (.050" Lift)	236
RPM Range	2000 to 6000
Lobe Separation	110 °

See more specs

Need To Know

Need help?

855.313.9176

View the Help Center

Quick and Easy Returns

Return Policy

COMP Cams CL12-223-4 Details

CL12-223-4 - Cam and Lifter Kit, CS 282S.

Chevrolet 262-400 c.i. 8 cyl. 1955-1998. Solid-Good power for street, choppy idle. Needs stall, likes headers and low gears. All COMP Cams Camshafts are manufactured to the strictest tolerances. Rigorously tested and checked for quality.

Great high RPM power
Easy on valve train parts
Can be used with mild ratio rocker arms & traditional performance valve springs
Best with aftermarket converter & 9.5:1+ compression

Application

1958-2002 Chevy 262-400

Guides & Documents

Warranty (COMP Cams)

CARB Warning

For race/ off road use only

Emissions warning: this part only legal for sale or use in California for racing (competition) vehicles which may never be used, registered, or licensed for use upon a public highway. Any other use renders the vehicle tampered and not legal for use on California public highways (any public street or roadway, public dirt road, public park, or publicly maintained right of way open to the use of the public for vehicular travel). Violations subject to $37,500 penalty per violation per vehicle, revocation of registration, loss of use on California public right of ways, and proof of correction for tampering. There are similar restrictions and penalties under federal law and the laws of all other states with penalties under federal law of up to approximately $45,268 per tampered vehicle and/or engine.

CA WARNING:

Can expose you to lead, a carcinogen and reproductive toxicant. See www.P65Warnings.ca.gov

CARB warning

COMP Cams CL12-223-4 Specifications

KEY SPECS
MFG. Part #	CL12-223-4
Brand	COMP Cams
Camshaft Type	Solid Flat Tappet
Intake Duration (.050" Lift)	236
Exhaust Duration (.050" Lift)	236
RPM Range	2000 to 6000
Lobe Separation	110 °
Lifter Type	Mechanical/Solid Flat Tappet

GENERAL
Intake Valve Lift w/ Rocker Arm Ratio	0.495"
Exhaust Valve Lift w/ Rocker Arm Ratio	0.495"
Sold in Quantity	Kit
Intake Duration	282
Exhaust Duration	282
GTIN Code	036584450276
Grind Number	CS 282S-10
Intake Valve Lash	0.022
Exhaust Valve Lash	0.022
External Ignition Box Required	No
Valve Springs Required	Yes
Valve Spring Included	No
Lifters Included	Yes
Retainers Included	No
Locks Included	No
Valve Stem Seals Included	No
Timing Chain and Gears Included	No
Assembly Lubricant Included	Yes
Pushrods Included	No
Rocker Arms Included	No
Gaskets Included	No

Ratings & Reviews

Be the first to write a review.

Questions & Answers

Be the first to ask a question.

Fitment

1967-1969 Chevy Camaro

Gen 1 DZ Small Block Chevy

1980-1981 Chevy Camaro

2-Piece Rear Main Chevy 267

1980-1982 Chevy Caprice

2-Piece Rear Main Chevy 267

1962-1963 Chevy Corvette

Gen 1 L76 Small Block Chevy

1979-1982 Chevy El Camino

2-Piece Rear Main Chevy 267

1980-1982 Chevy Impala

2-Piece Rear Main Chevy 267

1979-1982 Chevy Malibu

2-Piece Rear Main Chevy 267

1979-1982 Chevy Monte Carlo

2-Piece Rear Main Chevy 267

1960-1967 GMC Suburban

Gen 1 L76 Small Block Chevy
