Wilwood 140-11275-DR FDLI Front Disc Brake Kit, 1982-92 Camaro/Firebird

$105 Off

Wilwood 140-11275-DR FDLI Front Disc Brake Kit, 1982-92 Camaro/Firebird
Wilwood

|

#83514011275DR

Wilwood 140-11275-DR FDLI Front Disc Brake Kit, 1982-92 Camaro/Firebird

Rotor / Caliper Type:

Drilled / Red

UndrilledDrilledUndrilled / Red

$1,281.44

/each

Factory Shipped

$1,386.67

Save $105.23


Quantity

Need Help? Call to Order

Add to a list

Share

Select a vehicle to verify Fitment

Select Vehicle

Product Summary

Front Position, 12.19 Inch Rotor Diameter, Red

    See more details

    Key Specs

    MFG. Part #140-11275-DR
    PositionFront
    Wheel Bolt Pattern (in.)5x4.75 in.
    Wheel Bolt Pattern (mm)5x120.65 mm
    Rotor Diameter12.19 Inch
    See more specs

    Need To Know

    Need help?

    855.313.9176
    View the Help Center

    Quick and Easy Returns

    Return Policy

    Wilwood 140-11275-DR Details

    FDLI Big Brake Front Hub Kits provide the added advantage of larger diameter brake rotors for traditional non-ABS spindles on American muscle cars and vintage rods. Forged billet Dynalite calipers, 12.19" diameter rotors, and high performance Wilwood brake pads generate big brake stopping power to compliment wheel, tire, and suspension upgrades on all types of custom show and performance street / strip machines. A full range of options for caliper finish and rotor design provide custom builders with the ability to personalize the style and performance requirements of the mildest to the wildest machines.

    Application

    1982 Chevrolet Camaro Disc Brake Rear
    1982 Chevrolet Camaro Drum Brake Rear
    1982 Pontiac Firebird Disc Brake Rear
    1982 Pontiac Firebird Drum Brake Rear
    1983 Chevrolet Camaro Disc Brake Rear
    1983 Chevrolet Camaro Drum Brake Rear
    1983 Pontiac Firebird Disc Brake Rear
    1983 Pontiac Firebird Drum Brake Rear
    1984 Chevrolet Camaro Disc Brake Rear
    1984 Chevrolet Camaro Drum Brake Rear
    1984 Pontiac Firebird Disc Brake Rear
    1984 Pontiac Firebird Drum Brake Rear
    1985 Chevrolet Camaro Disc Brake Rear
    1985 Chevrolet Camaro Drum Brake Rear
    1985 Pontiac Firebird Disc Brake Rear
    1985 Pontiac Firebird Drum Brake Rear
    1986 Chevrolet Camaro Disc Brake Rear
    1986 Chevrolet Camaro Drum Brake Rear
    1986 Pontiac Firebird Disc Brake Rear
    1986 Pontiac Firebird Drum Brake Rear
    1987 Chevrolet Camaro Disc Brake Rear
    1987 Chevrolet Camaro Drum Brake Rear
    1987 Pontiac Firebird Disc Brake Rear
    1987 Pontiac Firebird Drum Brake Rear
    1988 Chevrolet Camaro OE Single Piston Caliper Spindles, Disc Brake Rear
    1988 Chevrolet Camaro OE Single Piston Caliper Spindles, Drum Brake Rear
    1988 Pontiac Firebird OE Single Piston Caliper Spindles, Disc Brake Rear
    1988 Pontiac Firebird OE Single Piston Caliper Spindles, Drum Brake Rear
    1989 Chevrolet Camaro OE Single Piston Caliper Spindles, Disc Brake Rear
    1989 Chevrolet Camaro OE Single Piston Caliper Spindles, Drum Brake Rear
    1989 Pontiac Firebird OE Single Piston Caliper Spindles, Disc Brake Rear
    1989 Pontiac Firebird OE Single Piston Caliper Spindles, Drum Brake Rear
    1990 Chevrolet Camaro OE Single Piston Caliper Spindles, Disc Brake Rear
    1990 Chevrolet Camaro OE Single Piston Caliper Spindles, Drum Brake Rear
    1990 Pontiac Firebird OE Single Piston Caliper Spindles, Disc Brake Rear
    1990 Pontiac Firebird OE Single Piston Caliper Spindles, Drum Brake Rear
    1991 Chevrolet Camaro OE Single Piston Caliper Spindles, Disc Brake Rear
    1991 Chevrolet Camaro OE Single Piston Caliper Spindles, Drum Brake Rear
    1991 Pontiac Firebird OE Single Piston Caliper Spindles, Disc Brake Rear
    1991 Pontiac Firebird OE Single Piston Caliper Spindles, Drum Brake Rear
    1992 Chevrolet Camaro OE Single Piston Caliper Spindles, Disc Brake Rear
    1992 Chevrolet Camaro OE Single Piston Caliper Spindles, Drum Brake Rear
    1992 Pontiac Firebird OE Single Piston Caliper Spindles, Disc Brake Rear
    1992 Pontiac Firebird OE Single Piston Caliper Spindles, Drum Brake Rear

    Charts

    Specs

    Our rotors are machined and fully e-coated, just like the rotor hats. This is a protectant coating the prohibits surface rust from forming on the exposed surfaces. Once the parts are installed and being bedded in, the brake pad friction and caliper pressure will remove the coating at the spot the brake pads touch. This will expose the silver iron material underneath.

    Wilwood 140-11275-DR Specifications

    KEY SPECS
    MFG. Part #140-11275-DR
    BrandWilwood
    PositionFront
    Wheel Bolt Pattern (in.)5x4.75 in.
    Wheel Bolt Pattern (mm)5x120.65 mm
    Rotor Diameter12.19 Inch
    Rotor TypeVented
    Caliper PistonsFour
    Caliper FinishPowder Coated
    Parking Brake ProvisionNo
    Minimum Recommended Wheel Diameter15 Inch
    Rotor ShapeRound
    Hardware IncludedYes
    Rotor StyleDrilled & Slotted
    Spindle TypeFactory Disc Spindle
    Front Rotor IncludedYes
    Front Rotor Diameter12.19 Inch
    Front Caliper IncludedYes
    Rear Caliper IncludedNo
    Front Spindles IncludedNo
    Master Cylinder IncludedNo
    Brake Booster IncludedNo
    Brake Hoses IncludedYes
    Rear Rotor IncludedNo
    ColorRed
    Bolt Pattern5 on 4.5" | 4.75"
    Front Caliper Piston Quantity4
    Front Caliper FinishPowder Coated
    GENERAL
    GTIN Code889545012484
    Rotor Thickness0.81"
    Stud Diameter1/2-20
    Mount TypeLug
    OE Hub Offset0"
    Total Piston Area4.80 sq. in.
    Piston TypeStainless
    Pad Area6.36 sq. in.
    Pad Volume2.1 cu. in.
    Brake Pad CompoundBP-10
    Caliper TypeLug
    Rotor FinishBlack E-Coat
    Rotor Material TypeIron
    Vane Count32 Straight Vane
    BeddedNo
    BalancedNo
    Brake Lines IncludedNo
    Caliper ColorRed
    Caliper Material TypeForged Aluminum
    Stud Diameter 21/2-20
