Key Specs

MFG. Part #
Wheel Diameter15 Inch
Width7"
Wheel Bolt Pattern (in.)5x4.75 in.
Wheel Bolt Pattern (mm)5x120.65 mm
See more specs

Need To Know

Quick and Easy Returns

Return Policy

Details

If you're an IMCA hobby stock or street stock racer, Bassett's collection of DOT-approved racing wheels are for you. They feature the same quality construction and high strength of Bassett's NASCAR certified wheel. Bassett DOT wheels are also the lightest on the market at just 19 lbs!

Since the wheels conform to the DOT specifications, they are legal for the street! When outfitting your car or truck with custom wheels, don't settle for lower quality knock-offs. Bassett Racing Wheels are race track tough.

Available in a 5 on 4-3/4" bolt circle pattern with a 1", 2", 2-1/2", 3" and 3-3/4" backspace. Chrome finish.

Learn more about determining the proper wheel offset, torque sequence, and bolt pattern for your application by reading our tech article. Racing Wheel Principles.

For offroad use only. The following must be considered when using Bassett wheels for on highway/street use when the wheel/tire assembly is being balanced. Bassett wheels are lug centric, which means they are built off of, and must be balanced using, the bolt circle and NOT the wheel center hole. Improper use of a tire balancer that centers the wheel on the hub bore, not the bolt circle, will result in an incorrect reading for rim runout as the center hole is not in the perfect center of the bolt pattern. The only machine capable of performing a lug centric balance is the Hunter GSP 9700 with the flange plate bolt circle adapter and no centering cone.

Specifications

KEY SPECS
MFG. Part #
BrandBassett
Garage Sale TypeCloseout
Wheel Diameter15 Inch
Width7"
Wheel Bolt Pattern (in.)5x4.75 in.
Wheel Bolt Pattern (mm)5x120.65 mm
Wheel Backspace
Wheel Material TypeSteel
Wheel Offset
Wheel Backspace Range
FinishChrome
ColorChrome
Beadlock IncludedNo
Material TypeSteel
Bolt Pattern5 on 4.75"
Diameter15"
GENERAL
Sold in QuantityEach
NotesDOT
DOT-ApprovedYes
Weight19 lbs.
Valve Stem IncludedNo
Lug Nut Seat Style45 Degree Conical
Center Cap IncludedNo
Lug Nuts IncludedNo
BeadlockNo
