#9108941
Flathead 10 Inch Clutch Disc/Pressure Plate/Release Bearing Kit
$360.99
/kit
In Stock
$367.46
Save $6.47
Quantity
Need Help? Call to Order
Add to a list
Select a vehicle to verify Fitment
Select Vehicle
Product Summary
10" Diameter, Organic Friction Material
Comes as a Kit
View Kit Components
Key Specs
| Diameter | 10" |
| Friction Material | Organic |
| Disc Style | Full face |
| Hub Style | Sprung |
| Flywheel Included | No |
Need To Know
Need help?
855.313.9176Quick and Easy Returns
Return PolicySpeedway Motors 9108941 Details
Speedway Motors 9108941 Details
It's getting harder to find flathead Ford clutch components. We can help you resolve this problem with our clutch kit that features 10" clutch discs and 10" Long-style pressure plates for the flathead V8. Kit also includes clutch alignment tool and release bearing.
They replace 10" OEM with a 11-5/8" bolt circle. These premium organic clutch friction discs are for use with flathead Ford V8. The pressure plate has a 6 bolt pattern divided up into 3 groups of 2 with a 3.125” center-to-center. The bearing assy is typical of those used on '35-'48 Ford passenger cars (except with the V8-60). This is the bearing and the collar.
Flathead 10 Inch Clutch Disc
- 1-3/8 Inch 10-Spline
- Early Ford Applications
- 1" center spline height while laying on side
Pressure plate bolt pattern must match your flywheel!
Charts
Speedway Motors 9108941 Specifications
Speedway Motors 9108941 Specifications
| KEY SPECS | |
|---|---|
| MFG. Part # | 9108941 |
| Brand | Speedway Motors |
| Diameter | 10" |
| Friction Material | Organic |
| Disc Style | Full face |
| Hub Style | Sprung |
| Flywheel Included | No |
| GENERAL | |
| Pressure Plate Style | Long |
| Throwout Bearing Included | Yes |
| Alignment Tool Included | Yes |
| Pilot Bushing Included | No |
| Counterweight Assist | Yes |
| Sold in Quantity | Kit |
| Spline Count | 10 |
| Shaft Diameter | 1.375" |
Ratings & Reviews
5
2 Reviews
Customers have positively recognized the product for its specific functionality, connecting a '53 Mercury 8CA flathead to a '39 transmission. Users have confirmed the product quality, welcoming the possibility of repeat purchases. A suggestion was made for including a pilot shaft bushing in the kit to enhance practicality.
Ratings & Reviews
5
2 Reviews
Customers have positively recognized the product for its specific functionality, connecting a '53 Mercury 8CA flathead to a '39 transmission. Users have confirmed the product quality, welcoming the possibility of repeat purchases. A suggestion was made for including a pilot shaft bushing in the kit to enhance practicality.
5
2 reviews
5
2
4
0
3
0
2
0
1
0
Filter by Ratings
Yes I would buy again
5.0
a month ago
Jeff
Centerville Michigan
Verified
It ties my 53 Mercury 8CA flathead to the 39 transmission in my AV8
Would Recommend
I would buy this again if needed.
5.0
9 months ago
Humpy
Willits Ca.
Verified
Just what I ordered. The only thing that would make it better is if you would include a pilot shaft bushing in the kit.
Would Recommend
Showing 2 of 2 reviews
