$103 Off
$103 Off
|
#83514011399DR
$1,256.75
/each
Factory Shipped
$1,359.96
Save $103.21
Quantity
Need Help? Call to Order
Add to a list
Select a vehicle to verify Fitment
Select Vehicle
| MFG. Part # | 140-11399-DR |
| Position | Rear |
| Wheel Bolt Pattern (in.) | 5x4.5 in. | 5x4.75 in. |
| Wheel Bolt Pattern (mm) | 5x114.3 mm | 5x120.65 mm |
| Rotor Diameter | 11 Inch |
Need help?
855.313.9176Quick and Easy Returns
Return PolicyApplication
Charts
Specs
| KEY SPECS | |
|---|---|
| MFG. Part # | 140-11399-DR |
| Brand | Wilwood |
| Position | Rear |
| Wheel Bolt Pattern (in.) | 5x4.5 in. | 5x4.75 in. |
| Wheel Bolt Pattern (mm) | 5x114.3 mm | 5x120.65 mm |
| Rotor Diameter | 11 Inch |
| Rotor Type | Vented |
| Caliper Pistons | Four |
| Caliper Finish | Powder Coated |
| Parking Brake Provision | Yes |
| Minimum Recommended Wheel Diameter | 14 Inch |
| Rotor Shape | Round |
| Hardware Included | Yes |
| Rotor Style | Drilled & Slotted |
| Front Rotor Included | No |
| Front Caliper Included | No |
| Rear Caliper Included | Yes |
| Front Spindles Included | No |
| Master Cylinder Included | No |
| Brake Booster Included | No |
| Brake Hoses Included | Yes |
| Rear Rotor Included | Yes |
| Color | Red |
| Bolt Pattern | 5 on 4.5" | 4.75" |
| GENERAL | |
| GTIN Code | 889545013283 |
| Rotor Thickness | 0.81" |
| Offset | 2.75" |
| Axle Flange Offset | 2.75" |
| Mount Type | Lug |
| Total Piston Area | 1.98 sq. in. |
| Piston Type | Stainless |
| Pad Area | 5.1 sq. in. |
| Pad Volume | 1.71 cu. in. |
| Brake Pad Compound | BP-10 |
| Caliper Type | Lug |
| Rotor Finish | Black E-Coat |
| Rotor Material Type | Iron |
| Vane Count | 32 Straight Vane |
| Bedded | No |
| Balanced | No |
| Brake Lines Included | No |
| Caliper Color | Red |
| Caliper Material Type | Forged Aluminum |
Be the first to ask a question.
1993-1997 Chevy Camaro
1993-1997 Pontiac Firebird
