Speedway Universal Fabricated Aluminum Fuel Tank, 16 Gallon

#91076051

Speedway Universal Fabricated Aluminum Fuel Tank, 16 Gallon

Name: Speedway Universal Fabricated Aluminum Fuel Tank, 16 Gallon
Brand: Speedway Motors
SKU: 91076051
Price: 471.99 USD
Availability: InStock
Rating: 4.2 (6 reviews)

6 Reviews

8 Questions

This fabricated aluminum fuel tank is TIG welded from natural finish aluminum sheet, and features a -6 AN male outlet
16 gallon capacity suitable for most any hot rod/street rod or custom build
Accepts the common 5-bolt sending unit popular with aftermarket manufacturers

$471.99

/each

In Stock

Quantity

Need Help? Call to Order

Add to a list

Select a vehicle to verify Fitment

Select Vehicle

Product Summary

Universal Fit, Custom Replacement Fuel Tank Style

This fabricated aluminum fuel tank is TIG welded from natural finish aluminum sheet, and features a -6 AN male outlet
16 gallon capacity suitable for most any hot rod/street rod or custom build
Accepts the common 5-bolt sending unit popular with aftermarket manufacturers
Filler neck measures 1-3/4" long and 2" in diameter
Tank measures 28" long, 10" deep, and 16" tall

See more details

Key Specs

MFG. Part #	91076051
Fuel Tank Style	Custom Replacement
Fuel System Type	Carbureted
Capacity	16 gallons
Material Type	Aluminum

See more specs

Need To Know

Need help?

855.313.9176

View the Help Center

Quick and Easy Returns

Return Policy

Speedway Motors 91076051 Details

This 16 gallon tank was designed to be bolted to the floor of a pick-up box, but we're sure you can figure out other applications
It measures 28" long, 10" deep and 16" tall
It accepts the common 240 ohm full - 33 ohm empty 5-bolt sending unit (tank threaded with 10-24 thread size for sending unit installation hardware - not included)
filler neck measures 1-3/4" in length, 2" o/d and includes a 2-1/2" o/d non-vented, o-ring type threaded cap
Ports on this tank are -6 AN for the pickup and 1/4" NPT for the vent
This has an AN6 pickup tube at the top of the tank to supply fuel to the fuel pump

Specs

Part Number 458400 vent/roll over valve

CARB Warning

For race/ off road use only

Emissions warning: this part only legal for sale or use in California for racing (competition) vehicles which may never be used, registered, or licensed for use upon a public highway. Any other use renders the vehicle tampered and not legal for use on California public highways (any public street or roadway, public dirt road, public park, or publicly maintained right of way open to the use of the public for vehicular travel). Violations subject to $37,500 penalty per violation per vehicle, revocation of registration, loss of use on California public right of ways, and proof of correction for tampering. There are similar restrictions and penalties under federal law and the laws of all other states with penalties under federal law of up to approximately $45,268 per tampered vehicle and/or engine.

CA Prop 65

CARB warning

Speedway Motors 91076051 Specifications

KEY SPECS
MFG. Part #	91076051
Brand	Speedway Motors
Fuel Tank Style	Custom Replacement
Fuel System Type	Carbureted
Capacity	16 gallons
Material Type	Aluminum
Finish	Natural
Color	Natural
Sending Unit Included	No
Fuel Pump Included	No
Overall Length	28"
Overall Width	10"
Overall Height	16"
Hardware Included	No
Fuel Capacity Range	15.00-19.99 Gallons

GENERAL
Sold in Quantity	Each
Outlet Fitting	-6 AN Male

Ratings & Reviews

4.2

6 Reviews

Overall Assessment

Customers appreciate our product's perfect fit, particularly in limited space areas like trunks or between seats in vehicles. The product has a compact footprint and the craftsmanship is highly commended. However, it has been suggested that the screw holes could be improved for better fitting, and the inclusion of rubber or neoprene mounting pads would be useful. Some users have had issues with the siphon tube threads, recommending a thorough check before installation. Despite these minor challenges, the overall quality and practicality of the product are favorably reviewed, surpassing similar products from competitors.

Write A Review

4.2

6 reviews

Filter by Ratings

Sort Reviews

would buy again

5.0

a year ago

mike

alexandria nh

Verified

fit well in a ford model a

Would Recommend

Size good but not threads

3.0

2 years ago

Larry

Batavia, IL.

Verified

The 5 10/32 screw holes had to be retaped. Pipe threads on both the hole for siphon tube and the siphon tube were not very good.

Would Recommend

Good fit in a pickup box

4.0

10 years ago

B30

Wisconsin

Verified

In a 1940 street rod truck. Fit well.

Would Recommend

Nice tank BUT

4.0

12 years ago

demonos

Tacoma wa

Nice tank for a Model A roadster to get more trunk room, well built, Cons, No baffles inside, pick up tube is for ana fittings, mounting tabs are approx 3/4 inch above bottom of tank. This is a nice tank however i recieved mine with a crossed threaded pick up tube i am now trying to repair as i dont want my car down for a return after removing my old tank..i have not contacted speedway on this matter, But check your fitting before you install. price is a little high and shipping is out of bounds

Would Recommend

looks like an easy install

5.0

13 years ago

ron

oneonta, ny

Verified

this is an excellent fit in my 29 ford roadster. not alot of room in truck area. the footprint of tank is just right for this application. still leaves enough trunk space and space behine seats for storage. i feel the craftsmanship of the tank to be excellent. keep up the good list of products you continue to offer.

Would Recommend

Good quality

4.0

14 years ago

Buff

Palm Beach Gardens, FL

Verified

Perfect fit for the space between my trunk and rear seat back of my '40 Chevy coupe. Dimensions stated don't include welded-on 2 inch-wide angle mounting brackets at base of tank. An extension capability of the filler neck/cap would be useful. Manufacturer should include 2"x9"x1/4" rubber or neoprene mounting pads.

Would Recommend

Showing 6 of 6 reviews
