Product Summary

Front Position, 14 Inch Rotor Diameter, Powder Coated

  • Designed to fit OE Factory Spindles. Updates stock drum or disc spindles with modern, heavy-duty disc brakes.
  • 6 piston Calipers, Spec-37 Iron Vaned Rotors, Aluminum Flared Bell Big Brake Rotor Hats, Bare Aluminum Rotor Hats
  • Built for larger wheels.
See more details

Key Specs

MFG. Part #140-17739
PositionFront
Rotor Diameter14 Inch
Rotor TypeSolid
Caliper PistonsSix
See more specs

Need To Know

Quick and Easy Returns

Return Policy

Wilwood 140-17739 Details

AERO6 Big Brake Front Brake Kit

AERO6 calipers were designed for the specific purpose of providing big capacity braking with large diameter rotors for heavy weight and extreme duty vehicles. For cars, it’s the biggest of the big providing big brake performance for show and dual purpose street and track vehicles. For trucks and SUV’s, it provides big stopping power for towing, off-road, and enhanced braking with wheel and tire upgrades. Kits listed for specific vehicles are fully compatible with OE master cylinder output and ABS function. Directional staggered vane 14.00” to 14.25”rotors provide maximum cooling for sustained high heat durability.

Specs

Our rotors are machined and fully e-coated, just like the rotor hats. This is a protectant coating the prohibits surface rust from forming on the exposed surfaces. Once the parts are installed and being bedded in, the brake pad friction and caliper pressure will remove the coating at the spot the brake pads touch. This will expose the silver iron material underneath.

Wilwood 140-17739 Specifications

KEY SPECS
MFG. Part #140-17739
BrandWilwood
PositionFront
Rotor Diameter14 Inch
Rotor TypeSolid
Caliper PistonsSix
Caliper FinishPowder Coated
Parking Brake ProvisionNo
Minimum Recommended Wheel Diameter18 Inch
Rotor ShapeRound
Hardware IncludedYes
Rotor StyleSlotted
Spindle TypeFactory Disc & Drum Spindles
Front Rotor IncludedYes
Front Rotor Diameter14
Front Caliper IncludedYes
Rear Caliper IncludedNo
Front Spindles IncludedNo
Master Cylinder IncludedNo
Brake Booster IncludedNo
Brake Hoses IncludedNo
Rear Rotor IncludedNo
ColorBlack
GENERAL
Sold in QuantityKit
GTIN Code889545117974
Rotor Thickness1.25"
Stud Diameter0.52"
Mount TypeRadial
OE Hub Offset0.33"
Total Piston Area5.4 sq. in.
Piston TypeStainless
Pad Area11.1 sq. in.
Pad Volume5.2 cu. in.
Brake Pad CompoundBP-10
Rotor FinishBlack E-Coat
Rotor Material TypeSpec-37 Iron
Vane Count72 Straight Vane
Hat TypeBig Brake Hat - Flared Bell
Hat FinishBlack E-Coat
Hub MaterialAluminum
Hat Material TypeAluminum
Hat Offset Dimension1.1"
Front Rotor Thickness1.25"
Front Caliper ColorBlack
Front Caliper PistonSteel
Brake Lines IncludedNo
Front Rotor StyleSlotted
Brake Pads IncludedNo
Caliper ColorBlack
Caliper Material TypeForged Aluminum
Brake Shoe MaterialNo
Drum Brake Pins IncludedNo
Drum Brake Springs IncludedNo
Hub Bolt Circle 15 x 4.50"
Hub Bolt Circle 25 x 4.75"
Hub FinishNatural
Rotor Hat MaterialAluminum
Hat Bolt Circle 15 x 4.50"
Hat Bolt Circle 25 x 4.75"
