$275 Shipping
$275 Shipping
|
#227PS6320CTCK
$19,799.00
/each
Factory Shipped
Quantity
Need Help? Call to Order
Add to a list
Select a vehicle to verify Fitment
Select Vehicle
Deluxe Crate Engine Crate Engine Type, Oil Pan Included
| Crate Engine Type | Deluxe Crate Engine |
| Compression Ratio | 11.0:1 |
| Engine Displacement | 632 cu. in. |
| Camshaft Type | Hydraulic Roller |
| Cylinder Head Material | Aluminum |
Made to Order
This custom item will ship when completed
Truck Shipment
Truck shipments must be pre-paid with a credit card, certified check or money order
Need help?
855.313.9176Quick and Easy Returns
Return Policy32 CI ProSeries Stroker Crate Engine | Big Block GM Style | 10.3L | Drop In Ready - Polished
BLOCK:
NEW BluePrint Cast Iron Block
Manufactured and Machined in the USA!
4-Bolt Main
4.600"
1-Piece Rear Main Seal
Mech fuel pump provision: Yes
Tall Deck
ROTATING ASSEMBLY:
New BluePrint Forged Crankshaft
4.750" Stroke
Forged H-beam 6.635" connecting rods
Forged Pistons
Internal
CYLINDER HEADS:
BluePrint Aluminum Cylinder Heads -PS8012
119cc chamber
2.30" intake/1.88" exhaust valves
358cc intake/125cc exhaust runners
CAM SPECS:
Cam Type: Roller
.698 Intake .698 Exhaust
272 Intake / 282 Exhaust duration
@ .050 - 110 degree lobe separation
ALSO INCLUDES:
Polished Pulley kit with Alternator, A/C and Power Steering
Carburetor
Aluminum, single plane intake manifold
MSD Pro Billet distributor
Valve covers, oil pan and timing cover
spark plugs
spark plug wires
Harmonic balancer
Dyno test results shipped with engine
Charts
Guides & Documents
Follow EPA, CARB, and state regulations for engine changes
CA WARNING:
Can expose you to lead, a carcinogen and reproductive toxicant. See www.P65Warnings.ca.gov
| KEY SPECS | |
|---|---|
| MFG. Part # | PS6320CTCK |
| Brand | BluePrint Engines |
| Crate Engine Type | Deluxe Crate Engine |
| Compression Ratio | 11.0:1 |
| Engine Displacement | 632 cu. in. |
| Camshaft Type | Hydraulic Roller |
| Cylinder Head Material | Aluminum |
| Piston Material | Forged Aluminum |
| Crankshaft Material | Forged |
| Carburetor Included | Yes |
| Intake Manifold Included | Yes |
| Distributor Included | Yes |
| Valve Covers Included | Yes |
| Engine Balance | Internal |
| Cylinder Heads Included | Yes |
| Rear Main Seal Style | 1-piece |
| Throttle Body Included | No |
| Timing Cover Included | Yes |
| Oil Pan Included | Yes |
| Water Pump Included | Yes |
| Harmonic Balancer Included | Yes |
| Flexplate Included | No |
| Flywheel Included | No |
| Air Cleaner Included | No |
| Spark Plugs Included | Yes |
| Spark Plug Wires Included | Yes |
| Computer Included | No |
| Wiring Harness Included | No |
| GENERAL | |
| Horsepower | 815 horsepower |
| Combustion Chamber Volume | 119cc |
| Camshaft Duration (.050 in) | 272° intake / 282° exhaust |
| Camshaft Lift (in) | .698 intake / .698 exhaust |
| Bore x Stroke (in) | 4.600" x 4.750" |
| Warranty | 30 month / 50,000 mile |
| Assembled | Yes |
| Block | 4 bolt main, 1 piece rear main seal |
