Product Summary

Front Position, 12.88 Inch Rotor Diameter, Black, Black

  • Updates stock drum or disc spindles with modern, heavy-duty disc brakes.
  • 6 piston Calipers, Spec-37 Iron Vaned Rotors, Aluminum Flared Bell Big Brake Rotor Hats, Bare Aluminum Rotor Hats
  • Built for larger wheels.
See more details

Key Specs

MFG. Part #140-17738
PositionFront
Rotor Diameter12.88 Inch
Rotor TypeSolid
Caliper PistonsSix
See more specs

Need To Know

Quick and Easy Returns

Return Policy

Wilwood 140-17738 Details

Forged Narrow Superlite 6R Big Brake Front Brake Kit (Hub)



FNSL6R billet Forged six-piston calipers with 13”-14” rotors deliver the ultimate combination for braking power and style in this group of kits engineered for traditional non-ABS spindles on American muscle cars and vintage rods. Built exclusively for 17” and larger wheels, SL6 kits enhance tire and suspension upgrades on all types of custom show and high performance dual-purpose street and track machines. A full range of options for caliper finishes and rotor designs are guaranteed to catch the eye of the most discriminating enthusiast while providing optimized brake performance for every individual application.

Specs

Our rotors are machined and fully e-coated, just like the rotor hats. This is a protectant coating the prohibits surface rust from forming on the exposed surfaces. Once the parts are installed and being bedded in, the brake pad friction and caliper pressure will remove the coating at the spot the brake pads touch. This will expose the silver iron material underneath.

Wilwood 140-17738 Specifications

KEY SPECS
MFG. Part #140-17738
BrandWilwood
PositionFront
Rotor Diameter12.88 Inch
Rotor TypeSolid
Caliper PistonsSix
Caliper FinishPowder Coated
Parking Brake ProvisionNo
Minimum Recommended Wheel Diameter17 Inch
Rotor ShapeRound
Hardware IncludedYes
Rotor StyleSlotted
Front Rotor IncludedYes
Front Rotor Diameter12.88
Front Caliper IncludedYes
Rear Caliper IncludedNo
Front Spindles IncludedNo
Master Cylinder IncludedNo
Brake Booster IncludedNo
Brake Hoses IncludedNo
Rear Rotor IncludedNo
ColorBlack
GENERAL
Sold in QuantityKit
GTIN Code889545117936
Rotor Thickness1.1"
Stud Diameter0.52"
Mount TypeRadial
OE Hub Offset0.33"
Total Piston Area4.86 sq. in.
Piston TypeStainless
Pad Area8.2 sq. in.
Pad Volume3.8 cu. in.
Brake Pad CompoundBP-10
Rotor FinishBlack E-Coat
Rotor Material TypeSpec-37 Iron
Vane Count48 Straight Vane
Hat TypeBig Brake Hat - Flared Bell
Hat FinishBlack E-Coat
Hub MaterialAluminum
Hat Material TypeAluminum
Hat Offset Dimension1.1"
Front Rotor Thickness1.10"
Front Caliper ColorBlack
Front Caliper PistonSteel
Brake Lines IncludedNo
Front Rotor StyleSlotted
Brake Pads IncludedNo
Caliper ColorBlack
Caliper Material TypeForged Aluminum
Brake Shoe MaterialNo
Drum Brake Pins IncludedNo
Drum Brake Springs IncludedNo
Hub Bolt Circle 15 x 4.50"
Hub Bolt Circle 25 x 4.75"
Hub FinishNatural
Rotor Hat MaterialAluminum
Hat Bolt Circle 15 x 4.50"
Hat Bolt Circle 25 x 4.75"
