Wilwood 140-11940-R FDLI Pro Series Front Disc Brake Kit, 1969-76 AMC

-7%

Wilwood 140-11940-R FDLI Pro Series Front Disc Brake Kit, 1969-76 AMC
Wilwood

|

#83514011940R

Wilwood 140-11940-R FDLI Pro Series Front Disc Brake Kit, 1969-76 AMC

Rotor / Caliper Type:

Undrilled / Red

UndrilledDrilled / Red

$1,149.59

/each

Factory Shipped

$1,244.00

Save $94.41


Quantity

Need Help? Call to Order

Add to a list

Share

Select a vehicle to verify Fitment

Select Vehicle

Product Summary

Front Position, 11 Inch Rotor Diameter, Powder Coated

    See more details

    Key Specs

    MFG. Part #140-11940-R
    PositionFront
    Wheel Bolt Pattern (in.)5x4.5 in. | 5x4.75 in.
    Wheel Bolt Pattern (mm)5x114.3 mm | 5x120.65 mm
    Rotor Diameter11 Inch
    See more specs

    Need To Know

    Need help?

    855.313.9176
    View the Help Center

    Quick and Easy Returns

    Return Policy

    Wilwood 140-11940-R Details

    FDLI Pro-Series Front Hub Kits offer complete disc brake upgrade solutions for OEM disc brake spindle applications for the popular AMC Passenger vehicles originally equipped with Kelsey-Hayes calipers. Based on the venerable forged billet Dynalite caliper and 11.00" x .81 rotors, these versatile kits are easily optioned to suit the braking requirements and style preferences for a daily driver, serious competition, or the most discriminating show enthusiast. This kit requires no modifications for installation, and provides plenty of clearance inside most popular 15" wheels. This kit will also work with aftermarket 14" disc brake steel wheels available from other vendors. FDLI Pro-Series kits can be used with either manual or power boost master cylinders.

    Application

    1969 American Motors Ambassador Disc Brake Spindle
    1969 American Motors AMX Disc Brake Spindle
    1969 American Motors Javelin Disc Brake Spindle
    1969 American Motors Rambler Disc Brake Spindle
    1969 American Motors Rebel Disc Brake Spindle
    1970 American Motors Ambassador Disc Brake Spindle
    1970 American Motors AMX Disc Brake Spindle
    1970 American Motors Hornet Disc Brake Spindle
    1970 American Motors Javelin Disc Brake Spindle
    1970 American Motors Rebel Disc Brake Spindle
    1971 American Motors Ambassador Disc Brake Spindle
    1971 American Motors AMX Disc Brake Spindle
    1971 American Motors Gremlin Disc Brake Spindle
    1971 American Motors Hornet Disc Brake Spindle
    1971 American Motors Javelin Disc Brake Spindle
    1971 American Motors Matador Disc Brake Spindle
    1972 American Motors Ambassador Disc Brake Spindle
    1972 American Motors AMX Disc Brake Spindle
    1972 American Motors Gremlin Disc Brake Spindle
    1972 American Motors Hornet Disc Brake Spindle
    1972 American Motors Javelin Disc Brake Spindle
    1972 American Motors Matador Disc Brake Spindle
    1973 American Motors Ambassador Disc Brake Spindle
    1973 American Motors AMX Disc Brake Spindle
    1973 American Motors Gremlin Disc Brake Spindle
    1973 American Motors Hornet Disc Brake Spindle
    1973 American Motors Javelin Disc Brake Spindle
    1973 American Motors Matador Disc Brake Spindle
    1974 American Motors Ambassador Disc Brake Spindle, Kelsey Hayes Calipers
    1974 American Motors AMX Disc Brake Spindle
    1974 American Motors Gremlin Disc Brake Spindle, Kelsey Hayes Calipers
    1974 American Motors Hornet Disc Brake Spindle, Kelsey Hayes Calipers
    1974 American Motors Javelin Disc Brake Spindle, Kelsey Hayes Calipers
    1974 American Motors Matador Disc Brake Spindle, Kelsey Hayes Calipers
    1975 American Motors Gremlin Disc Brake Spindle, Kelsey Hayes Calipers
    1975 American Motors Hornet Disc Brake Spindle, Kelsey Hayes Calipers
    1976 American Motors Gremlin Disc Brake Spindle, Kelsey Hayes Calipers
    1976 American Motors Hornet Disc Brake Spindle, Kelsey Hayes Calipers

    Charts

    Specs

    Our rotors are machined and fully e-coated, just like the rotor hats. This is a protectant coating the prohibits surface rust from forming on the exposed surfaces. Once the parts are installed and being bedded in, the brake pad friction and caliper pressure will remove the coating at the spot the brake pads touch. This will expose the silver iron material underneath.

    Wilwood 140-11940-R Specifications

    KEY SPECS
    MFG. Part #140-11940-R
    BrandWilwood
    PositionFront
    Wheel Bolt Pattern (in.)5x4.5 in. | 5x4.75 in.
    Wheel Bolt Pattern (mm)5x114.3 mm | 5x120.65 mm
    Rotor Diameter11 Inch
    Rotor TypeVented
    Caliper PistonsFour
    Caliper FinishPowder Coated
    Parking Brake ProvisionNo
    Minimum Recommended Wheel Diameter14 Inch
    Rotor ShapeRound
    Hardware IncludedYes
    Rotor StylePlain Face
    Spindle TypeFactory Disc Spindle
    Front Rotor IncludedYes
    Front Rotor Diameter11 Inch
    Front Caliper IncludedYes
    Rear Caliper IncludedNo
    Front Spindles IncludedNo
    Master Cylinder IncludedNo
    Brake Booster IncludedNo
    Brake Hoses IncludedYes
    Rear Rotor IncludedNo
    ColorRed
    Bolt Pattern5 on 4.5" | 4.75"
    Front Caliper Piston Quantity4
    Front Caliper FinishPowder Coated
    GENERAL
    GTIN Code889545014549
    Rotor Thickness0.81"
    Stud Diameter1/2-20
    Mount TypeLug
    Total Piston Area4.80 sq. in.
    Piston TypeStainless
    Pad Area6.36 sq. in.
    Pad Volume2.1 cu. in.
    Brake Pad CompoundBP-10
    Caliper TypeLug
    Rotor FinishNatural
    Rotor Material TypeIron
    Vane Count30 Straight Vane
    BeddedNo
    BalancedNo
    Brake Lines IncludedNo
    Caliper ColorRed
    Caliper Material TypeForged Aluminum
    Stud Diameter 21/2-20
