Wilwood 140-12724 Pro Series Front Disc Brake Kit, 42-56 Packard

$151 Off

Wilwood 140-12724 Pro Series Front Disc Brake Kit, 42-56 Packard
Wilwood

|

#83514012724

Wilwood 140-12724 Pro Series Front Disc Brake Kit, 42-56 Packard

$1,260.14

/each

Factory Shipped

$1,411.35

Save $151.21


Quantity

Need Help? Call to Order

Add to a list

Share

Select a vehicle to verify Fitment

Select Vehicle

Product Summary

Front Position, 11.75 Inch Rotor Diameter, Black

    See more details

    Key Specs

    MFG. Part #140-12724
    PositionFront
    Rotor Diameter11.75 Inch
    Rotor TypeVented
    Caliper PistonsFour
    See more specs

    Need To Know

    Need help?

    855.313.9176
    View the Help Center

    Quick and Easy Returns

    Return Policy

    Wilwood 140-12724 Details

    FDLI Pro-Series Front Hub Kits offer complete disc brake upgrade solutions for traditional non-ABS spindle applications on American muscle cars, vintage rods, and heavy weight drag cars. Based on the venerable forged billet Dynalite caliper, these versatile kits are easily optioned to suit the braking requirements and style preferences for a daily driver, serious competition, or the most discriminating show enthusiast. Most kits require no modifications for installation, and provide plenty of clearance inside popular 15" wheels. FDLI Pro-Series kits can be used with either manual or power boost master cylinders.

    Application

    Packard 200 1951-1952 All
    Packard 250 1951-1952 All
    Packard 300 1951-1952 All
    Packard Caribbean 1956 5688, All
    Packard Caribbean 1955 Base
    Packard Cavalier 1953 2602 All
    Packard Cavalier 1954 5402, All
    Packard Clipper 1953 2601 & 2611 All
    Packard Clipper 1954 5411 , Clipper w/ 12" Drums
    Packard Deluxe Eight 1948-1950 Base
    Packard Executive 1956 5670, All
    Packard Four Hundred 1955 5580, All
    Packard Four Hundred 1956 5680, All
    Packard Model 2000 1942 Base
    Packard Model 2001 1942 Base
    Packard Model 2010 1942 Base
    Packard Model 2011 1942 Base
    Packard Model 2020 1942 Base
    Packard Model 2021 1942 Base
    Packard Model 2030 1942 Base
    Packard Model 2100 1946-1947 Base
    Packard Model 2101 1946 Base
    Packard Model 2111 1946-1947 Base
    Packard Model 2130 1946 Base
    Packard Model 2201 1948 Base
    Packard Model 2202 1948 Base
    Packard Model 2211 1948 Base
    Packard Model 2301 1949 Base
    Packard Model 2302 1949 Base
    Packard Model 2332 1949 Base
    Packard  1954 Base
    Packard  1954 Caribbean Custom
    Packard  1954 Pacific
    Packard Patricain 1953 2606 All
    Packard Patricain 1954 5406, All
    Packard Patricain 1955 5580, All
    Packard Patricain 1956 5680, All
    Packard Patrician 1951-1952 Base
    Packard Standard Eight 1948-1950 Base
    Packard Super Deluxe Eight 1949-1950 Base
    Packard Super Eight 1948-1950 All

    Charts

    Specs

    Our rotors are machined and fully e-coated, just like the rotor hats. This is a protectant coating the prohibits surface rust from forming on the exposed surfaces. Once the parts are installed and being bedded in, the brake pad friction and caliper pressure will remove the coating at the spot the brake pads touch. This will expose the silver iron material underneath.

    Wilwood 140-12724 Specifications

    KEY SPECS
    MFG. Part #140-12724
    BrandWilwood
    PositionFront
    Rotor Diameter11.75 Inch
    Rotor TypeVented
    Caliper PistonsFour
    Caliper FinishPowder Coated
    Parking Brake ProvisionNo
    Minimum Recommended Wheel Diameter15 Inch
    Rotor ShapeRound
    Hardware IncludedYes
    Rotor StylePlain Face
    Spindle TypeFactory Drum Spindle
    Front Rotor IncludedYes
    Front Rotor Diameter11.75 Inch
    Front Caliper IncludedYes
    Rear Caliper IncludedNo
    Front Spindles IncludedNo
    Master Cylinder IncludedNo
    Brake Booster IncludedNo
    Brake Hoses IncludedYes
    Rear Rotor IncludedNo
    ColorBlack
    Bolt Pattern5 on 4.75" | 5"
    Front Caliper Piston Quantity4
    Front Caliper FinishPowder Coated
    GENERAL
    GTIN Code889545017311
    Rotor Thickness0.81"
    Stud Diameter1/2-20
    Mount TypeLug
    OE Hub Offset0.92"
    Total Piston Area4.80 sq. in.
    Piston TypeStainless
    Pad Area6.36 sq. in.
    Pad Volume2.1 cu. in.
    Brake Pad CompoundBP-10
    Caliper TypeLug
    Rotor FinishNatural
    Rotor Material TypeIron
    Vane Count32 Straight Vane
    BeddedNo
    BalancedNo
    Brake Lines IncludedNo
    Caliper ColorBlack
    Caliper Material TypeForged Aluminum
    Stud Diameter 21/2-20
