Ford 9 Inch, Rear Position, 12.88 Inch Rotor Diameter
| MFG. Part # | 140-15844-DR |
| Position | Rear |
| Wheel Bolt Pattern (in.) | 5x4.5 in. | 5x4.75 in. |
| Wheel Bolt Pattern (mm) | 5x114.3 mm | 5x120.65 mm |
| Rotor Diameter | 12.88 Inch |
Need help?
855.313.9176Quick and Easy Returns
Return PolicyForged Narrow Superlite 4R Big Brake Rear Electronic Parking Brake Kit
Forged Narrow Superlite 4R Rear Electronic Parking Brake Kits provide the ultimate Big Brake solution for popular muscle car rear axles that require a parking brake. FNSL4R four piston calipers, 13” or 14” two-piece rotors, and high performance BP-10 compound pads provide optimized and balanced braking to compliment front big brake upgrades on all types of custom, show and high performance street machines. The unique Electronic Parking Brake caliper provides a static high torque static holding power for parking without mechanical cabling. Supplied with control unit and harness assembly, it simplifies installation and use. Optional caliper finishes and rotor designs enable the builder to personalize the style and optimize brake performance for every individual application.
Kit Components
Charts
Specs
Guides & Documents
CA WARNING:
Can expose you to lead, a carcinogen and reproductive toxicant. See www.P65Warnings.ca.gov
| KEY SPECS | |
|---|---|
| MFG. Part # | 140-15844-DR |
| Brand | Wilwood |
| Position | Rear |
| Wheel Bolt Pattern (in.) | 5x4.5 in. | 5x4.75 in. |
| Wheel Bolt Pattern (mm) | 5x114.3 mm | 5x120.65 mm |
| Rotor Diameter | 12.88 Inch |
| Rotor Type | Vented |
| Caliper Pistons | Four |
| Caliper Finish | Powder Coated |
| Parking Brake Provision | Yes |
| Minimum Recommended Wheel Diameter | 17 Inch |
| Rotor Shape | Round |
| Hardware Included | Yes |
| Rotor Style | Drilled & Slotted |
| Front Rotor Included | No |
| Front Caliper Included | No |
| Rear Caliper Included | Yes |
| Front Spindles Included | No |
| Master Cylinder Included | No |
| Brake Booster Included | No |
| Brake Hoses Included | Yes |
| Ford Bearing End Style | Big Ford New Style (Torino) |
| Rear Rotor Included | Yes |
| Color | Red |
| Rotor Hat Bolt Pattern | 12 x 8.75" |
| Bolt Pattern | 5 on 4.5" | 4.75" |
| GENERAL | |
| Sold in Quantity | Kit |
| GTIN Code | 889545092677 |
| Bore Size | 1.12" |
| Rotor Drum I.D. | 6.29" |
| Rotor Thickness | 1.1" |
| Rotor I.D. | 9.46" |
| Rotor Backspace | 2.035" |
| Stud Diameter | 0.52" |
| Axle Flange Offset | 2.50" |
| Mount Type | Radial |
| OE Hub Offset | 2.50" |
| Total Piston Area | 1.98 sq. in. |
| Piston Type | Stainless |
| Pad Area | 8.2 sq. in. |
| Pad Volume | 3.8 cu. in. |
| Brake Pad Compound | BP-10 |
| Caliper Type | Radial |
| Rotor Finish | Black E-Coat |
| Rotor Material Type | Spec-37 Iron |
| Vane Count | 48 Curved Vane |
| Bedded | No |
| Balanced | Yes |
| Hat Type | Big Brake Hat - Flared Bell |
| Hat Finish | Black E-Coat |
| Hat Material Type | Aluminum |
| Hat Offset Dimension | 2.035" |
| Brake Lines Included | No |
| Parking Brake Cables Included | No |
| Caliper Color | Red |
| Caliper Material Type | Forged Aluminum |
| Hat Bolt Circle 1 | 5 x 4.50 |
| Hat Bolt Circle 2 | 5 x 4.75 |
| Hat Bolt Circle 3 | 5 x 5.00 |
| Stud Diameter 2 | 0.52" |
| Stud Diameter 3 | 0.52" |
| Bore Size 2 | 1.12" |
