Wilwood 140-12102-BK D154 Rear Brake Kit,1.12 / 1.12 Piston,0.81 Rotor

#83514012102BK

Wilwood 140-12102-BK D154 Rear Brake Kit,1.12 / 1.12 Piston,0.81 Rotor

Name: Wilwood 140-12102-BK D154 Rear Brake Kit,1.12 / 1.12 Piston,0.81 Rotor
Brand: Wilwood
SKU: 83514012102BK
Price: 501.07 USD
Availability: InStock

Write a Review

1 Question

Color:

Black

Polish Red

$501.07

/each

Factory Shipped

$522.86

Save $21.79

Quantity

Need Help? Call to Order

Add to a list

Select a vehicle to verify Fitment

Select Vehicle

Product Summary

Two Caliper Pistons, 1.12" Piston Diameter, Black

See more details

Key Specs

Caliper Pistons	Two
Fitting Attachment 1	Banjo
Parking Brake Provision	No
Fittings Included	No
Brake Pads Included	Yes

See more specs

Need To Know

Need help?

855.313.9176

View the Help Center

Quick and Easy Returns

Return Policy

Wilwood 140-12102-BK Details

Wilwood's D154 Rear Caliper Kit offers a matching rear replacement option for our front D154 calipers. It is a direct bolt-on 2-piston replacement for the factory original single piston "Metric" calipers used on many custom application rears. With the added benefit of smaller rear piston sizing (1.96 sq-inches of area) not normally available in OEM calipers, for correct front and rear bias. Forged billet aluminum bodies, stainless steel pistons, and competition style high-temperature seals put an end to the rust, bore pitting, and seal failures that plague the OE caliper design. D154 calipers provide low-maintenance performance and a huge weight savings with high temperature reliability for the street and track. D52 calipers mount in the stock location over stock rotors; use the original style OE D154 brake pads and an OE M10-1.5 banjo bolt brake line mounting. Calipers can be used with most wheels that clear the OE calipers. Kits contain Wilwoods hardened slide pins and BP-10 high friction pads.

Charts

Installation Instructions (PDF)

Guides & Documents

Brake Calipers Installation Instructions (83514012102BK)

Wilwood 140-12102-BK Specifications

KEY SPECS
MFG. Part #	140-12102-BK
Brand	Wilwood
Caliper Pistons	Two
Fitting Attachment 1	Banjo
Parking Brake Provision	No
Fittings Included	No
Brake Pads Included	Yes
Caliper Finish	Powder Coated

GENERAL
Piston Diameter	1.12"
Caliper Material Type	Aluminum
Caliper Color	Black
Thread Size	M10 x 1.5
Bracket Included	No
Color	Black
Rotor Thickness	0.81"
Total Piston Area	1.98 sq. in.
Pad Area	8.70 sq. in.
Pad Volume	2.90 cu. in.
Offset	0"
Mount Type	Floating
Caliper Type	D154
Piston Type	Stainless
Brake Pad Compound	BP-10
Brake Pad Material	Semi-metallic
Position	Rear
GTIN Code	889545015188
Logo	Wilwood
