Wilwood 140-15945 Forged Narrow Superlite 6R Front Brake Kit

$284 Off

Wilwood 140-15945 Forged Narrow Superlite 6R Front Brake Kit
Wilwood

|

#83514015945

Wilwood 140-15945 Forged Narrow Superlite 6R Front Brake Kit

Rotor / Caliper Type:

Undrilled

DrilledDrilled / RedUndrilled / Red

$2,363.61

/kit

Factory Shipped

$2,647.25

Save $283.64


Quantity

Need Help? Call to Order

Add to a list

Share

Select a vehicle to verify Fitment

Select Vehicle

Product Summary

Front Position, 13.06 Inch Rotor Diameter, Black

    See more details

    Key Specs

    MFG. Part #140-15945
    PositionFront
    Rotor Diameter13.06 Inch
    Rotor TypeVented
    Caliper PistonsSix
    See more specs

    Need To Know

    Need help?

    855.313.9176
    View the Help Center

    Quick and Easy Returns

    Return Policy

    Wilwood 140-15945 Details

    The unsurpassed braking capacity of the Forged Narrow Superlite 6R six-piston caliper serves as the base of this group of 13"-14" big rotor kits for he popular 1963 thru 1987 Chevrolet & GM C10 / C15 Trucks with Wilwood's new 1 Piece Iron Drop Pro Spindles. FNSL6R kits are engineered application specific for simplified installation and full compatibility with OE master cylinder output and ABS functions where used. Big brake kits provide increased brake capacity and complimentary style with wheel, tire, and suspension upgrades on show trucks and high performance street or track applications. Optional caliper finishes and rotor designs simplify personalizing the style and braking requirements of any application. This kit contains hubs with a 6 x 5.50" bolt circle.

    Charts

    Specs

    Our rotors are machined and fully e-coated, just like the rotor hats. This is a protectant coating the prohibits surface rust from forming on the exposed surfaces. Once the parts are installed and being bedded in, the brake pad friction and caliper pressure will remove the coating at the spot the brake pads touch. This will expose the silver iron material underneath.

    Wilwood 140-15945 Specifications

    KEY SPECS
    MFG. Part #140-15945
    BrandWilwood
    PositionFront
    Rotor Diameter13.06 Inch
    Rotor TypeVented
    Caliper PistonsSix
    Caliper FinishPowder Coated
    Parking Brake ProvisionNo
    Minimum Recommended Wheel Diameter17 Inch
    Rotor ShapeRound
    Hardware IncludedYes
    Rotor StyleSlotted
    Spindle TypeChevy
    Front Rotor IncludedYes
    Front Rotor Diameter13.06 Inch
    Front Caliper IncludedYes
    Rear Caliper IncludedNo
    Front Spindles IncludedNo
    Master Cylinder IncludedNo
    Brake Booster IncludedNo
    Brake Hoses IncludedNo
    Rear Rotor IncludedNo
    ColorBlack
    Bolt Pattern6 on 5.5"
    Front Caliper Piston Quantity6
    Application TypeWilwood C10 1-Piece Iron Pro Drop Spindles
    Front Caliper FinishPowder Coated
    GENERAL
    Sold in QuantityKit
    GTIN Code889545094107
    Bore Size1.75"
    Rotor Drum I.D.6.58"
    Rotor Thickness1.25"
    Rotor I.D.3.06"
    Stud Diameter0.52"
    Stud Length2.00"
    Thread Pitch1/2"-20
    Mount TypeRadial
    Total Piston Area4.86 sq. in.
    Piston TypeStainless
    Pad Area8.2 sq. in.
    Pad Volume3.8 cu. in.
    Brake Pad CompoundBP-20
    Caliper TypeRadial
    Rotor FinishPlain
    Rotor Material TypeSpec-37 Iron
    Vane Count48 Curved Vane
    BeddedNo
    BalancedYes
    Hat TypeBig Brake Hat - Flared Bell
    Hat FinishBlack E-Coat
    Hub MaterialAluminum
    Hat Material TypeAluminum
    Hat Offset Dimension1.380"
    Front Caliper MaterialForged Billet Aluminum
    Brake Lines IncludedNo
    Parking Brake Cables IncludedNo
    Caliper ColorBlack
    Caliper Material TypeForged Aluminum
    Hub FinishNatural
    Hub Bolt Circle 16 x 5.50"
    Bore Size 21.25"
    Hat Bolt Circle 16 x 5.50"
