#9174020
Aluminum Fan Shroud Kit for 22 Inch Radiator, Engine Driven Fan
- This universal aluminum fan shroud kit can be fit to a variety of applications and works perfect with a mechanical fan
- Includes fully-formed shroud of .063" lightweight aircraft aluminum
- 3" wide adjustable collar for 15" to 20" fan diameters
$95.99
/each
In Stock
Quantity
Need Help? Call to Order
Add to a list
Select a vehicle to verify Fitment
Select Vehicle
Product Summary
Universal Fit, 19.5" Overall Length, 2.5" Overall Width
- This universal aluminum fan shroud kit can be fit to a variety of applications and works perfect with a mechanical fan
- Includes fully-formed shroud of .063" lightweight aircraft aluminum
- 3" wide adjustable collar for 15" to 20" fan diameters
- Includes all the necessary hardware and mounting instructions
- Fan shroud box portion measures 19-1/2" tall, 16-3/4" wide, and 2-1/2" deep
Key Specs
| MFG. Part # | 9174020 |
| Brand | Speedway Motors |
| Overall Width | 2.5" |
| Overall Height | 16.75" |
| Material Type | Aluminum |
Need To Know
Need help?
855.313.9176Quick and Easy Returns
Return PolicySpeedway Motors 9174020 Details
Speedway Motors 9174020 Details
These universal fit aluminum fan shroud kits can be built to fit many applications with a belt-driven fan. The adjustable collar will accommodate 15"-20" fan diameters.
Measures outside spec of 19-1/2" tall x 16-3/4" wide x 2.5" deep with inside spec of 17-3/4" tall x 13" wide. Works well with Speedway & Afco 24" wide radiators and will work with the Speedway & Afco 22" wide radiators with slight trimming of the width of the shroud.
- Made for exact fit of many Muscle Car and Hotrod radiators
- Allows the installer the choice of off center, side-to-side and above the radiator fan positioning
- For crossflow or downflow radiator mounting
- Includes fully-formed shroud of .063" lightweight aircraft aluminum
- 3" trimmable collar
- Adjustable collar; adjusts for 15-20" fan diameters
- Includes all the necessary hardware and mounting instructions
- Outside measures 19.5" tall x 16-3/4" wide x 2.5" deep
- Inside measures 17-3/4" tall x 13" wide
Learn more about the importance of using a fan and shroud with our radiators by reading our tech article. Radiator Cooling Performance.
Charts
Guides & Documents
Speedway Motors 9174020 Specifications
Speedway Motors 9174020 Specifications
| KEY SPECS | |
|---|---|
| MFG. Part # | 9174020 |
| Brand | Speedway Motors |
| Overall Width | 2.5" |
| Overall Height | 16.75" |
| Material Type | Aluminum |
| GENERAL | |
| Overall Length | 19.5" |
| Notes | ALUMINUM FAN SHROUD 19.5" TALL X 16 3/4" WIDE x 2.5" thick |
| Sold in Quantity | Each |
Ratings & Reviews
3
4 Reviews
Overall, customers appreciate the affordability and fit of our product. It is praised for its good value for money and suitable fitting. However, some customers indicate that modifications may be required for certain uses, emphasizing the need for precise dimensions before purchasing to avoid difficulties. Even with this, they are likely to purchase again, reflecting the product's high quality compared to competitors. Negative comments referred to a lack of compatibility with certain items, but these may be specific use cases.
Ratings & Reviews
3
4 Reviews
Overall, customers appreciate the affordability and fit of our product. It is praised for its good value for money and suitable fitting. However, some customers indicate that modifications may be required for certain uses, emphasizing the need for precise dimensions before purchasing to avoid difficulties. Even with this, they are likely to purchase again, reflecting the product's high quality compared to competitors. Negative comments referred to a lack of compatibility with certain items, but these may be specific use cases.
3
4 reviews
5
1
4
1
3
0
2
1
1
1
Filter by Ratings
I would use it again
4.0
6 years ago
Mason
Santa Fe nm
Verified
Good product for the price
Would Recommend
vary good and I wood by it a gen
5.0
8 years ago
tom
EL DORADO CA
Verified
it fit good
Would Recommend
Get actual dimensions before ordering
1.0
9 years ago
Dave
Florida
Verified
Took a ton of modification and welding to make this right for my street rod 1930. I took a leap of faith based upon description . Big mistake. None of the shrouds of this sort have actual drawings with sizes.
Would Not Recommend
Bad
2.0
10 years ago
Billy
Hueytown al
Verified
Said would work great with 23 inch fm aluminum rag. No way would have t o highly modifier it . Not happy at all.
Would Not Recommend
Showing 4 of 4 reviews
Questions & Answers
Questions & Answers
2 Questions • 2 Answers
what are the pros and cons running or not running a shroud on a modified dirt race car , some guys I know run a shroud and some don't both seem the same temp , sometimes the no shroud option runs cooler?
by ripper
• 7 years ago
1 answer
View Answer
The product specs say 19.5" tall x 16 3/4" wide, but only 17 3/4 tall x 13" wide on the inside. Is that 13" inside dimension correct?? This says it will fit the 22" radiator, but not with that inside measurements listed. That would not even accommodate a 15" fan (??)
by David
• 7 years ago
1 answer
View Answer
2 of 2 questions shown
