#721HFR12
QA1 HFR12 H Series Rod End, Chromoly Steel, Male 3/4-16 RH Thread, 3-Piece
$32.99
/each
Factory Shipped
$47.45
Save $14.46
Quantity
Need Help? Call to Order
Add to a list
Share
Select a vehicle to verify Fitment
Select Vehicle
Key Specs
| Thread Type | RH Female |
| Rod End Attachment | Female Threads/Eyelet |
| Thread Pitch | 3/4"-16 |
| Material Type | Chromoly |
| Hole Diameter | 0.75" |
Need To Know
Need help?
855.313.9176Quick and Easy Returns
Return PolicyQA1 HFR12 Details
QA1 HFR12 Details
Female 3-Piece Rod End QA1's HF Series female rod ends are a traditional three-piece chromoly steel rod end. These precision rod ends are heat treated, are available in right and left hand threads and in metric and inch dimensions.
Ball
- 52100 Bearing Steel
- Heat Treated Hard Chrome Plated
- Precision Ground
Race
- Chromoly Heat Treated
- Steel Corrosion and Wear Resistant
Body
- Chromoly Steel
- Heat Treated Protective Coated for Corrosion Resistance"
Guides & Documents
QA1 HFR12 Specifications
QA1 HFR12 Specifications
| KEY SPECS | |
|---|---|
| MFG. Part # | HFR12 |
| Brand | QA1 |
| Thread Type | RH Female |
| Rod End Attachment | Female Threads/Eyelet |
| Thread Pitch | 3/4"-16 |
| Material Type | Chromoly |
| Hole Diameter | 0.75" |
| Rod End Style | Metal-to-metal |
| Rod End Construction | 3-piece |
| Grease Fitting | No |
| Finish | Zinc Plated |
| Color | Natural |
| Bushing Material | Steel |
| Jam Nut Included | No |
| GENERAL | |
| Thread Length | 1.75" |
| Rod End Head Diameter | 1.75" |
| Rod End Head Width | 0.875" |
| Rod End Misalign Angle | 14 degrees |
| Heat Treated | Yes |
| Load Capacity | 28081 lbs. |
| GTIN Code | 806990005427 |
| Sold in Quantity | Each |
