Wilwood 140-8175-BD FDL 10.75 Front Drag Disc Brake Kit, 1979-90 GM

$113 Off

Wilwood 140-8175-BD FDL 10.75 Front Drag Disc Brake Kit, 1979-90 GM
Wilwood

|

#8351408175BD

Wilwood 140-8175-BD FDL 10.75 Front Drag Disc Brake Kit, 1979-90 GM

$943.24

/each

Factory Shipped

$1,056.43

Save $113.19


Quantity

Need Help? Call to Order

Add to a list

Share

Select a vehicle to verify Fitment

Select Vehicle

Product Summary

Front Position, 10.75 Inch Rotor Diameter, Anodized

    See more details

    Key Specs

    MFG. Part #140-8175-BD
    PositionFront
    Rotor Diameter10.75 Inch
    Rotor TypeSolid
    Caliper PistonsFour
    See more specs

    Need To Know

    Need help?

    855.313.9176
    View the Help Center

    Quick and Easy Returns

    Return Policy

    Wilwood 140-8175-BD Details

    FDL Front Drag kits are drag racing's most popular front brake kits. FDL kits are available for the popular muscle car spindles and select aftermarket front struts used on four-wheel disc cars weighing up to 2,800 pounds, or rear drum brake equipped cars weighing up to 2,400 pounds. Forged billet FDL four piston calipers mount directly to the spindle with a bolt-on bracket. Forged billet, five lug hubs with direct mount steel rotors combine to provide an average weight savings of over 30 pounds compared to stock drum or disc brakes. Kits include all new hardware, wheel bearings, seals and extra length lug studs.

    Application

    1979 Buick Estate Wagon With OE 11" Rotor Spindles
    1979 Buick LeSabre With OE 11" Rotor Spindles
    1979 Buick Skylark Disc Brake Spindle
    1979 Chevrolet Camaro Disc Brake Spindle
    1979 Chevrolet Caprice With OE 11" Rotor Spindles
    1979 Chevrolet Impala With OE 11" Rotor Spindles
    1979 Chevrolet Nova Disc Brake Spindle
    1979 Oldsmobile Custom Cruiser With OE 11" Rotor Spindles
    1979 Oldsmobile Omega Disc Brake Spindle
    1979 Pontiac Bonneville With OE 11" Rotor Spindles
    1979 Pontiac Catalina With OE 11" Rotor Spindles
    1979 Pontiac Firebird Disc Brake Spindle
    1979 Pontiac Phoenix Disc Brake Spindle
    1980 Buick Estate Wagon With OE 11" Rotor Spindles
    1980 Buick LeSabre With OE 11" Rotor Spindles
    1980 Chevrolet Camaro Disc Brake Spindle
    1980 Chevrolet Caprice With OE 11" Rotor Spindles
    1980 Chevrolet Impala With OE 11" Rotor Spindles
    1980 Oldsmobile Custom Cruiser With OE 11" Rotor Spindles
    1980 Pontiac Bonneville With OE 11" Rotor Spindles
    1980 Pontiac Catalina With OE 11" Rotor Spindles
    1980 Pontiac Firebird Disc Brake Spindle
    1980 Pontiac Parisienne With OE 11" Rotor Spindles
    1981 Buick Estate Wagon With OE 11" Rotor Spindles
    1981 Buick LeSabre With OE 11" Rotor Spindles
    1981 Chevrolet Camaro Disc Brake Spindle
    1981 Chevrolet Caprice With OE 11" Rotor Spindles
    1981 Chevrolet Impala With OE 11" Rotor Spindles
    1981 Oldsmobile Custom Cruiser With OE 11" Rotor Spindles
    1981 Pontiac Bonneville With OE 11" Rotor Spindles
    1981 Pontiac Catalina With OE 11" Rotor Spindles
    1981 Pontiac Firebird Disc Brake Spindle
    1981 Pontiac Parisienne With OE 11" Rotor Spindles
    1982 Buick Estate Wagon With OE 11" Rotor Spindles
    1982 Buick LeSabre With OE 11" Rotor Spindles
    1982 Chevrolet Caprice With OE 11" Rotor Spindles
    1982 Chevrolet Impala With OE 11" Rotor Spindles
    1982 Oldsmobile Custom Cruiser With OE 11" Rotor Spindles
    1982 Pontiac Parisienne With OE 11" Rotor Spindles
    1983 Buick Estate Wagon With OE 11" Rotor Spindles
    1983 Buick LeSabre With OE 11" Rotor Spindles
    1983 Chevrolet Caprice With OE 11" Rotor Spindles
    1983 Chevrolet Impala With OE 11" Rotor Spindles
    1983 Oldsmobile Custom Cruiser With OE 11" Rotor Spindles
    1983 Pontiac Parisienne With OE 11" Rotor Spindles
    1984 Buick Estate Wagon With OE 11" Rotor Spindles
    1984 Buick LeSabre With OE 11" Rotor Spindles
    1984 Chevrolet Caprice With OE 11" Rotor Spindles
    1984 Chevrolet Impala With OE 11" Rotor Spindles
    1984 Oldsmobile Custom Cruiser With OE 11" Rotor Spindles
    1984 Pontiac Parisienne With OE 11" Rotor Spindles
    1985 Buick Estate Wagon With OE 11" Rotor Spindles
    1985 Buick LeSabre With OE 11" Rotor Spindles
    1985 Chevrolet Caprice With OE 11" Rotor Spindles
    1985 Chevrolet Impala With OE 11" Rotor Spindles
    1985 Oldsmobile Custom Cruiser With OE 11" Rotor Spindles
    1985 Pontiac Parisienne With OE 11" Rotor Spindles
    1986 Chevrolet Caprice With OE 11" Rotor Spindles
    1986 Pontiac Parisienne With OE 11" Rotor Spindles
    1987 Chevrolet Caprice With OE 11" Rotor Spindles
    1988 Chevrolet Caprice With OE 11" Rotor Spindles
    1989 Chevrolet Caprice With OE 11" Rotor Spindles
    1990 Chevrolet Caprice With OE 11" Rotor Spindles

    Charts

    Specs

    Our rotors are machined and fully e-coated, just like the rotor hats. This is a protectant coating the prohibits surface rust from forming on the exposed surfaces. Once the parts are installed and being bedded in, the brake pad friction and caliper pressure will remove the coating at the spot the brake pads touch. This will expose the silver iron material underneath.

    Wilwood 140-8175-BD Specifications

    KEY SPECS
    MFG. Part #140-8175-BD
    BrandWilwood
    PositionFront
    Rotor Diameter10.75 Inch
    Rotor TypeSolid
    Caliper PistonsFour
    Caliper FinishAnodized
    Parking Brake ProvisionNo
    Minimum Recommended Wheel Diameter15 Inch
    Rotor ShapeRound
    Hardware IncludedYes
    Rotor StyleDrilled
    Spindle TypeFactory Disc Spindle
    Front Rotor IncludedYes
    Front Rotor Diameter10.75 Inch
    Front Caliper IncludedYes
    Rear Caliper IncludedNo
    Front Spindles IncludedNo
    Master Cylinder IncludedNo
    Brake Booster IncludedNo
    Brake Hoses IncludedYes
    Rear Rotor IncludedNo
    Bolt Pattern5 on 4.75"
    ColorGray
    Front Caliper Piston Quantity4
    Front Caliper FinishAnodized
    GENERAL
    GTIN Code889545024395
    NotesFor use on cars up to 2800 pounds with rear discs or on cars up to 2400 pounds with rear drums
    Rotor Thickness0.35"
    Stud Diameter1/2-20
    Mount TypeLug
    OE Hub Offset0.31"
    Total Piston Area4.80 sq. in.
    Piston TypeStainless
    Pad Area6.36 sq. in.
    Pad Volume2.1 cu. in.
    Brake Pad CompoundBP-10
    Caliper TypeLug
    Rotor FinishBlack Oxide
    Rotor Material TypeSteel
    Vane CountNone
    BeddedNo
    BalancedNo
    Brake Lines IncludedNo
    Caliper ColorGray
    Caliper Material TypeForged Aluminum
    Stud Diameter 21/2-20
