#133324149005A
DeWitts® 32-4149005A 70-81 Camaro HP Radiator/Fan Combo, Auto
$1,738.99
/each
Factory Shipped
Quantity
Need Help? Call to Order
Add to a list
Select a vehicle to verify Fitment
Select Vehicle
Key Specs
| Radiator Style | Single Pass |
| Radiator Flow Direction | Crossflow |
| Material Type | Aluminum |
| Inlet Location | Upper driver side |
| Outlet Location | Lower passenger side |
Need To Know
Need help?
855.313.9176Quick and Easy Returns
Return PolicyDeWitts 32-4149005A Details
DeWitts 32-4149005A Details
PRO SERIES (2 ROW 1.00" TUBES)
DeWitts Pro-series aluminum radiators feature two rows of 1.0" wide cooling tubes which provides a 25% increase in cooling performance. Our Direct Fit® aluminum radiators feature factory type press formed end tanks, serpentine fins, and the factory type upper and lower channels. Each radiator core is assembled and brazed in our state of the art aluminum brazing furnace. DeWitts radiators are also epoxy free and come with a limited lifetime warranty. Direct Fit® is our official trademark and it means your radiator will fit, without modifications.
RADIATOR/FAN COMBINATIONS
The best of both worlds! The packages below include our Direct Fit® aluminum radiator and the Spal dual 11" fan assembled into one high-performance package. The dual fans eliminate the factory shroud and engine driven fans. All the necessary relays, fuses, and wiring are included. As a bonus, we add a port to the radiator and install the temperature switch, so you don't have to.
Guides & Documents
DeWitts 32-4149005A Specifications
DeWitts 32-4149005A Specifications
| KEY SPECS | |
|---|---|
| MFG. Part # | 32-4149005A |
| Brand | DeWitts |
| Radiator Style | Single Pass |
| Radiator Flow Direction | Crossflow |
| Material Type | Aluminum |
| Inlet Location | Upper driver side |
| Outlet Location | Lower passenger side |
| Row Quantity | 2 |
| Tube Size | 1.25" |
| Overall Width Range | 31.00" to 31.99" |
| Overall Width | 31" |
| Overall Height Range | 18.00" to 18.99" |
| Overall Height | 18.5" |
| Overall Thickness | 7.2" |
| Core Width Range | 26.00" to 26.99" |
| Core Width | 26.25" |
| Core Height Range | 18.00" to 18.99" |
| Core Height | 18.5" |
| Core Thickness | 2.75" |
| Finish | Natural |
| Cooling Fan | Dual |
| Transmission Cooler | Yes |
| Shroud Included | Yes |
| Fan Diameter | 11 Inch |
| CFM | 2780 CFM |
| CFM Range | 2,700-2,799 CFM |
| GENERAL | |
| Fan Included | Yes |
| Sold in Quantity | Each |
Ratings & Reviews
Ratings & Reviews
Fitment
Fitment
1970-1981 Chevy Camaro
