Wilwood 140-12276-R Art Morrison Big Front Brake Kit

Ask a Question

FNSL6R billet Forged six-piston calipers
1 piece rotor and hats kits deliver the cost effective combination for braking power and style in this group of kits engineered 1960 to 1968 Ford & Mercury full size vehicles
Built exclusively for 17” and larger wheels, FNSL6 kits enhance tire and suspension upgrades on all types of custom show and high performance dual-purpose street and track machines

$1,458.49

Factory Shipped

This part will be shipped by the manufacturer. We estimate this item will ship on or before October 3rd.

Add to a list

Select a vehicle to verify Fitment

Select Vehicle

Product Summary

Front Position, 5 on 4.5" | 4.75" Bolt Pattern, Red

FNSL6R billet Forged six-piston calipers
1 piece rotor and hats kits deliver the cost effective combination for braking power and style in this group of kits engineered 1960 to 1968 Ford & Mercury full size vehicles
Built exclusively for 17” and larger wheels, FNSL6 kits enhance tire and suspension upgrades on all types of custom show and high performance dual-purpose street and track machines
A full range of options for caliper finishes and rotor designs are guaranteed to catch the eye of the most discriminating enthusiast while providing optimized brake performance for every individual application

See more details

Key Specs

Position	Front
Bolt Pattern	5 on 4.5" \| 4.75"
Rotor Diameter	12.88 Inch
Rotor Type	Vented
Caliper Pistons	Six

See more specs

Need To Know

This Product Will Ship Free

Need help?

Quick and Easy Returns

Wilwood 140-12276-R Details

FNSL6R Billet Forged six-piston calipers with 12
88" diameter, 1 piece rotor and hats kits deliver the cost effective combination for braking power and style in this group of kits engineered for traditional non-ABS spindles on American muscle cars and vintage rods
Built exclusively for 17” and larger wheels, FNSL6 kits enhance tire and suspension upgrades on all types of custom show and high performance dual-purpose street and track machines
A full range of options for caliper finishes and rotor designs are guaranteed to catch the eye of the most discriminating enthusiast while providing optimized brake performance for every individual application

Guides & Documents

Everything You Need to Know About Converting Drum Brakes to Disc

Disc Brake Kits Instruction Sheet (83514012276R)

CA Prop 65

Wilwood 140-12276-R Specifications

KEY SPECS
MFG. Part #	140-12276-R
Brand	Wilwood
Position	Front
Bolt Pattern	5 on 4.5" \| 4.75"
Rotor Diameter	12.88 Inch
Rotor Type	Vented
Caliper Pistons	Six
Caliper Finish	Powder Coated
Color	Red
Parking Brake Provision	No
Minimum Recommended Wheel Diameter	17 Inch
Hardware Included	Yes
Spindle Type	Factory Disc Spindle
Rotor Style	Slotted
Front Rotor Included	Yes
Front Rotor Diameter	12.88 in./327.20mm
Front Caliper Included	Yes
Front Caliper Piston Quantity	Six
Rear Caliper Included	No
Front Spindles Included	No
Master Cylinder Included	No
Brake Booster Included	No
Brake Hoses Included	No
Rear Rotor Included	No

GENERAL
Rotor Thickness	1.1"
Stud Diameter	1/2-20
Sold in Quantity	Kit
Notes	Includes 1/2 in.-20 wheel studs. Designed for use with Wilwood ProSpindle.
Offset	0.55"
Mount Type	Radial
OE Hub Offset	0.55"
Total Piston Area	4.04 sq. in.
Piston Type	Stainless
Pad Area	8.20 sq. in.
Pad Volume	3.8 cu. in.
Brake Pad Compound	BP-10
Caliper Type	Radial
Rotor Finish	Natural
Rotor Material Type	Iron
Vane Count	34 Straight Vane
Bedded	No
Balanced	No
Stud Diameter 2	1/2-20
GTIN Code	889545015904
Front Rotor Thickness	1.10"
Front Caliper Material	Forged Billet Aluminum
Front Caliper Color	Red
Brake Lines Included	No
Front Rotor Style	Slotted
Caliper Color	Red
Caliper Material Type	Forged Aluminum
Front Rotor Construction	Vented
