#1331139007M
DeWitts® 1139007M 1993-02 Camaro Direct Fit® Radiator
$805.99
/each
Factory Shipped
Quantity
Need Help? Call to Order
Add to a list
Select a vehicle to verify Fitment
Select Vehicle
Key Specs
| Radiator Style | Single Pass |
| Radiator Flow Direction | Crossflow |
| Material Type | Aluminum |
| Inlet Location | Upper driver side |
| Outlet Location | Lower passenger side |
Need To Know
Need help?
855.313.9176Quick and Easy Returns
Return PolicyDeWitts 32-1139007M Details
DeWitts 32-1139007M Details
The superior quality of a DeWitts® radiator begins with a manufacturing process that is controlled 100% in house. Every core is assembled and brazed in Howell, MI to ensure excellence throughout the entire build. DeWitts® is the only USA aftermarket radiator company to own an aluminum Nocolok® brazing furnace which allows for production of a superior, epoxy free, aluminum core. DeWitts® radiators are assembled with press formed end tanks which eliminate fabrication seams and potential leak points of common box tanks while providing an original equipment look for your classic car. In most cases, DeWitts® double row radiators provide a 30% increase in heat rejection. Adding an electric fan will boost that number an additional 10%. If you’re still not sure if that’s enough, HP models are available with 1 1/4" tubes and offer approximately another 10% cooling capacity. Every DeWitts® Aluminum radiator is designed to fit the listed application without any modifications to your car and is available in your choice of a natural, Black Ice™ or polished finish.
- Direct Fit® with no modification
- Epoxy free, aluminum, dual row core
- 1" tubes
- Press formed end tanks
- Assembled and brazed in Howell, MI
Guides & Documents
Warranty Information
Click for details
Warranty Information
Click for details
DeWitts 32-1139007M Specifications
DeWitts 32-1139007M Specifications
| KEY SPECS | |
|---|---|
| MFG. Part # | 32-1139007M |
| Brand | DeWitts |
| Radiator Style | Single Pass |
| Radiator Flow Direction | Crossflow |
| Material Type | Aluminum |
| Inlet Location | Upper driver side |
| Outlet Location | Lower passenger side |
| Row Quantity | 2 |
| Tube Size | 1" |
| Overall Width Range | 31.00" to 31.99" |
| Overall Width | 31" |
| Overall Height Range | 17.00" to 17.99" |
| Overall Height | 17" |
| Overall Thickness | 3.25" |
| Core Width Range | 24.00" to 24.99" |
| Core Width | 24.75" |
| Core Height Range | 17.00" to 17.99" |
| Core Height | 17" |
| Core Thickness | 2.25" |
| Finish | Natural |
| Cooling Fan | Not Included |
| Transmission Cooler | No |
| Shroud Included | No |
| Radiator Cap Included | No |
| GENERAL | |
| Inlet Size | 1.25 |
| Outlet Size | 1.5 |
| Color | Natural |
| Fan Included | No |
| Sold in Quantity | Each |
Ratings & Reviews
Ratings & Reviews
Fitment
Fitment
1993-2002 Chevy Camaro
