Product Summary

63-89 Chevy, 63-91 GMC, Mono Tube Shock Type, 5" Stroke

    Key Specs

    MFG. Part #KG5409
    BrandKYB
    Shock TypeMono Tube
    Shock Body MaterialSteel
    Shock Body TypeSmooth

    Need To Know

    Free Shipping on Orders Over $149

    Shipping Policies & FAQs

    Quick and Easy Returns

    Return Policy

    Details

    The KYB Gas-a-Just monotube shock has two possible purposes.  First, it's a direct OE replacement if your vehicle came with a monotube.  Second, the Gas-a-Just is also performance upgrade for vehicles that came factory direct with a twin tube.  It can also increase steering responsiveness by as much as 30%.  The monotube design never experiences shock fade and the high gas pressure can automatically add performance for more aggressive driving conditions or for heavier loads.

    • The correct replacement for monotube equipped vehicles
    • A performance upgrade for twin-tube equipped vehicles
    • The monotube design is more responsive and automatically adjusts to driving conditions
    • Provides a firmer ride and additional control
    • Extended Length: 14.88"
    • Compressed Length: 9.88"
    • Stroke: 5"
    • Position: Front

    Application

    Chevrolet Blazer - Full Size (2WD) 1982-1969
    Chevrolet G-Series (1 Ton) 1995-1971
    Chevrolet G-Series (1/2 Ton) 1995-1971
    Chevrolet G-Series (3/4 Ton) 1995-1971
    Chevrolet P10 1984-1963
    Chevrolet P20 1991-1968
    Chevrolet P30 (Exc. Motorhome Chassis) 2001-1968
    Chevrolet Pickup (1 Ton) (2WD) 1991-1967
    Chevrolet Pickup (1/2 Ton) (2WD) 1987-1963
    Chevrolet Pickup (3/4 Ton) (2WD) 1990-1963
    Chevrolet Suburban (1/2 Ton) (2WD) 1991-1963
    Chevrolet Suburban (3/4 Ton) (2WD) 1991-1963
    GMC G-Series (1/2 Ton) Van 1995-1971
    GMC G-Series (3/4 Ton) Van 1995-1971
    GMC G-Series Van (1 Ton) (Exc. Motorhome Chassis) 1995-1971
    GMC Jimmy - Full Size (2WD) 1982-1969
    GMC P1000
    P1500 1984-1963
    GMC P2500 1991-1968
    GMC P3500 (Exc. Motorhome Chassis) 2001-1968
    GMC Pickup (1 Ton) (2WD) 1991-1967
    GMC Pickup (1/2 Ton) (2WD) 1987-1963
    GMC Pickup (3/4 Ton) (2WD) 1989-1963
    GMC Suburban (1/2 Ton) (2WD) 1991-1963
    GMC Suburban (3/4 Ton) (2WD) 1991-1963

    Specifications

    KEY SPECS
    MFG. Part #KG5409
    BrandKYB
    Shock TypeMono Tube
    Shock Body MaterialSteel
    Shock Body TypeSmooth
    GENERAL
    Shock Stroke Range5.00" to 5.99"
    PositionFront
    Stroke5"
    Shock Stroke5.00
    Upper Shock Mount1/2" Bushed Eyelet
    Lower Shock Mount1/2" Bushed Eyelet
    Extended Length Range14.00" to 14.99"
    Extended Length14.88"
    Compressed Length Range9.00" to 9.99"
    Compressed Length9.88"
    Schrader ValveNo
    FinishPainted
    Sold in QuantityEach
    Hardware IncludedYes
    GTIN Code781552054092
    Gas ChargedYes
    ColorSilver
