Detroit Speed 090222DS 21.5" Rear Steer Tuned Rack And Pinion

Detroit Speed’s 090222DS Detroit Tuned rack and pinion is a rear-steer steering upgrade built specifically for 1968–1982 Chevrolet Corvette applications. It’s designed to deliver precise, modern steering feel with fitment-focused dimensions, including a 21.5-inch inner tie rod ball-to-ball width and an 8.9-inch mounting bolt span.

This rack is made from all-new components and each unit is quality-checked and performance-tested before packaging for consistent operation right out of the box. It also features clearly defined connection specs—M12-1.5 mounting bolt threads, 9/16”-18 outer tie rod threads, and a 17mm-36 input shaft (DSE P/N: 092525DS), along with UNJF pressure fitting threads for secure hydraulic connections.

• All new components
• Every rack undergoes a rigorous quality check and is performance tested prior to being packaged
• Inner Tie Rod Ball-to-Ball Width: 21.5 inches
• Mounting Bolt Span: 8.9 inches
• Mounting Bolt Thread Size: M12-1.5
• Outer Tie Rod Thread Size: 9/16”-18
• Input Shaft: 17mm-36 (DSE P/N: 092525DS)
• High Pressure Fitting Thread: 9/16-18 UNJF (DSE P/N: 090230DS)
• Lower Pressure Fitting Thread: 3/4”-16 UNJF (DSE P/N : 090231DS)

Designed to fit 1968-1982 Chevrolet Corvette applications w/ Rear Steer.
