Wilwood Bolt-On Front / Rear Brake Kit, Ford Spindles
Wilwood Bolt-On Front / Rear Brake Kit, Ford Spindles
Wilwood

|

#7154020

Wilwood Bolt-On Front / Rear Brake Kit, Ford Spindles

$2,109.99

/kit

In Stock

$2,141.61

Save $31.62


Quantity

Need Help? Call to Order

Add to a list

Share

Select a vehicle to verify Fitment

Select Vehicle

Product Summary

Front and Rear Position, No Value Rotor Diameter

    Comes as a Kit

    View Kit Components

    See more details

    Key Specs

    MFG. Part #140-1501-B
    PositionFront and Rear
    Wheel Bolt Pattern (in.)5x4.5 in. | 5x4.75 in.
    Wheel Bolt Pattern (mm)5x114.3 mm | 5x120.65 mm
    Rotor TypeSolid
    See more specs

    Need To Know

    Need help?

    855.313.9176
    View the Help Center

    Quick and Easy Returns

    Return Policy

    Wilwood 140-1501-B Details

    Give your T roadster the ultimate stopping power with Wilwood disc brakes. These kits feature aluminum hubs with both 5-on-4.5" and 5-on-4.75" bolt patterns, rotors, four-piston calipers with pads, plus all of the bearings, seals, brackets and hardwear you need for installation on our Ford style spindles. Rear kit bolts on new-style Big Ford Ends.

    Charts

    Specs

    Our rotors are machined and fully e-coated, just like the rotor hats. This is a protectant coating the prohibits surface rust from forming on the exposed surfaces. Once the parts are installed and being bedded in, the brake pad friction and caliper pressure will remove the coating at the spot the brake pads touch. This will expose the silver iron material underneath.

    Wilwood 140-1501-B Specifications

    KEY SPECS
    MFG. Part #140-1501-B
    BrandWilwood
    PositionFront and Rear
    Wheel Bolt Pattern (in.)5x4.5 in. | 5x4.75 in.
    Wheel Bolt Pattern (mm)5x114.3 mm | 5x120.65 mm
    Rotor TypeSolid
    Caliper PistonsFour
    Caliper FinishPowder Coated
    Parking Brake ProvisionYes
    Minimum Recommended Wheel Diameter15 Inch
    Rotor ShapeRound
    Hardware IncludedYes
    Rotor StylePlain Face
    Front Rotor IncludedYes
    Front Rotor Diameter10.75 Inch
    Front Caliper IncludedYes
    Rear Caliper IncludedYes
    Front Spindles IncludedNo
    Master Cylinder IncludedNo
    Brake Booster IncludedNo
    Brake Hoses IncludedYes
    Rear Rotor IncludedYes
    ColorBlack/Gray
    Bolt Pattern5 on 4.5" | 4.75"
    Front Caliper Piston Quantity4
    Front Caliper FinishAnodized
    GENERAL
    Sold in QuantityKit
    NotesIncludes rotors, rotor adapters, calipers, hubs, bearings and seals, hardware, caliper brackets, brake pads, and brake line adapters.
    Rotor Thickness0.35"
    Stud Diameter0.5"
    Thread Pitch1/2"-20
    Rear Rotor Diameter12.19"
