Front Position, 12.88 Inch Rotor Diameter, Black, Black
| MFG. Part # | 140-17738-D |
| Position | Front |
| Rotor Diameter | 12.88 Inch |
| Rotor Type | Vented |
| Caliper Pistons | Six |
Need help?
855.313.9176Quick and Easy Returns
Return PolicyForged Narrow Superlite 6R Big Brake Front Brake Kit (Hub)
FNSL6R billet Forged six-piston calipers with 13”-14” rotors deliver the ultimate combination for braking power and style in this group of kits engineered for traditional non-ABS spindles on American muscle cars and vintage rods. Built exclusively for 17” and larger wheels, SL6 kits enhance tire and suspension upgrades on all types of custom show and high performance dual-purpose street and track machines. A full range of options for caliper finishes and rotor designs are guaranteed to catch the eye of the most discriminating enthusiast while providing optimized brake performance for every individual application.Specs
Guides & Documents
WARNING:
Cancer and Reproductive Harm – www.P65Warnings.ca.gov
| KEY SPECS | |
|---|---|
| MFG. Part # | 140-17738-D |
| Brand | Wilwood |
| Position | Front |
| Rotor Diameter | 12.88 Inch |
| Rotor Type | Vented |
| Caliper Pistons | Six |
| Caliper Finish | Powder Coated |
| Parking Brake Provision | No |
| Minimum Recommended Wheel Diameter | 17 Inch |
| Rotor Shape | Round |
| Hardware Included | Yes |
| Rotor Style | Drilled & Slotted |
| Spindle Type | Factory Disc & Drum Spindles |
| Front Rotor Included | Yes |
| Front Rotor Diameter | 12.88 |
| Front Caliper Included | Yes |
| Rear Caliper Included | No |
| Front Spindles Included | No |
| Master Cylinder Included | No |
| Brake Booster Included | No |
| Brake Hoses Included | No |
| Rear Rotor Included | No |
| Color | Black |
| GENERAL | |
| Sold in Quantity | Kit |
| GTIN Code | 889545117943 |
| Rotor Thickness | 1.1" |
| Stud Diameter | 0.52" |
| Mount Type | Radial |
| OE Hub Offset | 0.33" |
| Total Piston Area | 4.86 sq. in. |
| Piston Type | Stainless |
| Pad Area | 8.2 sq. in. |
| Pad Volume | 3.8 cu. in. |
| Brake Pad Compound | BP-10 |
| Rotor Finish | Black E-Coat |
| Rotor Material Type | Spec-37 Iron |
| Vane Count | 48 Straight Vane |
| Hat Type | Big Brake Hat - Flared Bell |
| Hat Finish | Black E-Coat |
| Hub Material | Aluminum |
| Hat Material Type | Aluminum |
| Hat Offset Dimension | 1.1" |
| Front Rotor Thickness | 1.10" |
| Front Caliper Color | Black |
| Front Caliper Piston | Steel |
| Brake Lines Included | No |
| Front Rotor Style | Drilled and Slotted |
| Brake Pads Included | No |
| Caliper Color | Black |
| Caliper Material Type | Forged Aluminum |
| Brake Shoe Material | No |
| Drum Brake Pins Included | No |
| Drum Brake Springs Included | No |
| Hub Bolt Circle 1 | 5 x 4.50" |
| Hub Bolt Circle 2 | 5 x 4.75" |
| Hub Finish | Natural |
| Rotor Hat Material | Aluminum |
| Hat Bolt Circle 1 | 5 x 4.50" |
| Hat Bolt Circle 2 | 5 x 4.75" |
