Wilwood 140-10737-D DP6 12.19 Inch Front Disc Brake Kit, 1955-57 Chevy

$139 Off

Wilwood 140-10737-D DP6 12.19 Inch Front Disc Brake Kit, 1955-57 Chevy
Wilwood

|

#83514010737D

Wilwood 140-10737-D DP6 12.19 Inch Front Disc Brake Kit, 1955-57 Chevy

Rotor / Caliper Type:

Drilled

Undrilled / RedUndrilledDrilled / Red

$1,689.38

/each

Factory Shipped

$1,828.12

Save $138.74


Quantity

Need Help? Call to Order

Add to a list

Share

Select a vehicle to verify Fitment

Select Vehicle

Product Summary

Front Position, 12.19 Inch Rotor Diameter, Black

    See more details

    Key Specs

    MFG. Part #140-10737-D
    PositionFront
    Wheel Bolt Pattern (in.)5x4.5 in. | 5x4.75 in.
    Wheel Bolt Pattern (mm)5x114.3 mm | 5x120.65 mm
    Rotor Diameter12.19 Inch
    See more specs

    Need To Know

    Need help?

    855.313.9176
    View the Help Center

    Quick and Easy Returns

    Return Policy

    Wilwood 140-10737-D Details

    Wilwood 140-10737-D DP6 12.19 Inch Front Disc Brake Kit, 1955-57 ChevyWilwoodDisc Brake Kits140-10737-D

    Application

    1955 Chevrolet One-Fifty Series All, w/ OE Drum Brake Spindle
    1955 Chevrolet Two-Ten Series All, w/ OE Drum Brake Spindle
    1956 Chevrolet One-Fifty Series All, w/ OE Drum Brake Spindle
    1956 Chevrolet Two-Ten Series All, w/ OE Drum Brake Spindle
    1957 Chevrolet One-Fifty Series All, w/ OE Drum Brake Spindle
    1957 Chevrolet Two-Ten Series All, w/ OE Drum Brake Spindle

    Charts

    Specs

    Our rotors are machined and fully e-coated, just like the rotor hats. This is a protectant coating the prohibits surface rust from forming on the exposed surfaces. Once the parts are installed and being bedded in, the brake pad friction and caliper pressure will remove the coating at the spot the brake pads touch. This will expose the silver iron material underneath.

    Wilwood 140-10737-D Specifications

    KEY SPECS
    MFG. Part #140-10737-D
    BrandWilwood
    PositionFront
    Wheel Bolt Pattern (in.)5x4.5 in. | 5x4.75 in.
    Wheel Bolt Pattern (mm)5x114.3 mm | 5x120.65 mm
    Rotor Diameter12.19 Inch
    Rotor TypeVented
    Caliper PistonsSix
    Caliper FinishPowder Coated
    Parking Brake ProvisionNo
    Minimum Recommended Wheel Diameter15 Inch
    Rotor ShapeRound
    Hardware IncludedYes
    Rotor StyleDrilled & Slotted
    Spindle TypeFactory Drum Spindle
    Front Rotor IncludedYes
    Front Rotor Diameter12.19 Inch
    Front Caliper IncludedYes
    Rear Caliper IncludedNo
    Front Spindles IncludedNo
    Master Cylinder IncludedNo
    Brake Booster IncludedNo
    Brake Hoses IncludedYes
    Rear Rotor IncludedNo
    ColorBlack
    Front Caliper Piston Quantity6
    Bolt Pattern5 on 4.5" | 4.75"
    Front Caliper FinishPowder Coated
    GENERAL
    GTIN Code889545010039
    Rotor Thickness0.81"
    Stud Diameter0.52"
    Front Suspension TypeIFS
    Mount TypeLug
    OE Hub Offset0.23"
    Total Piston Area5.06 sq. in.
    Piston TypeStainless
    Pad Area7.30 sq. in.
    Pad Volume2.4 cu. in.
    Brake Pad CompoundBP-10
    Caliper TypeLug
    Rotor FinishBlack E-Coat
    Rotor Material TypeIron
    Vane Count32 Straight Vane
    BeddedNo
    BalancedNo
    Hat TypeBig Brake Hat - Short Offset
    Hat FinishBlack E-Coat
    Hat Material TypeAluminum
    Hat Offset Dimension1.43"
    Brake Lines IncludedNo
    Caliper ColorBlack
    Caliper Material TypeForged Aluminum
    Hat Bolt Circle 15 x 4.50
    Hat Bolt Circle 25 x 4.75
    Stud Diameter 20.52"
