Wilwood 140-15303-R Forged Narrow Superlite Big Front Brake Kit

$183 Off

#83514015303R

Wilwood 140-15303-R Forged Narrow Superlite Big Front Brake Kit

The unsurpassed braking capacity of the Forged Narrow Superlite 6R six-piston caliper serves as the base of this group of 13”-14” big rotor kits for he popular 1963 thru 1987 Chevrolet & GM C10 / C15 Trucks with Wilwood's new Modular Drop Pro Spindles

Rotor / Caliper Type:

Undrilled / Red

$2,231.16

/each

Factory Shipped

$2,414.40

Save $183.24

Quantity

Need Help? Call to Order

Add to a list

Select a vehicle to verify Fitment

Select Vehicle

Product Summary

Front Position, 13.06 Inch Rotor Diameter, Red, Red

The unsurpassed braking capacity of the Forged Narrow Superlite 6R six-piston caliper serves as the base of this group of 13”-14” big rotor kits for he popular 1963 thru 1987 Chevrolet & GM C10 / C15 Trucks with Wilwood's new Modular Drop Pro Spindles
FNSL6R kits are engineered application specific for simplified installation and full compatibility with OE master cylinder output and ABS functions where used
Big brake kits provide increased brake capacity and complimentary style with wheel, tire, and suspension upgrades on show trucks and high performance street or track applications
Optional caliper finishes and rotor designs simplify personalizing the style and braking requirements of any application

See more details

Key Specs

MFG. Part #	140-15303-R
Position	Front
Rotor Diameter	13.06 Inch
Rotor Type	Vented
Caliper Pistons	Six

See more specs

Need To Know

Need help?

855.313.9176

View the Help Center

Quick and Easy Returns

Return Policy

Wilwood 140-15303-R Details

The unsurpassed braking capacity of the Forged Narrow Superlite 6R six-piston caliper serves as the base of this group of 13”-14” big rotor kits for he popular 1963 thru 1987 Chevrolet & GM C10 / C15 Trucks with Wilwood's new Modular Drop Pro Spindles
FNSL6R kits are engineered application specific for simplified installation and full compatibility with OE master cylinder output and ABS functions where used
Big brake kits provide increased brake capacity and complimentary style with wheel, tire, and suspension upgrades on show trucks and high performance street or track applications
Optional caliper finishes and rotor designs simplify personalizing the style and braking requirements of any application

Specs

Our rotors are machined and fully e-coated, just like the rotor hats. This is a protectant coating the prohibits surface rust from forming on the exposed surfaces. Once the parts are installed and being bedded in, the brake pad friction and caliper pressure will remove the coating at the spot the brake pads touch. This will expose the silver iron material underneath.

Guides & Documents

Everything You Need to Know About Converting Drum Brakes to Disc

Disc Brake Kits Installation Instructions (83514015303R)

CA WARNING:

Can expose you to lead, a carcinogen and reproductive toxicant. See www.P65Warnings.ca.gov

Wilwood 140-15303-R Specifications

KEY SPECS
MFG. Part #	140-15303-R
Brand	Wilwood
Position	Front
Rotor Diameter	13.06 Inch
Rotor Type	Vented
Caliper Pistons	Six
Caliper Finish	Powder Coated
Parking Brake Provision	No
Minimum Recommended Wheel Diameter	17 Inch
Rotor Shape	Round
Hardware Included	Yes
Rotor Style	Slotted
Spindle Type	Drop Spindle
Front Rotor Included	Yes
Front Rotor Diameter	13.06 in./331.70mm
Front Caliper Included	Yes
Rear Caliper Included	No
Front Spindles Included	No
Master Cylinder Included	No
Brake Booster Included	No
Brake Hoses Included	No
Rear Rotor Included	No
Color	Red
Bolt Pattern	5 on 4.75" \| 5"
Front Caliper Piston Quantity	Six

GENERAL
Sold in Quantity	Kit
GTIN Code	889545077537
Notes	Fits Wilwood aluminum Pro Spindles.
Rotor Thickness	1.25"
Mount Type	Radial
Piston Type	Stainless
Pad Area	8.2 sq. in.
Pad Volume	3.8 cu. in.
Brake Pad Compound	BP-10
Caliper Type	Radial
Rotor Material Type	Spec-37 Iron
Vane Count	48 Curved Vane
Bedded	No
Balanced	Yes
Hat Type	Big Brake Hat - Flared Bell
Hat Finish	Black E-Coat
Hat Material Type	Aluminum
Hat Offset Dimension	1.38"
Front Rotor Thickness	1.250"
Front Caliper Material	Forged Billet Aluminum
Front Caliper Color	Red
Brake Lines Included	No
Front Rotor Style	Slotted
Caliper Color	Red
Caliper Material Type	Forged Aluminum
Front Rotor Construction	Vented
Rotor Hat Material	Aluminum
