Product Summary

Universal Fit, Firewall Position, Single Outlet Count

    Key Specs

    MFG. Part #260-13621
    BrandWilwood

    Need To Know

    Free Shipping on Orders Over $149

    Shipping Policies & FAQs

    Quick and Easy Returns

    Return Policy

    Details

    This new version of Wilwood’s Compact Combination Master Cylinders now features a 3/8-24 banjo outlet. Designed for limited space applications requiring the output capacity of a full size master cylinder. The ultra short 3.37”compact body provides 2.16” of additional clearance between the mounting flange and the fluid outlet. A full 1.12” of piston stroke meets or exceeds the stroke capacity of most full size cylinders. With 3/8-24 banjo fluid outlet port located at the top radius of the cylinder bore, reduces the chances for trapped air. Enhanced fluid inlet port allows mounting of the standard reservoir included in kit and also contains 11/16-20 internal threads for custom reservoir arrangements. The black E-Coated aluminum body resists corrosion and maintains a durable long lasting finish.

    • 7/8 Inch bore size
    • 1.12" stroke
    • .67 (cu in.) volume
    • 3/8"-24 banjo outlet
    • 11/16"-20 internal threads
    • Aluminum/plastic material
    • Remote reservoir

    Learn more about selecting the proper master cylinder for your vehicle by reading our tech article.Brake System Selection.

    Tech Tip: The bigger the master cylinder, the more fluid you get...But you'll have less pressure at the caliper.

    Charts

    Specifications

    KEY SPECS
    MFG. Part #260-13621
    BrandWilwood
    GENERAL
    PositionFirewall
    Brake System TypeDisc
    Outlet CountSingle
    Reservoir TypeRemote/Adjustable
    Master Cylinder Bore Size7/8 Inch
    Stroke1.12"
    Master Cylinder MaterialAluminum
    FinishEDP Coated
    ColorBlack
    Reservoir IncludedYes
    Reservoir MaterialABS Plastic
    Reservoir Size (cu in)18.0 or 12.6
    Fluid Capacity10.0 / 7.0 fl oz.
    Area0.6 sq. in.
    Volume0.67 cu. in.
    Outlet Fitting3/8"-24 Banjo
    Overall Length7.8"
    Mounted Length3.37"
    Sold in QuantityKit
    GTIN Code889545067330
