#1331139003M
DeWitts® 32-1139003M 68-72 Chevelle Direct Fit® Radiator
$805.99
/each
Factory Shipped
Quantity
Need Help? Call to Order
Add to a list
Share
Select a vehicle to verify Fitment
Select Vehicle
Key Specs
| Radiator Style | Single Pass |
| Radiator Flow Direction | Crossflow |
| Material Type | Aluminum |
| Inlet Location | Upper driver side |
| Outlet Location | Lower passenger side |
Need To Know
Need help?
855.313.9176Quick and Easy Returns
Return PolicyDeWitts 32-1139003M Details
DeWitts 32-1139003M Details
- DeWitts Pro-series aluminum radiators feature two rows of 1.0" wide cooling tubes which provides a 25% increase in cooling performance
- Our Direct Fit® aluminum radiators feature factory type press formed end tanks, serpentine fins, and the factory type upper and lower channels
- Each radiator core is assembled and brazed in our state of the art aluminum brazing furnace
- DeWitts radiators are also epoxy free and come with a limited lifetime warranty
- Direct Fit® is our official trademark and it means your radiator will fit, without modifications
Connections are top right & bottom right.
Used on Mach 1 and 1967-70 Mustang with 390/427/428.
1970 302/351 Mustang and Cougar with HD cooling.
Guides & Documents
Warranty Information
Click for details
Warranty Information
Click for details
DeWitts 32-1139003M Specifications
DeWitts 32-1139003M Specifications
| KEY SPECS | |
|---|---|
| MFG. Part # | 32-1139003M |
| Brand | DeWitts |
| Radiator Style | Single Pass |
| Radiator Flow Direction | Crossflow |
| Material Type | Aluminum |
| Inlet Location | Upper driver side |
| Outlet Location | Lower passenger side |
| Row Quantity | 2 |
| Tube Size | 1" |
| Overall Width Range | 33.00" to 33.99" |
| Overall Width | 33" |
| Overall Height Range | 18.00" to 18.99" |
| Overall Height | 18.5" |
| Overall Thickness | 3.25" |
| Core Width Range | 28.00" to 28.99" |
| Core Width | 28.25" |
| Core Height Range | 18.00" to 18.99" |
| Core Height | 18.5" |
| Core Thickness | 2.25" |
| Finish | Natural |
| Cooling Fan | Not Included |
| Transmission Cooler | No |
| Shroud Included | No |
| Inlet Size | 1.5 |
| Outlet Size | 1.75 |
| Radiator Cap Included | No |
| GENERAL | |
| Color | Natural |
| Fan Included | No |
| Sold in Quantity | Each |
Ratings & Reviews
Ratings & Reviews
Fitment
Fitment
1968-1972 Chevy Chevelle
