#91645169
Speedway Universal Ladder Bar Rear Suspension Kit, 54 Inch
- Get the awesome look and functionality of ladder bars with this simple to install weld on kit
- Mounts are included for coil-overs lower mount point
- Rear four bar rear axle brackets have 3 holes for different height adjustments
$518.99
/kit
In Stock
Quantity
Need Help? Call to Order
Add to a list
Select a vehicle to verify Fitment
Select Vehicle
Product Summary
Universal Fit
- Get the awesome look and functionality of ladder bars with this simple to install weld on kit
- Mounts are included for coil-overs lower mount point
- Rear four bar rear axle brackets have 3 holes for different height adjustments
- Panhard bar or Watts link is required
- This complete kit includes one pair of 54" heavy ladder bars, 3/4" heavy duty front rod ends and jam nuts, stainless steel 11 degree 5/8" rear rod ends and jam nuts, lower coil over mounts and rear axle brackets
Comes as a Kit
View Kit Components
Need To Know
Need help?
855.313.9176Quick and Easy Returns
Return PolicySpeedway Motors 91645169 Details
Speedway Motors 91645169 Details
Our ladder bar kit includes one pair of 54" long heavy wall ladder bars, 3/4" heavy duty front rod end and jam nuts, stainless steel 11 degree 5/8" rear rod ends (straight or 7 deg rod ends available for substitution upon request using comments box at checkout) and jam nut, lower coil over mounts and rear axle brackets. Welding and fitting required.
- 3/4" heavy duty front rod end and jam nuts
- Stainless steel 11 degree 5/8" rear rod ends and jam nut (Straight or 7 deg also available for substitution upon request using comments box at checkout)
- Lower coil over mounts and rear axle brackets
- Welding and fitting required
Charts
916-45169 Instructions (pdf)
Speedway Motors 91645169 Specifications
Speedway Motors 91645169 Specifications
| KEY SPECS | |
|---|---|
| MFG. Part # | 91645169 |
| Brand | Speedway Motors |
Ratings & Reviews
4.1
7 Reviews
Customers appreciate the sturdy material and precision fit of our product, commenting on its overall good quality. However, some users note the need to re-tap threads for a smooth installation. The product meets customer needs with the help of tech support, who effectively customize the kits, requiring minimal modifications from users. Despite occasional minor inconsistencies in bar ends, the product holds up well under practical usage, standing out for its robust build, good value for money, and adaptability to specific requirements.
Ratings & Reviews
4.1
7 Reviews
Customers appreciate the sturdy material and precision fit of our product, commenting on its overall good quality. However, some users note the need to re-tap threads for a smooth installation. The product meets customer needs with the help of tech support, who effectively customize the kits, requiring minimal modifications from users. Despite occasional minor inconsistencies in bar ends, the product holds up well under practical usage, standing out for its robust build, good value for money, and adaptability to specific requirements.
4.1
7 reviews
5
3
4
2
3
2
2
0
1
0
Filter by Ratings
Yes
5.0
3 months ago
Frankenfreak
Prince Albert Sask.
Verified
Nicely built… strong.
Would Recommend
Good product, Must re tap all threads
4.0
5 years ago
Rich
Louisiana
Verified
As described
Would Recommend
Good for gassers, average quality
3.0
5 years ago
Prime Time
West Coast
These bars are ok quality. Like someone else said, chase the threads with a tap before you install rod ends. Also I got 11* rod ends instead of straight, but that was my own mistake when ordering. If you lay these bars flat on a surface plate they bow super slightly in a c shape, not nearly enough to be concerned or mad about but it is noticeable under observable conditions.
Sweet
5.0
7 years ago
Rancharo
NJ
Verified
Great quality material. Great precision fit.
Would Recommend
Good product but needs some tweeking before use
3.0
8 years ago
Axel's 40
Wisconsin
Verified
Nicely built but you'll need taps and dies for both ends to chase the threads on the ladder bar ends and heim joints and four bar ends to get them to screw in smoothly, at least on two sets that I received.
Would Recommend
Gasser ladder bars
4.0
10 years ago
Gasser1
Palmdale, CA
Verified
I was sent 11 degree offset bar ends instead of straights. Very unhappy about that
Would Recommend
Ladder bar kit customized to my needs
5.0
10 years ago
Bob
Schenectady, NY
Verified
Tech support took a catalog ladder bar kit and swapped out unneeded parts and added parts in that met my needs and put together a nice kit price. The peices all went together and I had very little to do as far as modifications, but those changes were explained to me before my purchase was made.
Would Recommend
Showing 7 of 7 reviews
