Turbosmart TS-0404-1242 Fuel Pressure Regulator, 5 Port, AN 10

The Turbosmart FPR Pro 10 Series provides market leading fuel control and response via true 1:1 ratio and superior flow and bypass capacity for vehicles with -10 / 10AN fuel feed and -8 / 8AN return fittings. Utilising our Stainless Steel Valve Seat & Milspec Diaphragm the FPR10 Pro Series is suitable for all Fuel types including Race Fuel and aggressive leaded fuels. Our FPR10 Pro Range includes 1 x 10AN inlet, 4 x 8AN outlet ports and a 8AN return and is available in Pro EFI (50psi to 130psi) and Pro M (50psi to 100psi) for Mechanical Pump Systems.

Features

• Stainless Steel Valve Seat
• Suitable for all fuel types
• 1:1 Class Leading Ratio & Response
• Adjustable Pressure
• 1/8 NPT Pressure Sensor Port
• Unique Locking Collar Design
• Milspec Diaphragm
• Detailed Specific Fuel Flow Data & Spec
• AN 10

About Turbosmart

Behind every Turbosmart product stands a long and rich racing history. While a majority of Turbosmart products are used on street cars, their design and testing procedure is identical to the high-end purpose-made racing products. Before reaching the consumer, Turbosmart products are subjected to a range of tests performed in the most demanding environment, the race track.

When Turbosmart began making performance products back in 1997, a great amount of effort was put into the design and manufacturing process to ensure our products created a new standard. More hand-crafted than mass-produced, Turbosmart products quickly gained acceptance within the performance community for their quality and reliability. Coupled with extraordinary service and after-sales support, Turbosmart quickly became one of the most sought-after names in the industry. Not much has changed since then. Although our product line and the company itself have grown considerably, the products are still designed and manufactured in our factory in Sydney, Australia, using the same tried and proven formula of innovative design, strict quality control, and rigorous testing. We have invested in our research facility manufacturing equipment and staff training to ensure our products continue to perform up to and beyond your expectations. At Turbosmart, we do not believe in cutting corners and half-measures. We do not accept anything short of perfection - and neither should you.

Installation Instructions (TML)

MSDS (CE=)
