MSD 8365 Pro-Billet Chevy HEI Distributor Kit, Moroso Plug Wires

Breathe new life into your Small Block Chevy or Big Block Chevy engine with this easy-to-install distributor ignition kit!

Kit Includes:

• (1) MSD 8365 Pro-Billet Chevy HEI Distributor
• (1) Moroso Ready to Install Plug Wire Set-HEI/Under Header/Red
• (1) Chevy Distributor Clamp
• (1) GM HEI Distributor Wiring Pigtail Connector, 10 Inch

MSD 8365 Pro-Billet Chevy HEI Distributor

• Easy-to-adjust mechanical advance with supplied springs and stop bushings
• Vacuum advance canister for improved economy (can be locked out)
• CNC machined billet aluminum housing and billet aluminum base
• Polished steel shaft is QPQ coated and guided by a sealed ball bearing
• Advance plate and weights are fine blanked from chromoly steel and QPQ coated for friction reduction
• Mechanical advance assembly can easily be locked out
• Advance weight pins are staked and tig welded to the plate
• Nylon pads ensure smooth operation of the advance weights
• Special oil tract improves lubrication to the distributor and cam gear
• Supplied with a 7.5 amp, single spark, inductive discharge ignition module
• Epoxy filled 42,000 Volt coil with .31 OHMs resistance
• Full spark energy output to 9,000 RPM
• Supplied with brass terminal distributor cap and rotor
• Iron distributor gear
• Includes three sets of springs and four stop bushings
• Dial in up to 24 different timing curves to match your driving needs

Moroso Ready to Install Plug Wire Set

• Save time and energy with these pre-assembled Moroso 8mm spiral core wires
• Fiberglass reinforced with a silicone outer layer
• 90° boots on both ends
• Available in Red

Chevy Distributor Clamp

• Extra heavy duty distributor clamp
• Gives more hold-down area for your Small Block Chevy (SBC) or Big Block Chevy (BBC)

GM HEI Distributor Wiring Pigtail Connector

• Features a dual HEI connector that helps clean up your engine bay by eliminating the use of single spade connectors to make battery and tachometer connections
• 10 inch length
• Red and green wires to identify battery and tach leads

• 265-400 S/B Chevy
• 396-454 B/B Chevy
• Designed to replace GM HEI distributors that use a 4-Pin ignition module

547-8365 Instructions (PDF)

Spark Plug Wires:

• Spiral Core conductor style
• 90 Degree boot ends
• 8mm diameter wires

Plug Wire Lengths Included:

• 37-7/8" x 1
• 37"       x 2
• 35-1/2" x 1
• 33"       x 1
• 29-5/5" x 1
• 27-3/4" x 2

For warranty information, please visit http://www.msdhelp.com/
