$154 Off

Wilwood FDP-LP 11.00 Inch Parking Brake Kit, Chevy 12-Bolt

$154 Off

Wilwood FDP-LP 11.00 Inch Parking Brake Kit, Chevy 12-Bolt
Wilwood

|

#UP232623

Wilwood FDP-LP 11.00 Inch Parking Brake Kit, Chevy 12-Bolt

  • Open Box
  • Item is in like-new condition. Original packaging may be damaged or missing. Please review the description for additional details
  • 11" rotor is designed to clear 14"-up wheels
See More

$1,186.93

/each

In Stock

$1,340.56

Save $153.63

Order soon, only 1 left in stock!

Item is in like-new condition. Original packaging may be damaged or missing. Please review the description for additional details.

Buy it brand new for $1,196.93

Quantity

Need Help? Call to Order

Add to a list

Share

Select a vehicle to verify Fitment

Select Vehicle

Product Summary

GM 8.2 Inch 10-Bolt Chevy 64-72, GM 8.5 Inch 10-Bolt

  • Open Box
  • Item is in like-new condition. Original packaging may be damaged or missing. Please review the description for additional details
  • 11" rotor is designed to clear 14"-up wheels
  • Features 4 piston calipers that are powder coated black for enhanced corrosion protection
  • High friction pads provide optimized and balanced braking for all types of custom performance street/strip and show machines
  • A neatly hidden internal shoe system provides a clean installation with superior static holding power for parking
  • Rotor features a drilled and slotted design for excellent heat dissipation
See more details

Key Specs

Garage Sale TypeOpen Box
PositionRear
Wheel Bolt Pattern (in.)5x4.5 in. | 5x4.75 in.
Wheel Bolt Pattern (mm)5x114.3 mm | 5x120.65 mm
Rotor Diameter11 Inch
See more specs

Need To Know

Need help?

855.313.9176
View the Help Center

Ineligible for Return

Contains items that cannot be returned

Wilwood 140-11398-D Details

Garage Sale Product

This is Garage Sale priced because it is a factory shipped open box item and returned that we don't carry in house.

NO WARRANTY, NO RETURNS ON GARAGE SALE ITEMS

Forged Dynapro Low-Profile Pro-Series rear disc brake kits provide a complete solution for popular muscle car rear axles on applications that require a parking brake assembly and extra clearance for 14.00" to 15.00" rim applications. Forged billet Dynapro Low-Profile four-piston calipers 11.00" one-piece hat and rotor assemblies, and high friction pads provide optimized and balanced braking for all types of custom performance street/strip and show machines. The neatly hidden internal shoe system provides a clean installation with superior static holding power for parking. Optional caliper finishes and rotor designs enable the builder to personalize the style and optimize brake performance for every individual application.

Charts

Specs

Our rotors are machined and fully e-coated, just like the rotor hats. This is a protectant coating the prohibits surface rust from forming on the exposed surfaces. Once the parts are installed and being bedded in, the brake pad friction and caliper pressure will remove the coating at the spot the brake pads touch. This will expose the silver iron material underneath.

Wilwood 140-11398-D Specifications

KEY SPECS
MFG. Part #140-11398-D
BrandWilwood
Garage Sale TypeOpen Box
PositionRear
Wheel Bolt Pattern (in.)5x4.5 in. | 5x4.75 in.
Wheel Bolt Pattern (mm)5x114.3 mm | 5x120.65 mm
Rotor Diameter11 Inch
Rotor TypeVented
Caliper PistonsFour
Caliper FinishPowder Coated
Parking Brake ProvisionYes
Minimum Recommended Wheel Diameter14 Inch
Rotor ShapeRound
Hardware IncludedYes
Rotor StyleDrilled & Slotted
Front Rotor IncludedNo
Front Caliper IncludedNo
Rear Caliper IncludedYes
Front Spindles IncludedNo
Master Cylinder IncludedNo
Brake Booster IncludedNo
Brake Hoses IncludedYes
Rear Rotor IncludedYes
ColorBlack
Bolt PatternBlank
GENERAL
Rotor Thickness0.81"
Offset2.75"
Axle Flange Offset2.75"
Mount TypeLug
Total Piston Area1.98 sq. in.
Piston TypeStainless
Pad Area5.1 sq. in.
Pad Volume1.71 cu. in.
Brake Pad CompoundBP-10
Caliper TypeLug
Rotor FinishBlack E-Coat
Rotor Material TypeIron
Vane Count32 Straight Vane
BeddedNo
BalancedNo
Brake Lines IncludedNo
Caliper ColorBlack
Caliper Material TypeForged Aluminum
