Model A to 1934 Ford 48 In I-Beam Axle Radius Rod Kit - Ford Spindle
Model A to 1934 Ford 48 In I-Beam Axle Radius Rod Kit - Ford Spindle
Universal Fit, Straight Axle Front Suspension Type, 4 Inch Lowered Suspension Height Adjustment
On Backorder
Ships FREE
STORE PICKUP
Availability
Store Pickup Availability
X
Lincoln, NE -
Phoenix, AZ -
Select Vehicle
Model A to 1934 Ford 48 In I-Beam Axle Radius Rod Kit - Ford Spindle
X
We estimate this item will ship on or before March 19th.
Part # 91639506
$599.99
each
Add to Buildlist
Compare
Details
What's In The Kit
Reviews
Q&A
Videos & Articles
- This Radius Rod I-Beam axle kit is designed to fit '28-'31 Model A and '32-'34 Ford frames
- The 48" I-Beam axle requires '37-'48 Ford passenger car spindles
- 27" hairpin radius rods provide elegant hot rod styling
- 31-1/4" Super Glide spring has nylon buttons which work as a dry lubricant to improve ride quality
- Steering and brake kits are available to complete your front end
Build Your Kit
You're almost there! This kit has an option or two for you to select. Let us know which options you want for your new kit.Next
Details
Front Suspension Type:
Straight Axle
Suspension Height Adjustment:
4 Inch Lowered
Control Arm Style:
Radius Rod
Shock Type:
Not Included
Spring Type:
Leaf Spring
Finish:
Natural
Bolt Pattern:
Not Applicable
Rotor Diameter:
Not Included
Spindle Style:
Ford Stock
Dropped Spindles:
No
Dropped Axle:
Yes
Dropped Control Arms:
No
Front Leaf Spring Style:
Spring-Over Axle
Spindles Included:
No
Steering Included:
No
MFG. Part #:
91639506
Welding Required:
Yes
Info
Speedway Radius Rod I-Beam axle kits are designed to fit '28-'31 Model A and '32-'34 Ford frames. I-Beam axles require '37-'48 Ford passenger car spindles. Kits are available in Plain steel or Chrome.
Each kit includes:
- 48" kingpin-to-kingpin I-beam axle, 4" dropped
- 27" hairpin radius rods
- Forged steel perch bolts
- Forged steel lower shock mounts (key-slotted design)
- Spring shackles w/ nylon bushings
- 31-1/4" eye-to-eye 4-leaf Super Glide spring, 1-3/4" wide
- All hardware for assembly
Notes
Installation Guide (PDF)
Charts
916-39506 Instructions (PDF)
Important Messages
- Get FREE shipping when your order includes this item and exceeds $99! Ground shipping only in the contiguous US.
Some parts are not legal for use in California or other states with similar laws/regulations
Related Products
-
Ford Model T - 1934 Front Spring U-Bolt Kit, Plain Steel$31.49 -
Speedway 1928-1948 Ford Forged Spindles w/ King Pins$227.19
What's In The Kit
Each kit from Speedway Motors is carefully packaged and delivered right to your door. Below is a list of all the items you should expect to receive when you order this kit. Some of these items may also be available for sale individually if you're here looking for replacement parts.
-
Plain 1928-36 Ford 4 Inch Dropped I-Beam Axle, 48 InchesPart # 7022850Qty x 1
-
Super Glide® Front Spring, 48 Inch Axle, Reverse Eye, PlainPart # 91033030Qty x 1
-
Radius Rod/Four-Bar Frame Mounting Brackets, 5/8 Hole, 4-3/8 InchPart # 91635051Qty x 1
-
Speedway Front Solid Axle Leaf Spring Perch, Plain Forged SteelPart # 91033047Qty x 1
-
Front Hairpin Radius Rods, 27 Inch, Plain SteelPart # 91635023Qty x 1
-
Speedway Bolt-On Hairpin Radius Rod Axle BracketsPart # 91635000Qty x 1
-
Steel Clevis, 5/8-18 RH Thread, 3/8 Inch Slot, Zinc PlatedPart # 91002006Qty x 4
-
Standard Steel Heim Joint Rod Ends, 5/8-18 RH MalePart # 1750106Qty x 2
-
Steel Jam Nuts, 5/8 Inch-18 Right Hand NF Fine Thread, Pack/6Part # 1756046-RHQty x 1
-
Transverse Leaf Spring Shackles w/ Nylon Bushings, Zinc FinishPart # 91033323-ZINCQty x 1
-
Speedway Forged Steel Lower Shock Mounts for Front Solid Axle, ZincPart # 91036105Qty x 1
-
Nut/Bolt KitPart # 91649021-1Qty x 1
-
Hairpin Front Axle InstructionsPart # 916395Qty x 1
-
Steel Cone Spacers for Rod Ends, 5/8 InchPart # 5464110Qty x 1
