Wilwood 140-11978-DR FNSL6R 12.88 Front Disc Brake Kit,06-Up Civic/CRZ

$182 Off

Wilwood 140-11978-DR FNSL6R 12.88 Front Disc Brake Kit,06-Up Civic/CRZ
Wilwood

|

#83514011978DR

Wilwood 140-11978-DR FNSL6R 12.88 Front Disc Brake Kit,06-Up Civic/CRZ

Rotor / Caliper Type:

Drilled / Red

Undrilled / Red

$2,216.93

/each

Factory Shipped

$2,399.00

Save $182.07


Quantity

Need Help? Call to Order

Add to a list

Share

Select a vehicle to verify Fitment

Select Vehicle

Product Summary

Front Position, 12.88 Inch Rotor Diameter, Red

    See more details

    Key Specs

    MFG. Part #140-11978-DR
    PositionFront
    Wheel Bolt Pattern (in.)5x4.5 in. | 5x4.75 in.
    Wheel Bolt Pattern (mm)5x114.3 mm | 5x120.65 mm
    Rotor Diameter12.88 Inch
    See more specs

    Need To Know

    Need help?

    855.313.9176
    View the Help Center

    Quick and Easy Returns

    Return Policy

    Wilwood 140-11978-DR Details

    The unsurpassed braking capacity of the Forged Narrow Superlite 6R six-piston caliper serves as the base of this group of 13"-14" big rotor kits for these popular late model vehicles. FNSL6R kits are engineered application specific for simplified installation and full compatibility with OE master cylinder output and ABS functions where used. Big brake kits provide increased brake capacity and complimentary style with wheel, tire, and suspension upgrades on show cars and high performance street/track machines. Optional caliper finishes and rotor designs simplify personalizing the style and braking requirements of any application.

    Application

    2006 Honda Civic DX Coupe 1.8L (SOHC) DX / LX
    2006 Honda Civic DX Sedan 1.8L (SOHC) DX / LX
    2006 Honda Civic EX Coupe 1.8L (SOHC) EX
    2006 Honda Civic EX Sedan 1.8L (SOHC) EX
    2006 Honda Civic GX Sedan 1.8L (SOHC) GX
    2006 Honda Civic Hybrid Sedan 1.3L (SOHC) Hybrid
    2006 Honda Civic SI Coupe 2.0L (DOHC) SI
    2007 Honda Civic DX Coupe 1.8L (SOHC) DX / LX
    2007 Honda Civic DX Sedan 1.8L (SOHC) DX / LX
    2007 Honda Civic EX Coupe 1.8L (SOHC) EX
    2007 Honda Civic EX Sedan 1.8L (SOHC) EX
    2007 Honda Civic GX Sedan 1.8L (SOHC) GX
    2007 Honda Civic Hybrid Sedan 1.3L (SOHC) Hybrid
    2007 Honda Civic SI Coupe 2.0L (DOHC) SI
    2007 Honda Civic SI Sedan 2.0L (DOHC) SI
    2008 Honda Civic DX Coupe 1.8L (SOHC) DX / LX
    2008 Honda Civic DX Sedan 1.8L (SOHC) DX / LX
    2008 Honda Civic EX Coupe 1.8L (SOHC) EX
    2008 Honda Civic EX Sedan 1.8L (SOHC) EX
    2008 Honda Civic GX Sedan 1.8L (SOHC) GX
    2008 Honda Civic Hybrid Sedan 1.3L (SOHC) Hybrid
    2008 Honda Civic SI Coupe 2.0L (DOHC) SI
    2008 Honda Civic SI Sedan 2.0L (DOHC) SI
    2009 Honda Civic DX Coupe 1.8L (SOHC) DX / LX
    2009 Honda Civic DX Sedan 1.8L (SOHC) DX / LX
    2009 Honda Civic EX Coupe 1.8L (SOHC) EX
    2009 Honda Civic EX Sedan 1.8L (SOHC) EX
    2009 Honda Civic GX Sedan 1.8L (SOHC) GX
    2009 Honda Civic Hybrid Sedan 1.3L (SOHC) Hybrid
    2009 Honda Civic SI Coupe 2.0L (DOHC) SI
    2009 Honda Civic SI Sedan 2.0L (DOHC) SI
    2010 Honda Civic DX Coupe 1.8L (SOHC) DX / LX
    2010 Honda Civic DX Sedan 1.8L (SOHC) DX / LX
    2010 Honda Civic EX Coupe 1.8L (SOHC) EX
    2010 Honda Civic EX Sedan 1.8L (SOHC) EX
    2010 Honda Civic GX Sedan 1.8L (SOHC) GX
    2010 Honda Civic Hybrid Sedan 1.3L (SOHC) Hybrid
    2010 Honda Civic SI Coupe 2.0L (DOHC) SI
    2010 Honda Civic SI Sedan 2.0L (DOHC) SI
    2011 Honda Civic DX Coupe 1.8L (SOHC) DX / LX
    2011 Honda Civic DX Sedan 1.8L (SOHC) DX / LX
    2011 Honda Civic EX Coupe 1.8L (SOHC) EX
    2011 Honda Civic EX Sedan 1.8L (SOHC) EX
    2011 Honda Civic GX Sedan 1.8L (SOHC) GX
    2011 Honda Civic Hybrid Sedan 1.3L (SOHC) Hybrid
    2011 Honda Civic SI Coupe 2.0L (DOHC) SI
    2011 Honda Civic SI Sedan 2.0L (DOHC) SI
    2011 Honda CR-Z All
    2012 Honda Civic DX Coupe 1.8L (SOHC) DX / LX
    2012 Honda Civic DX Sedan 1.8L (SOHC) DX / LX
    2012 Honda Civic EX Coupe 1.8L (SOHC) EX
    2012 Honda Civic EX Sedan 1.8L (SOHC) EX
    2012 Honda Civic GX Sedan 1.8L (SOHC) GX
    2012 Honda Civic Hybrid Sedan 1.3L (SOHC) Hybrid
    2012 Honda Civic SI Coupe 2.0L (DOHC) SI
    2012 Honda Civic SI Sedan 2.0L (DOHC) SI
    2012 Honda CR-Z All

    Charts

    Specs

    Our rotors are machined and fully e-coated, just like the rotor hats. This is a protectant coating the prohibits surface rust from forming on the exposed surfaces. Once the parts are installed and being bedded in, the brake pad friction and caliper pressure will remove the coating at the spot the brake pads touch. This will expose the silver iron material underneath.

    Wilwood 140-11978-DR Specifications

    KEY SPECS
    MFG. Part #140-11978-DR
    BrandWilwood
    PositionFront
    Wheel Bolt Pattern (in.)5x4.5 in. | 5x4.75 in.
    Wheel Bolt Pattern (mm)5x114.3 mm | 5x120.65 mm
    Rotor Diameter12.88 Inch
    Rotor TypeVented
    Caliper PistonsSix
    Caliper FinishPowder Coated
    Parking Brake ProvisionNo
    Minimum Recommended Wheel Diameter17 Inch
    Rotor ShapeRound
    Hardware IncludedYes
    Rotor StyleDrilled & Slotted
    Spindle TypeFactory Disc Spindle
    Front Rotor IncludedYes
    Front Rotor Diameter12.88 Inch
    Front Caliper IncludedYes
    Rear Caliper IncludedNo
    Front Spindles IncludedNo
    Master Cylinder IncludedNo
    Brake Booster IncludedNo
    Brake Hoses IncludedYes
    Rear Rotor IncludedNo
    ColorRed
    Front Caliper Piston Quantity6
    Bolt Pattern5 on 4.5" | 4.75"
    Front Caliper FinishPowder Coated
    GENERAL
    GTIN Code889545014730
    Rotor Thickness1.1"
    Stud Diameter0.52"
    Mount TypeRadial
    Total Piston Area3.46 sq. in.
    Piston TypeStainless
    Pad Area8.20 sq. in.
    Pad Volume3.8 cu. in.
    Brake Pad CompoundBP-10
    Caliper TypeRadial
    Rotor FinishBlack E-Coat
    Rotor Material TypeSpec-37 Iron
    Vane Count48 Curved Vane
    BeddedNo
    BalancedNo
    Hat TypeBig Brake Hat - Flared Bell
    Hat FinishBlack E-Coat
    Hat Material TypeAluminum
    Hat Offset Dimension0.54"
    Brake Lines IncludedNo
    Caliper ColorRed
    Caliper Material TypeForged Aluminum
    Hat Bolt Circle 15 x 4.50
