#2822608216
COMP Cams 26082-16 Valve Springs, Triple, 686 lb Rate, Set of 16
$649.95
/set
Factory Shipped
Quantity
Need Help? Call to Order
Add to a list
Select a vehicle to verify Fitment
Select Vehicle
Key Specs
| MFG. Part # | 26082-16 |
| Brand | COMP Cams |
| Valve Spring Style | Standard |
| Spring Rate | 686 lbs. |
Need To Know
Need help?
855.313.9176Quick and Easy Returns
Return PolicyCOMP Cams 26082-16 Details
COMP Cams 26082-16 Details
Elite Race Triple Valve Springs from COMP Cams have an .800° to .900° maximum lift and outside diameter of 1.680°. Designed for use with roller cams, they are widely used in aggressive and endurance applications such as Competition Eliminator, Super Gas, Super Stock and other Fast Bracket Classes, as well as boat drag and tractor pull applications. The metallurgists at COMP Cams scrutinize every piece of metal utilized in the creation of Elite Race Valve Springs to make sure they are of unsurpassable quality because fissures within the metal of standard spring wire, caused by molecular contaminants, are the weakest link in valve spring construction. These fissures appear to be immense under the Scanning Electron Microscope but in fact, are just microns wide. Diminishing the occurrence of these fissures in our valve spring steel is the COMP Cams standard when selecting materials.
Guides & Documents
CARB Warning
For race/ off road use only
CARB Warning
For race/ off road use only
COMP Cams 26082-16 Specifications
COMP Cams 26082-16 Specifications
| KEY SPECS | |
|---|---|
| MFG. Part # | 26082-16 |
| Brand | COMP Cams |
| Valve Spring Style | Standard |
| Spring Rate | 686 lbs. |
| GENERAL | |
| Outer Spring O.D. | 1.68" |
| Coil Bind Height | 1.13" |
| Damper Spring Included | No |
| Outer Spring I.D. | 1.195" |
| Inner Spring I.D. | 0.635" |
| Sold in Quantity | Set |
| Number of Springs Per Valve | Triple |
| Coated | No |
| GTIN Code | 036584071273 |
