D8-6 front calipers are a direct bolt-on 6 piston replacement for the OE factory 4 piston front calipers on all 1965-82 Corvettes. Forged billet aluminum bodies, stainless steel pistons, and high temperature seals put an end to the rust, bore pitting, and seal failures that plague the original cast iron caliper design. D8-6 calipers mount in the stock location over stock rotors and use the original type D8 brake pads. These calipers fit inside 1967 and later production steel rally wheels and most of the later model alloy wheels. Original steel JK code wheels from 1965-66, and some aftermarket alloy replica wheels, will requires a 3/16 or thicker wheel spacer for clearance. D8-6 calipers use the same overall piston volume as the original calipers, but with the added benefit of differential bores. Differential bores counteract pad taper in high temperature racing and the 6 piston design offer greater pad support. Other than a new flexline with an 1/8 -27 NPT end for the new aluminum caliper, no other changes such as master cylinder output or front to rear bias adjustment are necessary. D8-6 calipers are the product of Wilwood's in-house FEA design and 3-D modeling technology. With its unyielding strength and superior piston design, the D8-4 generates positive pedal response and high clamping efficiency with a substantial weight savings.

Wilwood 120-11711-RD Specifications

KEY SPECS
MFG. Part #	120-11711-RD
Brand	Wilwood
Caliper Pistons	Six
Parking Brake Provision	No
Fittings Included	No
Brake Pads Included	No
Material Type	Aluminum

GENERAL
Piston Diameter	1.88"
Caliper Material Type	Aluminum
Caliper Color	Red
Bracket Included	No
Caliper Mounting Type	Lug
Rotor Diameter	11.75 Inch
Mounting Side	Right Hand
Bore Size	1.88"
Color	Red
Centerline of Holes	7.00"
Thread Pitch	1/8-27 NPT
Rotor Thickness	1.25"
Finish	Powder Coated
Bore 2 Size	1.38"
Bore 3 Size	1.250"
Total Piston Area	5.51 sq. in.
Mount Hole Size	0.00"
Mounted Height	1.83"
Pad Area	0.00 sq. in.
Pad Volume	3.90 cu. in.
Position	Front
GTIN Code	889545002126
Notes	Direct 6-piston bolt-on replacement for factory 4-piston front calipers.
Logo	Wilwood

Ratings & Reviews

Be the first to write a review.

Questions & Answers

Be the first to ask a question.

Fitment

1965-1982 Chevy Corvette
