#83514017739D
$2,783.98
/each
Factory Shipped
Quantity
Need Help? Call to Order
Add to a list
Select a vehicle to verify Fitment
Select Vehicle
Front Position, 14 Inch Rotor Diameter, Powder Coated
| MFG. Part # | 140-17739-D |
| Position | Front |
| Rotor Diameter | 14 Inch |
| Rotor Type | Vented |
| Caliper Pistons | Six |
Need help?
855.313.9176Quick and Easy Returns
Return PolicyAERO6 Big Brake Front Brake Kit
AERO6 calipers were designed for the specific purpose of providing big capacity braking with large diameter rotors for heavy weight and extreme duty vehicles. For cars, it’s the biggest of the big providing big brake performance for show and dual purpose street and track vehicles. For trucks and SUV’s, it provides big stopping power for towing, off-road, and enhanced braking with wheel and tire upgrades. Kits listed for specific vehicles are fully compatible with OE master cylinder output and ABS function. Directional staggered vane 14.00” to 14.25”rotors provide maximum cooling for sustained high heat durability.Specs
Guides & Documents
WARNING:
Cancer and Reproductive Harm – www.P65Warnings.ca.gov
| KEY SPECS | |
|---|---|
| MFG. Part # | 140-17739-D |
| Brand | Wilwood |
| Position | Front |
| Rotor Diameter | 14 Inch |
| Rotor Type | Vented |
| Caliper Pistons | Six |
| Caliper Finish | Powder Coated |
| Parking Brake Provision | No |
| Minimum Recommended Wheel Diameter | 18 Inch |
| Rotor Shape | Round |
| Hardware Included | Yes |
| Rotor Style | Drilled & Slotted |
| Spindle Type | Factory Disc & Drum Spindles |
| Front Rotor Included | Yes |
| Front Rotor Diameter | 14 |
| Front Caliper Included | Yes |
| Rear Caliper Included | No |
| Front Spindles Included | No |
| Master Cylinder Included | No |
| Brake Booster Included | No |
| Brake Hoses Included | No |
| Rear Rotor Included | No |
| Color | Black |
| GENERAL | |
| Sold in Quantity | Kit |
| GTIN Code | 889545117981 |
| Rotor Thickness | 1.25" |
| Stud Diameter | 0.52" |
| Mount Type | Radial |
| OE Hub Offset | 0.33" |
| Total Piston Area | 5.4 sq. in. |
| Piston Type | Stainless |
| Pad Area | 11.1 sq. in. |
| Pad Volume | 5.2 cu. in. |
| Brake Pad Compound | BP-10 |
| Rotor Finish | Black E-Coat |
| Rotor Material Type | Spec-37 Iron |
| Vane Count | 72 Straight Vane |
| Hat Type | Big Brake Hat - Flared Bell |
| Hat Finish | Black E-Coat |
| Hub Material | Aluminum |
| Hat Material Type | Aluminum |
| Hat Offset Dimension | 1.1" |
| Front Rotor Thickness | 1.25" |
| Front Caliper Color | Black |
| Front Caliper Piston | Steel |
| Brake Lines Included | No |
| Front Rotor Style | Drilled and Slotted |
| Brake Pads Included | No |
| Caliper Color | Black |
| Caliper Material Type | Forged Aluminum |
| Brake Shoe Material | No |
| Drum Brake Pins Included | No |
| Drum Brake Springs Included | No |
| Hub Bolt Circle 1 | 5 x 4.50" |
| Hub Bolt Circle 2 | 5 x 4.75" |
| Hub Finish | Natural |
| Rotor Hat Material | Aluminum |
| Hat Bolt Circle 1 | 5 x 4.50" |
| Hat Bolt Circle 2 | 5 x 4.75" |
Be the first to ask a question.
1968-1970 Chevy Bel Air
1968-1970 Chevy Biscayne
1969-1970 Chevy Brookwood
1968-1970 Chevy Caprice
1969-1982 Chevy Corvette
1970 Chevy Estate
1968-1970 Chevy Impala
1969-1970 Chevy Kingswood
1969-1970 Chevy Townsman
