Product Summary

Left Position, Round Rotor Shape, Vented Rotor Type

  • Wilwood's ULHD 16 Curved Vane Spec-37 rotors are manufactured from a proprietary iron alloy developed to withstand extreme temperatures with the highest possible degree of resistance against distortion, warping, cracking, and wear
  • The formulation for this alloy is a derivative of technology and materials that were significant in the development of the extreme-duty military spec rotors that are manufactured by Wilwood
  • HP Series preparation includes full detail machining and smooth pad contact faces without slots

Key Specs

PositionLeft
Rotor ShapeRound
Rotor Diameter11.75 Inch
Rotor TypeVented
Rotor StylePlain Face

Need To Know

Free Shipping on Orders Over $149

Shipping Policies & FAQs

Quick and Easy Returns

Return Policy

Details

Wilwood''s ULHD-16 Curved Vane Spec-37 rotors are manufactured from a proprietary iron alloy developed to withstand extreme temperatures with the highest possible degree of resistance against distortion, warping, cracking, and wear. The formulation for this alloy is a derivative of technology and materials that were significant in the development of the extreme duty military spec rotors that are manufactured by Wilwood. Our HP Series preparation includes full detail machining and smooth pad contact faces without slots.

Specifications

KEY SPECS
MFG. Part #160-15878
BrandWilwood
PositionLeft
Rotor ShapeRound
Rotor Diameter11.75 Inch
Rotor TypeVented
Rotor StylePlain Face
Rotor Material TypeSpec-37 Iron
GENERAL
Rotor FinishPlain
ColorNatural
Rotor Thickness0.99"
Bolt Pattern8 on 7"
Vane Count16 Curved Vane
Rotor Hat IncludedNo
Rotor Hat Bolt Pattern8 x 7.00"
BeddedNo
BalancedNo
Lug ID6.38"
Inside Diameter8.46"
Rotor Mount Hole Size0.326"
Weight7.10 lbs.
Sold in QuantityEach
GTIN Code889545095562
