$103 Off
$103 Off
|
#83514014663R
$858.26
/kit
Factory Shipped
$961.25
Save $102.99
Quantity
Need Help? Call to Order
Add to a list
Select a vehicle to verify Fitment
Select Vehicle
| MFG. Part # | 140-14663-R |
| Position | Front |
| Wheel Bolt Pattern (in.) | 5x4.5 in. | 5x4.75 in. |
| Wheel Bolt Pattern (mm) | 5x114.3 mm | 5x120.65 mm |
| Rotor Diameter | 11.50 Inch |
Need help?
855.313.9176Quick and Easy Returns
Return PolicyCharts
Specs
Guides & Documents
CA WARNING:
Can expose you to lead, a carcinogen and reproductive toxicant. See www.P65Warnings.ca.gov
| KEY SPECS | |
|---|---|
| MFG. Part # | 140-14663-R |
| Brand | Wilwood |
| Position | Front |
| Wheel Bolt Pattern (in.) | 5x4.5 in. | 5x4.75 in. |
| Wheel Bolt Pattern (mm) | 5x114.3 mm | 5x120.65 mm |
| Rotor Diameter | 11.50 Inch |
| Rotor Type | Vented |
| Caliper Pistons | Four |
| Caliper Finish | Powder Coated |
| Parking Brake Provision | No |
| Minimum Recommended Wheel Diameter | 15 Inch |
| Rotor Shape | Round |
| Hardware Included | Yes |
| Rotor Style | Plain Face |
| Spindle Type | Factory Drum Spindle |
| Front Rotor Included | Yes |
| Front Rotor Diameter | 11.50 Inch |
| Front Caliper Included | Yes |
| Rear Caliper Included | No |
| Front Spindles Included | No |
| Master Cylinder Included | No |
| Brake Booster Included | No |
| Brake Hoses Included | Yes |
| Rear Rotor Included | No |
| Color | Red |
| Bolt Pattern | 5 on 4.75" | 5" |
| Front Caliper Piston Quantity | 4 |
| Front Caliper Finish | Powder Coated |
| GENERAL | |
| GTIN Code | 889545082128 |
| Rotor Thickness | 1" |
| Brake Pad Material | BP-10 |
| Mount Type | Lug |
| Total Piston Area | 4.8 sq. in. |
| Piston Type | Stainless |
| Caliper Type | Lug |
| Rotor Finish | Plain |
| Rotor Material Type | Iron |
| Bedded | No |
| Balanced | No |
| Brake Lines Included | No |
| Caliper Color | Red |
| Caliper Material Type | Forged Aluminum |
Be the first to ask a question.
1955-1964 Chevy Bel Air
1959-1964 Chevy Biscayne
1959-1961 Chevy Brookwood
1963-1964 Chevy Corvette
1957 Chevy Del Ray
1959-1960 Chevy El Camino
1959-1964 Chevy Impala
1959-1961 Chevy Kingswood
1955-1961 Chevy Nomad
1955-1957 Chevy One-Fifty Series
1959-1961 Chevy Parkwood
1955-1960 Chevy Sedan Delivery
1955-1957 Chevy Two-Ten Series
