Wilwood 140-12649-D FDLI Pro Series Front Disc Brake Kit,41-55 Cadillac

$104 Off

Wilwood 140-12649-D FDLI Pro Series Front Disc Brake Kit,41-55 Cadillac
Wilwood

|

#83514012649D

Wilwood 140-12649-D FDLI Pro Series Front Disc Brake Kit,41-55 Cadillac

Rotor / Caliper Type:

Drilled

UndrilledDrilled / Red

$1,267.99

/each

Factory Shipped

$1,372.13

Save $104.14


Quantity

Need Help? Call to Order

Add to a list

Share

Select a vehicle to verify Fitment

Select Vehicle

Product Summary

Front Position, 11.75 Inch Rotor Diameter, Black

    See more details

    Key Specs

    MFG. Part #140-12649-D
    PositionFront
    Rotor Diameter11.75 Inch
    Rotor TypeVented
    Caliper PistonsFour
    See more specs

    Need To Know

    Need help?

    855.313.9176
    View the Help Center

    Quick and Easy Returns

    Return Policy

    Wilwood 140-12649-D Details

    FDLI Pro-Series Front Hub Kits offer complete disc brake upgrade solutions for traditional non-ABS spindle applications on American muscle cars, vintage rods, and heavy weight drag cars. Based on the venerable forged billet Dynalite caliper, these versatile kits are easily optioned to suit the braking requirements and style preferences for a daily driver, serious competition, or the most discriminating show enthusiast. Most kits require no modifications for installation, and provide plenty of clearance inside popular 15" wheels. FDLI Pro-Series kits can be used with either manual or power boost master cylinders.

    Application

    1941 Cadillac Series 63 All
    1941 Cadillac Series 67 All
    1942 Cadillac Series 60 All
    1942 Cadillac Series 61 All
    1942 Cadillac Series 62 All
    1942 Cadillac Series 67 All
    1946 Cadillac Series 61 All
    1946 Cadillac Series 62 All
    1947 Cadillac Series 61 All
    1947 Cadillac Series 62 All
    1948 Cadillac Series 61 All
    1948 Cadillac Series 62 All
    1949 Cadillac Series 61 All
    1949 Cadillac Series 62 All
    1950 Cadillac Series 61 All
    1950 Cadillac Series 62 All
    1951 Cadillac Series 61 All
    1951 Cadillac Series 62 All
    1952 Cadillac Series 62 All
    1953 Cadillac DeVille All
    1953 Cadillac Eldorado All
    1953 Cadillac Series 62 All
    1954 Cadillac DeVille All
    1954 Cadillac Eldorado All
    1954 Cadillac Series 62 All
    1955 Cadillac DeVille All
    1955 Cadillac Eldorado All
    1955 Cadillac Series 62 All

    Charts

    Specs

    Our rotors are machined and fully e-coated, just like the rotor hats. This is a protectant coating the prohibits surface rust from forming on the exposed surfaces. Once the parts are installed and being bedded in, the brake pad friction and caliper pressure will remove the coating at the spot the brake pads touch. This will expose the silver iron material underneath.

    Wilwood 140-12649-D Specifications

    KEY SPECS
    MFG. Part #140-12649-D
    BrandWilwood
    PositionFront
    Rotor Diameter11.75 Inch
    Rotor TypeVented
    Caliper PistonsFour
    Caliper FinishPowder Coated
    Parking Brake ProvisionNo
    Minimum Recommended Wheel Diameter15 Inch
    Rotor ShapeRound
    Hardware IncludedYes
    Rotor StyleDrilled & Slotted
    Spindle TypeFactory Drum Spindle
    Front Rotor IncludedYes
    Front Rotor Diameter11.75 Inch
    Front Caliper IncludedYes
    Rear Caliper IncludedNo
    Front Spindles IncludedNo
    Master Cylinder IncludedNo
    Brake Booster IncludedNo
    Brake Hoses IncludedYes
    Rear Rotor IncludedNo
    Bolt Pattern5 on 5"
    ColorBlack
    Front Caliper Piston Quantity4
    Front Caliper FinishPowder Coated
    GENERAL
    GTIN Code889545017281
    Rotor Thickness0.81"
    Stud Diameter1/2-20
    Mount TypeLug
    OE Hub Offset0.35"
    Total Piston Area4.80 sq. in.
    Piston TypeStainless
    Pad Area6.36 sq. in.
    Pad Volume2.1 cu. in.
    Brake Pad CompoundBP-10
    Caliper TypeLug
    Rotor FinishBlack E-Coat
    Rotor Material TypeIron
    Vane Count32 Straight Vane
    BeddedNo
    BalancedNo
    Brake Lines IncludedNo
    Caliper ColorBlack
    Caliper Material TypeForged Aluminum
