#325174132
Edelbrock 174132 Fuel Pressure Regulator, Blue Anodized
- This carbureted fuel pressure regulator has an internal diaphragm made of fluorosilicone to ensure high temperature protection resulting in an extended life.
- This Edelbrock fuel pressure regulator #174131 is compatible with all grades of gasoline, ethanol, methanol and E85 fuels.
- Pressure regulation slope is 0.75 psi/gal of flow rate change.
$174.95
/each
Factory Shipped
Quantity
Need Help? Call to Order
Add to a list
Share
Select a vehicle to verify Fitment
Select Vehicle
Product Summary
Universal Fit, 1 Inlet Quantity, 1 Outlet Quantity
- This carbureted fuel pressure regulator has an internal diaphragm made of fluorosilicone to ensure high temperature protection resulting in an extended life.
- This Edelbrock fuel pressure regulator #174131 is compatible with all grades of gasoline, ethanol, methanol and E85 fuels.
- Pressure regulation slope is 0.75 psi/gal of flow rate change.
- Will hold fuel system pressure for at least 20 minutes after pump shutdown.
- Developed for optimum compatibility with Edelbrock electric fuel pumps.
Need To Know
Need help?
855.313.9176Quick and Easy Returns
Return PolicyEdelbrock 174132 Details
Edelbrock 174132 Details
This Edelbrock fuel pressure regulator #174132 is machined from aircraft quality aluminum for those who demand the best.
- This carbureted fuel pressure regulator has an internal diaphragm made of fluorosilicone to ensure high temperature protection resulting in an extended life.
- This Edelbrock fuel pressure regulator #174131 is compatible with all grades of gasoline, ethanol, methanol and E85 fuels.
- Pressure regulation slope is 0.75 psi/gal of flow rate change.
- Will hold fuel system pressure for at least 20 minutes after pump shutdown.
- Developed for optimum compatibility with Edelbrock electric fuel pumps.
Guides & Documents
Edelbrock 174132 Specifications
Edelbrock 174132 Specifications
| KEY SPECS | |
|---|---|
| MFG. Part # | 174132 |
| Brand | Edelbrock |
| Regulator Style | Return |
| GENERAL | |
| Inlet Quantity | 1 |
| Outlet Quantity | 1 |
| Regulator Material | Aluminum |
| Boost/Vacuum Reference Port | No |
| Gauge Port | Yes |
| Rebuildable | Yes |
| Inlet Attachment | Female Threads |
| Outlet Attachment | Female Threads |
| Includes Mounting Bracket(s) | Yes |
| Fittings Included | No |
| Regulator Finish | Blue anodized |
| Return Attachment | Female threads |
| Sold in Quantity | Each |
| Regulator Location | Inline |
| Return Fitting Size | 3/8 in. NPT |
| Notes | Capable of handling 160 gallons per hour. |
| GTIN Code | 087133932422 |
