Product Summary

Deluxe Crate Engine Crate Engine Type, Oil Pan Included

  • HP & Torque: 815 HP / 775 FT LBS
  • Compression Ratio: 11.0:1
  • Aluminum Heads
  • Hydraulic Roller Cam
  • Forged Crank & Forged Pistons
See more details

Key Specs

Crate Engine TypeDeluxe Crate Engine
Compression Ratio11.0:1
Engine Displacement632 cu. in.
Camshaft TypeHydraulic Roller
Cylinder Head MaterialAluminum
See more specs

Need To Know

Made to Order

This custom item will ship when completed

Truck Shipment

Truck shipments must be pre-paid with a credit card, certified check or money order

Quick and Easy Returns

Return Policy

BluePrint Engines PS6320CTCKB Details

32 CI ProSeries Stroker Crate Engine | Big Block GM Style | 10.3L | Drop In Ready - Black

  • HP & Torque: 815 HP / 775 FT LBS
  • Compression Ratio: 11.0:1
  • Aluminum Heads
  • Hydraulic Roller Cam
  • Forged CrankForged Pistons


BLOCK:
NEW BluePrint Cast Iron Block
Manufactured and Machined in the USA!
4-Bolt Main
4.600"
1-Piece Rear Main Seal
Mech fuel pump provision: Yes
Tall Deck

ROTATING ASSEMBLY:
New BluePrint Forged Crankshaft
4.750" Stroke
Forged H-beam 6.635" connecting rods
Forged Pistons
Internal

CYLINDER HEADS:
BluePrint Aluminum Cylinder Heads -PS8012
119cc chamber
2.30" intake/1.88" exhaust valves
358cc intake/125cc exhaust runners

CAM SPECS:
Cam Type: Roller
.698 Intake .698 Exhaust
272 Intake / 282 Exhaust duration
@ .050 - 110 degree lobe separation

ALSO INCLUDES:
Polished Pulley kit with Alternator, A/C and Power Steering
Carburetor
Aluminum, single plane intake manifold
MSD Pro Billet distributor
Valve covers, oil pan and timing cover
spark plugs
spark plug wires
Harmonic balancer
Dyno test results shipped with engine

Charts

CARB Warning

Follow EPA, CARB, and state regulations for engine changes

Emissions warning: this part is for vehicle engine changes, not direct oem engine replacements. In California, engine changes are legal when done in compliance with California bureau of automotive repairs (bar) engine change policy. For assistance, call bar referee at: (800) 622-7733. And see https://bar.Ca.Gov/consumer/smog_check_program/engine_changes. All customers must comply with federal epa mobile source enforcement memorandum no. 1a (and addendum) and all applicable state regulations when conducting engine changes. Improper installation and/or use of this part in California may subject the installer and/or owner to a $37,500 penalty per violation per vehicle, revocation of registration, loss of use on California public right of ways, and proof of correction for tampering. There are similar restrictions and penalties under federal law and laws of all states for use of this engine change part on makes or models of vehicles that render them noncompliant with applicable state and/or federal emission laws with penalties under federal law of up to approximately $45,268 per tampered vehicle and/or engine

BluePrint Engines PS6320CTCKB Specifications

KEY SPECS
MFG. Part #PS6320CTCKB
BrandBluePrint Engines
Crate Engine TypeDeluxe Crate Engine
Compression Ratio11.0:1
Engine Displacement632 cu. in.
Camshaft TypeHydraulic Roller
Cylinder Head MaterialAluminum
Piston MaterialForged Aluminum
Crankshaft MaterialForged
Carburetor IncludedNo
Intake Manifold IncludedNo
Distributor IncludedNo
Valve Covers IncludedYes
Engine BalanceInternal
Cylinder Heads IncludedYes
Rear Main Seal Style1-piece
Throttle Body IncludedNo
Timing Cover IncludedYes
Oil Pan IncludedYes
Water Pump IncludedNo
Harmonic Balancer IncludedNo
Flexplate IncludedNo
Flywheel IncludedNo
Air Cleaner IncludedNo
Spark Plugs IncludedNo
Spark Plug Wires IncludedNo
Computer IncludedNo
Wiring Harness IncludedNo
GENERAL
Horsepower815 horsepower
Combustion Chamber Volume119cc
Camshaft Duration (.050 in)272° intake / 282° exhaust
Camshaft Lift (in).698 intake / .698 exhaust
Bore x Stroke (in)4.600" x 4.750"
Warranty30 month / 50,000 mile
AssembledYes
Block4 bolt main, 1 piece rear main seal
