Walker C-493-1 Cobra 1942-1948 Ford Radiator for Chevy Engine
Discontinued
This item is currently not available
Shop all Walker Cobra Radiators
Key Specs
| Radiator Style | Single Pass |
| Radiator Flow Direction | Downflow |
| Material Type | Copper/Brass |
| Inlet Location | Upper driver side |
| Outlet Location | Lower passenger side |
Need To Know
Need help?
855.313.9176Quick and Easy Returns
Return PolicyWalker Radiator Works C-493-1 Details
Walker Radiator Works C-493-1 Details
Walker Cobra Series radiators boast a relatively thin, but efficient, high-flow copper core which is ideal for use with mild Small Block engines with stock or low compression ratios. Each radiator is built for a direct fit with heavy gauge steel side brackets and standard mounting holes pre-stamped. Plus, all radiators feature a built-in oil cooler for use with automatic transmissions. They work with original, reproduction, steel or fiberglass grille shells.
- Copper core w/ 1-piece brass tanks
- Vertical tubes every 1/4" and 17 fins per inch of height
- Heavy duty 12 Ga. steel side brackets w/ pre-drilled holes
- Use a 15-18 lb. radiator cap
- Brass drain cock
- Simple bolt-in install w/ no modifications to grille or grille shell
Learn more about how radiators work and selecting the proper radiator for your vehicle by reading our tech article.Radiator Cooling Performance.
Charts
Specs
Guides & Documents
Warranty Information
Click for details
Warranty Information
Click for details
This item is in closeout status and as such, no manufacturer warranty is applicable or extended with its purchase.
Walker Radiator Works C-493-1 Specifications
Walker Radiator Works C-493-1 Specifications
| KEY SPECS | |
|---|---|
| MFG. Part # | C-493-1 |
| Brand | Walker Radiator Works |
| Radiator Style | Single Pass |
| Radiator Flow Direction | Downflow |
| Material Type | Copper/Brass |
| Inlet Location | Upper driver side |
| Outlet Location | Lower passenger side |
| Row Quantity | 3 |
| Overall Width Range | 20.00" to 20.99" |
| Overall Width | 20.13" |
| Overall Height Range | 25.00" to 25.99" |
| Overall Height | 25.38" |
| Overall Thickness | 4.13" |
| Core Width Range | 20.00" to 20.99" |
| Core Width | 20" |
| Core Height Range | 19.00" to 19.99" |
| Core Height | 19.5" |
| Core Thickness | 2.00" |
| Finish | Painted |
| Cooling Fan | Not Included |
| Transmission Cooler | Yes |
| Shroud Included | No |
| GENERAL | |
| Filler Neck Height | 0.88" |
| Inlet Size | 1.50 |
| Color | Black |
| Fan Included | No |
| Notes | 1/8" NPT fittings for transmission cooler. 1/4" NPT fitting for drain. 1.75" wide mounting feet on both sides. |
| Sold in Quantity | Each |
Ratings & Reviews
Ratings & Reviews
Fitment
Fitment
1946-1948 Ford Deluxe
1942 Ford Model 2 GA Special
1942 Ford Model 21 A Deluxe
1942-1947 Ford Sedan Delivery
1942-1948 Ford Super Deluxe
