$263 Off
$263 Off
|
#83514013868R
$3,200.56
/each
Factory Shipped
$3,463.40
Save $262.84
Quantity
Need Help? Call to Order
Add to a list
Select a vehicle to verify Fitment
Select Vehicle
| MFG. Part # | 140-13868-R |
| Position | Rear |
| Wheel Bolt Pattern (in.) | 8x6.5 in. |
| Wheel Bolt Pattern (mm) | 8x165.1 mm |
| Rotor Diameter | 15.50 Inch |
Need help?
855.313.9176Quick and Easy Returns
Return PolicyCharts
Specs
Guides & Documents
| KEY SPECS | |
|---|---|
| MFG. Part # | 140-13868-R |
| Brand | Wilwood |
| Position | Rear |
| Wheel Bolt Pattern (in.) | 8x6.5 in. |
| Wheel Bolt Pattern (mm) | 8x165.1 mm |
| Rotor Diameter | 15.50 Inch |
| Rotor Type | Vented |
| Caliper Pistons | Six |
| Caliper Finish | Powder Coated |
| Parking Brake Provision | Yes |
| Minimum Recommended Wheel Diameter | 20 Inch |
| Rotor Shape | Round |
| Hardware Included | Yes |
| Rotor Style | Slotted |
| Spindle Type | Factory Disc Spindle |
| Front Rotor Included | No |
| Front Rotor Diameter | 15 Inch |
| Front Caliper Included | No |
| Rear Caliper Included | Yes |
| Front Spindles Included | No |
| Master Cylinder Included | No |
| Brake Booster Included | No |
| Brake Hoses Included | Yes |
| Rear Rotor Included | Yes |
| Color | Red |
| Bracket Material | Steel |
| Finish | Clear Anodized |
| Bolt Pattern | 8 on 170mm |
| Front Caliper Finish | Powder Coated |
| GENERAL | |
| Sold in Quantity | Kit |
| GTIN Code | 889545071412 |
| Rotor Thickness | 1.38" |
| Stud Diameter | 0.64" |
| Stud Length | 1" |
| Thread Pitch | 1/8 in. NPT |
| Brake Pad Material | BP-10 |
| Offset | 0" |
| Axle Flange Offset | 0.00" |
| Mount Type | Radial |
| Total Piston Area | 6.52 sq. in. |
| Piston Type | Stainless |
| Pad Area | 12.69 sq. in. |
| Pad Volume | 6.81 cu. in. |
| Brake Pad Compound | BP-20 |
| Caliper Type | Radial |
| Rotor Finish | Black E-Coat |
| Rotor Material Type | Spec-37 Iron |
| Vane Count | 60 Curved Vane |
| Bedded | No |
| Balanced | Yes |
| Hat Type | Parking Brake Hat - Truck |
| Hat Finish | Black E-Coat |
| Hub Material | Aluminum |
| Hat Offset Dimension | 3.41" |
| Front Rotor Thickness | 1.50" |
| Front Caliper Material | Forged Billet Aluminum |
| Front Caliper Color | Gray/Silver |
| Brake Lines Included | No |
| Parking Brake Cables Included | No |
| Brake Hose Material | Rubber |
| Front Rotor Style | Slotted |
| Front Rotor Type | Vented |
| Bearings Included | Yes |
| Bracket Color | Zinc plated |
| Bracket Included | Yes |
| Brake Pads Included | Yes |
| Caliper Color | Red |
| Caliper Material Type | Forged Aluminum |
| Caliper Series | Wilwood |
| Fitting Attachment 1 | Female NPT |
| Fittings Included | Yes |
| For Use with Stock Calipers | No |
| Front Rotor Construction | Vented |
| Intended for Street Use | Yes |
| Piston Diameter | 2" |
| Hub Finish | Anodized |
| Hat Bolt Circle 1 | 8 x 6.69 |
Be the first to ask a question.
2005-2012 Ford F-250
2005-2012 Ford F-250 Super Duty
2005-2012 Ford F-350
2005-2012 Ford F-350 Super Duty
