Product Summary

Front Position, 14 Inch Rotor Diameter, Powder Coated

    See more details

    Key Specs

    MFG. Part #140-12465-D
    PositionFront
    Wheel Bolt Pattern (in.)5x4.75 in.
    Wheel Bolt Pattern (mm)5x120.65 mm
    Rotor Diameter14 Inch
    See more specs

    Need To Know

    Quick and Easy Returns

    Return Policy

    Wilwood 140-12465-D Details

    FNSL6R billet Forged six-piston calipers with 13"-14" rotors deliver the ultimate combination for braking power and style in this group of kits engineered for traditional non-ABS spindles on American muscle cars and vintage rods. Built exclusively for 17" and larger wheels, SL6 kits enhance tire and suspension upgrades on all types of custom show and high performance dual-purpose street and track machines. A full range of options for caliper finishes and rotor designs are guaranteed to catch the eye of the most discriminating enthusiast while providing optimized brake performance for every individual application.

    Application

    1959 Chevrolet Biscayne All
    1959 Chevrolet Brookwood All
    1959 Chevrolet El Camino All
    1959 Chevrolet Impala All
    1960 Chevrolet Biscayne All
    1960 Chevrolet Brookwood All
    1960 Chevrolet El Camino All
    1960 Chevrolet Impala All
    1961 Chevrolet Biscayne All
    1961 Chevrolet Brookwood All
    1961 Chevrolet Impala All
    1962 Chevrolet Biscayne All
    1962 Chevrolet Impala All
    1963 Chevrolet Biscayne All
    1963 Chevrolet Corvette C-2
    1963 Chevrolet Impala All
    1964 Chevrolet Biscayne All
    1964 Chevrolet Corvette C-2
    1964 Chevrolet Impala All

    Charts

    Specs

    Our rotors are machined and fully e-coated, just like the rotor hats. This is a protectant coating the prohibits surface rust from forming on the exposed surfaces. Once the parts are installed and being bedded in, the brake pad friction and caliper pressure will remove the coating at the spot the brake pads touch. This will expose the silver iron material underneath.

    Wilwood 140-12465-D Specifications

    KEY SPECS
    MFG. Part #140-12465-D
    BrandWilwood
    PositionFront
    Wheel Bolt Pattern (in.)5x4.75 in.
    Wheel Bolt Pattern (mm)5x120.65 mm
    Rotor Diameter14 Inch
    Rotor TypeVented
    Caliper PistonsSix
    Caliper FinishPowder Coated
    Parking Brake ProvisionNo
    Minimum Recommended Wheel Diameter18 Inch
    Rotor ShapeRound
    Hardware IncludedYes
    Rotor StyleDrilled & Slotted
    Spindle TypeFactory Drum Spindle
    Front Rotor IncludedYes
    Front Rotor Diameter14 Inch
    Front Caliper IncludedYes
    Rear Caliper IncludedNo
    Front Spindles IncludedNo
    Master Cylinder IncludedNo
    Brake Booster IncludedNo
    Brake Hoses IncludedYes
    Rear Rotor IncludedNo
    ColorBlack
    Front Caliper Piston Quantity6
    Bolt Pattern5 on 4.5" | 4.75"
    Front Caliper FinishPowder Coated
    GENERAL
    GTIN Code889545016635
    Rotor Thickness1.1"
    Stud Diameter0.52"
    Mount TypeRadial
    OE Hub Offset0.21"
    Total Piston Area4.04 sq. in.
    Piston TypeStainless
    Pad Area8.20 sq. in.
    Pad Volume3.8 cu. in.
    Brake Pad CompoundBP-10
    Caliper TypeRadial
    Rotor FinishBlack E-Coat
    Rotor Material TypeSpec-37 Iron
    Vane Count72 Curved Vane
    BeddedNo
    BalancedYes
    Hat TypeBig Brake Hat - Flared Bell
    Hat FinishBlack E-Coat
    Hat Material TypeAluminum
    Hat Offset Dimension1.50"
    Brake Lines IncludedNo
    Caliper ColorBlack
    Caliper Material TypeForged Aluminum
    Hat Bolt Circle 15 x 4.50
    Hat Bolt Circle 25 x 4.75
    Stud Diameter 20.52"
