MSD 82893-8 Details

The most powerful Smart Coil on the market for use with Holley HP and Dominator ECU's and other EFI systems.

The MSD Smart Coil is a direct replacement for the popular IGN-1A coil. Here's the difference; it produces more spark energy while consuming less power without sacrificing voltage output. This means you get hotter spark at the plug to burn the maximum amount of fuel in each cylinder while using less power from your electrical system.

It is compatible with Holley EFI and many other aftermarket electronic fuel injection systems and will run on traditional 12 volt or 16 volt electrical systems found in race applications. Unique elongated mounting holes accommodate IGN-1A mounting brackets or allow it to bolt in place of an LS coil with 72mm bolt spacing. The MSD Smart Coil will bolt right on to Holley LS cast aluminum valve covers for a super clean look. Available in red or black, there's a set ready for your build.

Features:

More spark energy than any other IGN-1A smart coil on the market for maximum fuel burn during combustion sequence
Low current draw means less demand on the electrical and charging system
Built-in ignitor for compatibility with Holley EFI and many other aftermarket ECU’s
Maximum operating voltage of 17 volts – for compatibility with both 12 volt and 16 volt electrical systems found in many performance/race applications
Same wiring pinout as other IGN-1A coils for easy plugin upgrades
Elongated mounting holes to allow direct replacement of IGN-1A coils and will bolt in place of factory LS 1/2/3/6/7 coils with 72mm bolt spacing
Direct bolt-on to Holley cast aluminum LS valve covers with 72mm bolt spacing
Black Finish

Guides & Documents

Ignition Coils Installation Instructions (425828938)

CARB Warning

For race/ off road use or for use on pre-1966 vehicles.

Emissions warning: this part only legal for sale or use in California for racing (competition) vehicles which may never be used, registered, or licensed for use upon a public highway, or if installed in vehicles model-year 1965 or older; motorcycles model-year 1977 or older; or off-highway recreational vehicles (such as off-road motorcycles and all-terrain vehicles) model-year 1996 and older. Any other use renders the vehicle tampered and not legal for use on California public highways (any public street or roadway, public dirt road, public park, or publicly maintained right of way open to the use of the public for vehicular travel). Violations subject to $37,500 penalty per violation per vehicle, revocation of registration, loss of use on California public right of ways, and proof of correction for tampering. There are similar restrictions and penalties under federal law and the laws of all other states with penalties under federal law of up to approximately $45,268 per tampered vehicle and/or engine.

CA WARNING:

Can expose you to lead, a carcinogen and reproductive toxicant. See www.P65Warnings.ca.gov

CARB warning

MSD 82893-8 Specifications

KEY SPECS
MFG. Part #	82893-8
Brand	MSD
Coil Style	Coil pack
Maximum Voltage	50,000 volts

GENERAL
Turns Ratio	69:1
Resistance	0.55 ohms
Inductance	5.2 mH
Peak Current	201 mJ
Color	Red
Coil Wire Included	No
Mounting Bracket Included	No
GTIN Code	090127077399
Sold in Quantity	Kit
