Wilwood 120-9689-PLP Dynapro Single Caliper, Polished, 3.75 Inch Mount

#8351209689PLP

Wilwood 120-9689-PLP Dynapro Single Caliper, Polished, 3.75 Inch Mount

Name: Wilwood 120-9689-PLP Dynapro Single Caliper, Polished, 3.75 Inch Mount
Brand: Wilwood
SKU: 8351209689PLP
Price: 358.45 USD
Availability: InStock

Write a Review

Ask a Question

Finish:

Polished

Anodized

$358.45

/each

Factory Shipped

$374.03

Save $15.58

Quantity

Need Help? Call to Order

Add to a list

Select a vehicle to verify Fitment

Select Vehicle

Product Summary

Universal Fit, Two Caliper Pistons, 1.75" Bore Size

See more details

Key Specs

MFG. Part #	120-9689-PLP
Caliper Pistons	Two
Parking Brake Provision	No
Fittings Included	No
Brake Pads Included	No

See more specs

Need To Know

Need help?

855.313.9176

View the Help Center

Quick and Easy Returns

Return Policy

Wilwood 120-9689-PLP Details

The DynaPro Single (DPS) billet caliper is the newest generation of calipers available as an upgrade or replacement for applications previously using the Dynalite Single (DLS) series. DPS calipers combine superior strength with performance enhancements to make these the best "Dyna" series calipers ever. Calipers are fully CNC machined from premium grade alloy billet. The FEA generated body design incorporates a fortified transition between the piston housings and the bridges. Strengthening this critical area has substantially increased its resistance to deflection and body separation under load. Reductions in overall deflection, and the subsequent decreases in fluid volume displacement, translate to increased clamping efficiency with less pedal travel. The DPS is loaded with exclusive Wilwood performance enhancements. The calipers feature Quick-E-Clip pad retainers that support a 6812 type brake pad from the top. In addition to fast pad service without caliper removal, this feature provides substantially stronger retention over the single Quick-Clip pin and 7012 type pads used in the previous DLS models. The DPS uses heavy wall stainless steel pistons to resist corrosion and slow the heat transfer from the pads. The heavy wall sectional thickness improves pedal firmness and adds to the overall clamping efficiency by eliminating piston backside deflection. Calipers are fitted with replaceable stainless steel SRS bridge plates. SRS plates eliminate bridge wear caused by pad gouging. The spring-loading action of the SRS plates eliminates pad rattle and dampens the vibration harmonics that contribute to squeal during engagement. The package is completed with internal fluid passages and four corner bleed screws that allow mounting in any front, rear, left, or right side position.

Wilwood 120-9689-PLP Specifications

KEY SPECS
MFG. Part #	120-9689-PLP
Brand	Wilwood
Caliper Pistons	Two
Parking Brake Provision	No
Fittings Included	No
Brake Pads Included	No
Material Type	Aluminum

GENERAL
Piston Diameter	1.75"
Caliper Material Type	Aluminum
Caliper Color	Polished
Thread Size	1/8" NPT
Bracket Included	No
Caliper Mounting Type	Lug
Rotor Diameter	13 Inch
Mounting Side	Universal
Bore Size	1.75"
Color	Natural
Centerline of Holes	3.75"
Thread Pitch	1/8-27 NPT
Rotor Thickness	0.19"
Finish	Polished
Total Piston Area	2.40 sq. in.
Mount Hole Size	0.39"
Mounted Height	1.92"
Pad Area	3.00 sq. in.
Pad Volume	1.10 cu. in.
GTIN Code	889545007121
Notes	The DynaPro Single billet caliper is the next generation of calipers available as an upgraded or replacement for applications previously using the Dynalite Single series calipers.
Logo	Wilwood
